Summary of Contents for Asus TUF X470-PLUS GAMING

  • Page 1 TUF X470-PLUS GAMING...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ....................... v About this guide ......................vi TUF X470-PLUS GAMING specifications summary ..........viii Package contents ...................... xii Installation tools and components ................. xiii Chapter 1: Product Introduction Motherboard overview ................1-1 1.1.1 Before you proceed ..............1-1 1.1.2...
  • Page 4 3.6.10 USB Configuration ..............3-15 Monitor menu ................... 3-16 Boot menu ....................3-16 Tool menu ....................3-17 3.9.1 ASUS EZ Flash 3 Utility ............3-17 3.9.2 ASUS User Profile..............3-18 3.9.3 ASUS SPD Information ............. 3-18 3.10 Exit menu ....................3-18 3.11...

  • Page 5: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 6: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website (www.asus.com) provides updated information on ASUS hardware and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.
  • Page 7 Conventions used in this guide To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task.

  • Page 8: Tuf X470-Plus Gaming Specifications Summary

    - 4 x DIMM, max. 64GB, DDR4 2400/ 2133 MHz, un-buffered memory Dual channel memory architecture * Hyper DIMM support is subject to the physical characteristics of individual CPUs. ** Refer to www.asus.com for the Memory QVL (Qualified Vendors List). AMD Ryzen™ 2 Generation/ Ryzen™ 1 Generation Processors 1 x PCIe 3.0 x16 slot (max.
  • Page 9 - 6 x USB 2.0 ports at mid-board (2 ports at back panel,4 ports at mid-board) Dependable Stability ASUS TUF PROTECTION - ASUS SafeSlot - Protect your graphics card Investment - ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges! - ASUS Overvoltage Protection: World-class circuit-protecting...
  • Page 10 TUF X470-PLUS GAMING specifications summary Easy PC DIY Safe motherboard mounting - Component-free areas to minimize damage risk Q-Design - ASUS Q-Slot ASUS Unique Features - ASUS Q-DIMM ASUS Exclusive Features - featuring a friendly graphics user interface - ASUS CrashFree BIOS 3...
  • Page 11 1 x S/PDIF out connector 1 x Clear CMOS jumper (2-pin) 256 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.0, ACPI 6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Q-fan Control, F3 My Favorites, Last Modified log, F12 BIOS...

  • Page 12: Package Contents

    Package contents Check your motherboard package for the following items. Motherboard TUF X470-PLUS GAMING Cables 2 x SATA 6 Gb/s cables 1 x I/O shield 1 x M.2 screw package Accessories 1 x TUF Gaming Sticker 1 x TUF Certification card...

  • Page 13: Installation Tools And Components

    Installation tools and components 1 Bag of screws Phillips (cross) screwdriver PC chassis Power supply unit AMD AM4 CPU AMD AM4/AM3 compatible CPU Fan DDR4 DIMM SATA hard disk drive SATA optical disc drive (optional) Graphics card (optional) The tools and components in the table above are not included in the motherboard package. xiii...

  • Page 15: Chapter 1: Product Introduction

    Chapter 1: Product Introduction Product Introduction Motherboard overview 1.1.1 Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity. • Hold components by the edges to avoid touching the ICs on them. • Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component. • Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. ASUS TUF X470-PLUS GAMING...

