PRIME X670E-P

Advertisement

Table of Contents
loading

Related Manuals for Asus PRIME X670E-P

Summary of Contents for Asus PRIME X670E-P

  • Page 1 PRIME X670E-P...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ...................... iv About this guide ......................v PRIME X670E-P specifications summary ..............vi Connectors with shared bandwidth ................x Package contents ....................... xi Installation tools and components ................xii Chapter 1: Product Introduction Before you proceed ................... 1-1 Motherboard layout..................

  • Page 4: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 5: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.

  • Page 6: Prime X670E-P Specifications Summary

    2 x PCIe 4.0 x16 slots (support x4 mode) Expansion Slots 1 x PCIe 3.0 x1 slot** * Please check the PCIe bifurcation table at https://www.asus.com/support/ FAQ/1037507/. ** The PCIe 3.0 x1 slot shares bandwidth with the SATA6G_3/4 ports. When a device is installed on the PCIe 3.0 x1 slot, the SATA6G_3/4 ports cannot be...
  • Page 7 PRIME X670E-P specifications summary Rear USB (Total 10 ports) 1 x USB 3.2 Gen 2x2 port (1 x USB Type-C ® 3 x USB 3.2 Gen 2 ports (3 x Type-A) 4 x USB 3.2 Gen 1 ports (4 x Type-A) 2 x USB 2.0 ports (2 x Type-A)
  • Page 8 PRIME X670E-P specifications summary Miscellaneous 3 x Addressable Gen 2 headers 2 x Aura RGB headers 1 x Clear CMOS header 1 x COM Port header Internal I/O Connectors 1 x Front Panel Audio header (AAFP) 1 x S/PDIF Out header...
  • Page 9 Operating System Windows 11, Windows 10 64-bit ® ® ATX Form Factor Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm) Specifications are subject to change without notice. Please refer to the ASUS website for the latest specifications.

  • Page 10: Connectors With Shared Bandwidth

    Connectors with shared bandwidth PLUG_8PIN_PWR CPU_OPT KBMS_USB_2627 ATX_12V_2 ATX_12V_1 DIGI FLBK_LED +VRM BIOS_FLBK AIO_PUMP CPU_FAN HDMI_DP U32G1_2_3_4_23 U32G2_22 U32G2X2_C18 SOCKET AM5 LAN_U32G2_2021 AUDIO M.2(WIFI) 256Mb BIOS 2280 2260 2242 CHA_FAN1 PCIE SATA 5.0 X4 M.2_1(SOCKET3) CHA_FAN2 PCIEX16_1 Ethernet Super X670 X670 M.2_2(SOCKET3) PCIE...

  • Page 11: Package Contents

    Package contents Check your motherboard package for the following items. Motherboard 1 x PRIME X670E-P motherboard Cables 2 x SATA 6Gb/s cables 1 x I/O Shield 1 x Rubber Package for M.2 Miscellaneous 2 x Screw Packages for M.2 SSD...

  • Page 12: Installation Tools And Components

    Installation tools and components Phillips (cross) screwdriver PC chassis Power supply unit AMD AM5 CPU AMD AM5/AM4/AM3 compatible CPU Fan DDR5 DIMM SATA hard disk drive SATA optical disc drive (optional) Graphics card (optional) M.2 SSD module (optional) Screws The tools and components in the table above are not included in the motherboard package.

  • Page 13: Chapter 1: Product Introduction

    Unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components. The pin definitions in this chapter are for reference only. The pin names depend on the location of the header/jumper/connector. PRIME X670E-P...

  • Page 14: Motherboard Layout

    Motherboard layout 24.4cm(9.6in) PLUG_8PIN_PWR CPU_OPT KBMS_USB_2627 ATX_12V_2 ATX_12V_1 DIGI FLBK_LED +VRM BIOS_FLBK AIO_PUMP CPU_FAN HDMI_DP U32G1_2_3_4_23 U32G2_22 U32G2X2_C18 SOCKET AM5 LAN_U32G2_2021 AUDIO M.2(WIFI) 256Mb BIOS 2280 2260 2242 CHA_FAN1 PCIE SATA 5.0 X4 M.2_1(SOCKET3) CHA_FAN2 PCIEX16_1 Ethernet Super X670 X670 M.2_2(SOCKET3) PCIE SATA...
  • Page 15 16. V-M.2 slot (Key E) 1-18 17. S/PDIF Out header 1-18 18. SPI TPM header (14-1pin) 1-19 19. System Panel header 1-20 20. Thunderbolt™ (USB4 ) header 1-21 ® 21. BIOS FlashBack™ LED 1-22 22. 8-pin Power Plug LED 1-22 PRIME X670E-P...
  • Page 16 Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related.
  • Page 17 A DDR5 memory module is notched differently from a DDR, DDR2, DDR3 or DDR4 module. DO NOT install a DDR, DDR2, DDR3 or DDR4 memory module to the DDR5 slot. Recommended memory configurations DIMM_A1 DIMM_A2 DIMM_A2 DIMM_A2 DIMM_B1 DIMM_B2 DIMM_B2 PRIME X670E-P...
  • Page 18 (D/C) from the same vendor. Check with the vendor to get the correct memory modules. • Visit the ASUS website for the latest QVL, and memory frequency support depends on the CPU types. Chapter 1: Product Introduction...
  • Page 19 Hyper M.2 x16 series card is installed. • For full details on the PCIe bifurcation, you may visit the support site at https://www.asus.com/support/FAQ/1037507/. • The Hyper M.2 x16 series card is sold separately. • Adjust the PCIe bifurcation under BIOS settings. PRIME X670E-P...
  • Page 20 Please refer to the following table for the recommended VGA configuration. Recommended VGA configuration Slot Description Single VGA Dual VGA Triple VGA PCIEX16_1 PCIEX16_2 PCIEX16_3 Connect chassis fans to the chassis fan headers when using multiple graphics cards for better thermal environment. Fan and Pump headers The Fan and Pump headers allow you to connect fans or pumps to cool the system.
  • Page 21 The system may become unstable or may not boot up if the power is inadequate. • If you want to use two or more high-end PCI Express x16 cards, use a PSU with 1000W power or above to ensure the system stability. PRIME X670E-P...
  • Page 22 M.2 slots The M.2 slots allow you to install M.2 devices such as M.2 SSD modules. M.2_1(SOCKET3) M.2_2(SOCKET3) M.2_3(SOCKET3) • AMD Ryzen™ 7000 Series Desktop Processors: - M.2_1 slot supports PCIe 5.0 x4 mode M Key design and type 2242/2260/2280 storage devices.
  • Page 23 The PCIe 3.0 x1 slot shares bandwidth with the SATA6G_3/4 ports. When a device is installed on the PCIe 3.0 x1 slot, the SATA6G_3/4 ports cannot be used. Before creating a RAID set, refer to the RAID Configuration Guide. You can download the RAID Configuration Guide from the ASUS website. PRIME X670E-P 1-11...
  • Page 24 USB 3.2 Gen 1 Type-C Front Panel connector ® The USB 3.2 Gen 1 Type-C connector allows you to connect a USB 3.2 Gen 1 ® Type-C module for an additional USB 3.2 Gen 1 Type-C port on the front panel. The ®...
  • Page 25 The USB 2.0 headers provide data transfer speeds of up to 480 Mb/s. USB_1415 PIN 1 USB_1617 PIN 1 DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! The USB 2.0 module is purchased separately. PRIME X670E-P 1-13...
  • Page 26 Addressable Gen 2 headers The Addressable Gen 2 headers allow you to connect individually addressable RGB WS2812B LED strips or WS2812B based LED strips. ADD_GEN 2_1 ADD_GEN 2_2 ADD_GEN 2_3 PIN 1 The Addressable Gen 2 header supports WS2812B addressable RGB LED strips (5V/ Data/Ground), with a maximum power rating of 3A (5V) and the addressable headers on this board can handle a combined maximum of 500 LEDs.
  • Page 27 RGB LED strip is connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard. • The LED strip will only light up when the system is powered on. • The LED strip is purchased separately. PRIME X670E-P 1-15...
  • Page 28 Clear CMOS header The Clear CMOS header allows you to clear the Real Time Clock (RTC) RAM in the CMOS, which contains the date, time, system passwords, and system setup parameters. CLRTC PIN 1 To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Short-circuit pin 1-2 with a metal object or jumper cap for about 5-10 seconds.
  • Page 29 HD Audio. Connect one end of the front panel audio I/O module cable to this header. AAFP PIN 1 HD-audio-compliant pin definition We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability. PRIME X670E-P 1-17...
  • Page 30 V-M.2 slot (Key E) The vertical M.2 slot (Key E) allows you to install an M.2 Wi-Fi module. M.2(WIFI) The M.2 Wi-Fi module and vertical M.2 Key E bracket set are purchased separately. S/PDIF Out header This header is for an additional Sony/Philips Digital Interface (S/PDIF) port. Connect the S/PDIF Out module cable to this header, then install the module to a slot opening at the back of the system chassis.
  • Page 31 A TPM system also helps enhance network security, protects digital identities, and ensures platform integrity. PIN 1 VCCSPI S_SPI_TPM_IRQ# S_PLTRST# S_SPI_TPM_CS2# TPM_DETECT_L F_SPI_PWR F_SPI_CS0#_R T_SPI_CLK T_SPI_MISO T_SPI_MOSI F_SPI_HOLD#_R The SPI TPM module is purchased separately. PRIME X670E-P 1-19...
  • Page 32 System Panel header The System Panel header supports several chassis-mounted functions. PLED PWRSW SPEAKER PANEL PIN 1 HDD_LED RESET PLED • System Power LED header (PLED) The 2-pin and/or 3-1 pin headers allow you to connect the System Power LED. The System Power LED lights up when the system is connected to a power source, or when you turn on the system power, and blinks when the system is in sleep mode.
  • Page 33 Please visit the official website of your purchased Thunderbolt™ card for more details on compatibility. The Thunderbolt™ card can only be used when installed to the PCIEX16_3 slot. Ensure to install your Thunderbolt™ card to the PCIEX16_3 slot. PRIME X670E-P 1-21...
  • Page 34 BIOS FlashBack™ LED The BIOS FlashBack™ LED lights up or blinks to indicate the status of the BIOS FlashBack™. FLBK_LED BIOS FlashBack™ Refer to the BIOS update utility section for more information on the feature. 8-pin Power Plug LED The 8-pin Power Plug LED lights up to indicate that the 8-pin power plug is not connected.