  • Page 16: Motherboard Layout

    1.1.2 Motherboard layout 24.4cm(9.6in) KBMS_910 EATX12V DIGI CHA_FAN2 +VRM CPU_FAN U31G1_C7 HDMI U31G2_12 LAN_U31G1_56 AUDIO 22110 2280 2260 2242 PCIEX16_1 ® 8111H ® X470 BATTERY PCIEX1_1 Super CHA_FAN3 PCIEX16_2 M.2_2(SOCKET3) PCIEX1_2 2280 2260 2242 SATA6G_4 SATA6G_3 PCIEX1_3 CLRTC SATA6G_2 SATA6G_1 U31G1_12 USB1314 USB1112...
  • Page 17 Layout contents Connectors/Jumpers/Buttons and switches/Slots Page ATX power connectors (24-pin EATXPWR; 8-pin EATX12V) 1-14 CPU and chassis fan connectors; AIO pump connector (4-pin CPU_FAN, 1-13 4-pin CHA_FAN1-3; 4-pin AIO_PUMP) AM4 CPU socket DDR4 DIMM slots AURA RGB header (4-pin RGB_HEADER) 1-16 USB 3.1 Gen 1 connectors (20-1 pin U31G1_12, U31G1_34) 1-11 M.2 Socket 3 1-15 AMD Serial ATA 6 Gb/s connectors (7-pin SATA6G_1-6) 1-10 System panel connectors (20-5 pin PANEL) 1-12 10. USB 2.0 connectors (10-1 pin USB1112, USB1314) 1-11 11. Clear RTC RAM jumper (2-pin CLRTC) 12. Serial port connector (10-1 pin COM) 1-14 13. Digital audio connector (4-1 pin SPDIF_OUT) 14. Front panel audio connector (10-1 pin AAFP) ASUS TUF X470-PLUS GAMING...

  • Page 18: Central Processing Unit (Cpu)

    1.1.3 Central Processing Unit (CPU) The motherboard comes with an AM4 socket designed for AMD Ryzen™ 2 Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1 Generation/ 7th Generation A-Series/ Athlon X4 processors. ® TUF X470-PLUS GAMING CPU socket AM4 The AM4 socket has a different pinout design. Ensure that you use a CPU designed for the AM4 socket. The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU! Ensure that all power cables are unplugged before installing the CPU. 1.1.4 System memory The motherboard comes with four Double Data Rate 4 (DDR4) Dual Inline Memory Modules (DIMM) slots. A DDR4 module is notched differently from a DDR, DDR2, or DDR3 module. DO NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot. ® TUF X470-PLUS GAMING 288-pin DDR4 DIMM sockets Chapter 1: Product Introduction...
  • Page 19 Recommended memory configurations DIMM_A1 DIMM_A2* DIMM_A2* DIMM_A2* DIMM_B1 DIMM_B2* DIMM_B2* Memory configurations You may install 2 GB, 4 GB, 8 GB, and 16 GB unbuffered DDR4 DIMMs into the DIMM sockets. • You may install varying memory sizes in Channel A and Channel B. The system maps the total size of the lower-sized channel for the dual-channel configuration. Any excess memory from the higher-sized channel is then mapped for single-channel operation. • This motherboard does not support DIMMs made up of 512 Mb (64 MB) chips or less (Memory chip capacity counts in Megabit, 8 Megabit/Mb = 1 Megabyte/MB). • The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value. • For system stability, use a more efficient memory cooling system to support a full memory load (4 DIMMs) or overclocking condition. • Always install the DIMMS with the same CAS Latency. For an optimum compatibility, we recommend that you install memory modules of the same version or data code (D/C) from the same vendor. Check with the vendor to get the correct memory modules. ASUS TUF X470-PLUS GAMING...

  • Page 20: Expansion Slots

    1.1.5 Expansion slots Unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. PCIEX16_1 ® PCIEX1_1 PCIEX16_2 PCIEX1_2 PCIEX1_3 Slot No. Slot Description PCIe 3.0 x16_1 slot PCIe 2.0 x1_1 slot PCIe 2.0 x16_2 slot PCIe 2.0 x1_2 slot PCIe 2.0 x1_3 slot Chapter 1: Product Introduction...
  • Page 21 PCIe 3.0 x16_1 PCIe 2.0 x16_2 Single VGA/PCIe card Dual VGA/PCIe card AMD Ryzen™ with Radeon™ Vega Graphics/ 7th Generation A-Series/ Athlon X4 Processors PCIe operating mode VGA Configuration PCIe 3.0 x16_1 PCIe 2.0 x16_2 Single VGA/PCIe card Dual VGA/PCIe card • We recommend that you provide sufficient power when running CrossFireX™ mode. • Connect chassis fans to the motherboard chassis fan connectors when using multiple graphics cards for better thermal environment. ASUS TUF X470-PLUS GAMING...