  • Page 35: Chapter 2: Basic Installation

    DO NOT force the CPU into the socket to prevent bending the pins and damaging the CPU. • ASUS will not cover damages resulting from incorrect CPU installation/removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user.
  • Page 36 Chapter 2: Basic Installation...

  • Page 37: Cooling System Installation

    CPU before you install the cooling system, if necessary. We recommend using AM5 compatible coolers with stock AM5 backplate to prevent potential damages to the pins in the socket. CPU heatsink and fan assembly Type 1 PRIME X670E-P...
  • Page 38 CPU heatsink and fan assembly Type 2 When using this type of CPU fan, remove the screws and the retention module only. Do not remove the plate on the bottom. Chapter 2: Basic Installation...
  • Page 39 To install an AIO cooler If you wish to install an AIO cooler, we recommend installing the AIO cooler after installing the motherboard into the chassis. AIO_PUMP CPU_FAN CPU_OPT PRIME X670E-P...

  • Page 40: Dimm Installation

    2.1.3 DIMM installation To remove a DIMM Chapter 2: Basic Installation...

  • Page 41: Installation

    1.25mm. • Use a Phillips screwdriver when removing or installing the screws or screw stands mentioned in this section. • The M.2 is purchased separately. Loosen the screws from the M.2 heatsink. Lift and remove the heatsink. PRIME X670E-P...
  • Page 42 Install your M.2 to your M.2 slot. The steps may differ between installing M.2 of different lengths, please refer to the different types and their installation steps below: • To install an M.2 to M.2_1 slot For 2280 length (optional) Install the bundled M.2 rubber pad if you are installing a single sided M.2 storage device.
  • Page 43 OPTIONAL PRIME X670E-P...
  • Page 44 • To install an M.2 to M.2_2 slot For 22110, 2280, 2260, 2242 length Install the bundled screw stand to the M.2 length screw hole you wish to install your M.2 to. Install your M.2 to the M.2 slot. Secure your M.2 using the bundled screw stand’s screw. Chapter 2: Basic Installation 2-10...
  • Page 45 For 2280, 2260, 2242 length Install the bundled screw stand to the M.2 length screw hole you wish to install your M.2 to. Install your M.2 to the M.2 slot. Secure your M.2 using the bundled screw stand’s screw. PRIME X670E-P 2-11...
  • Page 46 Chapter 2: Basic Installation 2-12...
  • Page 47 Remove the plastic film from the thermal pad on the bottom of the heatsink. If the thermal pad on the M.2 heatsink becomes damaged, we recommend replacing it with a thermal pad with a thickness of 1.25mm. Replace the heatsink. Secure the heatsink using the screws removed previously. PRIME X670E-P 2-13...

  • Page 48: Motherboard Installation

    2.1.5 Motherboard installation Install the ASUS I/O Shield to the chassis rear I/O panel. Some sharp edges and points might cause physical injury. We recommend you put on cut or puncture resistant gloves before motherboard and I/O shield installation. Place the motherboard into the chassis, ensuring that its rear I/O ports are aligned to the chassis’...
  • Page 49 Place nine (9) screws into the holes indicated by circles to secure the motherboard to the chassis. DO NOT over tighten the screws! Doing so can damage the motherboard. PRIME X670E-P 2-15...

  • Page 50: Atx Power Connection

    2.1.6 ATX power connection • DO NOT connect the 4-pin power plug only, the motherboard may overheat under heavy usage. • Ensure to connect the 8-pin power plug, or both the 8-pin and 4-pin power plugs. Chapter 2: Basic Installation 2-16...

  • Page 51: Sata Device Connection

    2.1.7 SATA device connection PRIME X670E-P 2-17...

  • Page 52: Front I/O Connector

    2.1.8 Front I/O connector To install front panel connector To install USB 3.2 Gen 1 Type-C ® connector USB 3.2 Gen 1 Type-C ® This connector will only fit in one orientation. Push the connector until it clicks into place. To install USB 2.0 connector To install USB 3.2 Gen 1 connector USB 2.0...

  • Page 53: Expansion Card Installation

    2.1.9 Expansion card installation To install PCIe x16 cards To install PCIe x1 card PRIME X670E-P 2-19...
  • Page 54 To install Thunderbolt™ series card 6-pin PCIe power connector USB Type-C ® port connects to Thunderbolt devices MiniDP in port connects to DP out port on the motherboard or a VGA card USB 2.0 header Thunderbolt™ (USB4 ) header ® The Thunderbolt™...

  • Page 55: Bios Update Utility

    • Updating BIOS may have risks. If the BIOS program is damaged during the process and results to the system’s failure to boot up, please contact your local ASUS Service Center. PRIME X670E-P...

  • Page 56: Motherboard Rear And Audio Connections

    For more information on using the BIOS FlashBack™ feature, please refer to https://www.asus.com/support/, or by scanning the QR code below. Motherboard rear and audio connections 2.3.1 Rear I/O connection Rear panel connectors PS/2 Keyboard/Mouse combo port DisplayPort USB 3.2 Gen 1 Type-A ports 2, 3, 4, and 23 USB 3.2 Gen 2 Type-A ports 20, 21, and 22...

  • Page 57: Audio I/O Connections

    Pink – – – – (Front panel) To configure a 7.1-channel audio output: Use a chassis with HD audio module in the front panel to support a 7.1-channel audio output. 2.3.2 Audio I/O connections Audio I/O ports PRIME X670E-P 2-23...
  • Page 58 Connect to Headphone and Mic Connect to 2-channel Speakers Connect to 4-channel Speakers Chapter 2: Basic Installation 2-24...
  • Page 59 Connect to 5.1-channel Speakers Connect to 7.1-channel Speakers PRIME X670E-P 2-25...

  • Page 60: Starting Up For The First Time

    Starting up for the first time After making all the connections, replace the system case cover. Ensure that all switches are off. Connect the power cord to the power connector at the back of the system chassis. Connect the power cord to a power outlet that is equipped with a surge protector. Turn on the devices in the following order: Monitor External storage devices (starting with the last device on the chain)

  • Page 61: Chapter 3: Bios And Raid Support

    Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 62: Bios Setup Program

    BIOS Setup program Use the BIOS Setup to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief onscreen help to guide you in using the BIOS Setup program. Entering BIOS at startup To enter BIOS Setup at startup, press <Delete> or <F2> during the Power-On Self Test (POST).

  • Page 63: Asus Ez Flash 3

    ASUS EZ Flash 3 The ASUS EZ Flash 3 feature allows you to update the BIOS without using an OS-based utility. Ensure to load the BIOS default settings to ensure system compatibility and stability. Select the Load Optimized Defaults item under the Exit menu or press hotkey <F5>.

  • Page 64: Asus Crashfree Bios 3

    ASUS CrashFree BIOS 3 The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using a USB flash drive that contains the BIOS file.

  • Page 65: Raid Configurations

    For more information on configuring your RAID sets, please refer to the RAID Configuration Guide which you can find at https://www.asus.com/support, or by scanning the QR code. RAID definitions Volume provides the ability to link-together storage from one or several disks, regardless of the size of the space on those disks.
  • Page 66 Chapter 3: BIOS and RAID Support...

  • Page 67: Appendix