  • Page 22: Jumpers

    1.1.6 Jumpers Clear RTC RAM jumper (2-pin CLRTC) This jumper allows you to clear the CMOS RTC RAM data of the system setup information such as date, time, and system passwords. ® CLRTC PIN 1 TUF X470-PLUS GAMING Clear RTC RAM To erase the RTC RAM: Turn OFF the computer and unplug the power cord. Use a metal object such as a screwdriver to short the two pins. Plug the power cord and turn ON the computer. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter data. If the steps above do not help, remove the onboard battery and short the two pins again to clear the CMOS RTC RAM data. After clearing the CMOS, reinstall the battery. Chapter 1: Product Introduction...

  • Page 23: Internal Connectors

    1.1.7 Internal connectors Front panel audio connector (10-1 pin AAFP) This connector is for a chassis-mounted front panel audio I/O module that supports HD Audio. Connect one end of the front panel audio I/O module cable to this connector. AAFP ® HD-audio-compliant pin definition TUF X470-PLUS GAMING Front panel connector We recommend that you connect a high-definition front panel audio module to this connector to avail of the motherboard’s high-definition audio capability. Digital audio connector (4-1 pin SPDIF_OUT) This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port. Connect the S/PDIF Out module cable to this connector, then install the module to a slot opening at the back of the system chassis. ® SPDIF_OUT TUF X470-PLUS GAMING Digital audio connector The S/PDIF module is purchased separately.
  • Page 24 If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID 1, and RAID 10 configuration through the onboard AMD X470 chipset. SATA6G_5 RSATA_TXP5 RSATA_TXN5 RSATA_RXN5 RSATA_RXP5 SATA6G_6 RSATA_TXP6 RSATA_TXN6 RSATA_RXN6 RSATA_RXP6 SATA6G_4 SATA6G_3 ® SATA6G_2 SATA6G_1 TUF X470-PLUS GAMING SATA 6 Gb/s connectors • These connectors are set to [AHCI] by default. If you intend to create a Serial ATA RAID set using these connectors, set the SATA Mode Selection item in the BIOS to [RAID]. • Before creating a RAID set, refer to section RAID configurations or the manual bundled in the motherboard support DVD. • When using NCQ, set the SATA Mode in the BIOS to [AHCI]. Refer to section SATA Configuration for details. Chapter 1: Product Introduction 1-10...
  • Page 25 5 Gb/s, faster charging time for USB-chargeable devices, optimized power efficiency, and backward compatibility with USB 2.0. U31G1_34 U31G1_12 PIN 1 Vbus Vbus IntA_P1_SSRX- IntA_P2_SSRX- IntA_P1_SSRX+ IntA_P2_SSRX+ IntA_P1_SSTX- PIN 1 IntA_P2_SSTX- IntA_P1_SSTX+ IntA_P2_SSTX+ ® IntA_P1_D- IntA_P2_D- IntA_P1_D+ IntA_P2_D+ TUF X470-PLUS GAMING USB 3.1 Gen 1 connectors The USB 3.1 Gen 1 module is purchased separately. The plugged USB 3.1 Gen 1 device may run on xHCI or EHCI mode depending on the operating system’s setting. ASUS TUF X470-PLUS GAMING 1-11...
  • Page 26 SPEAKER PWR_SW PIN 1 ® +HDD_LED- RESET +PWR_LED- * Requires an ATX power supply TUF X470-PLUS GAMING System panel connector • System power LED (2-pin or 3-1 pin PLED) The 2-pin or 3-1 pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. • Hard disk drive activity LED (2-pin HDD_LED) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable...
  • Page 27 CHA FAN PWM CHA_FAN3 AIO_PUMP ® CHA FAN PWM AIO PUMP PWR CHA FAN IN AIO PUMP IN CHA FAN PWR AIO PUMP PWM TUF X470-PLUS GAMING Fan connectors • DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan connectors! • Ensure to fully insert the 4-pin CPU fan cable to the CPU fan connector. Connect the pump cable from the all-in-one cooler (AIO cooler) to the AIO_PUMP header, and connect the fan cable to the CPU fan connector. Header Max. Current Max.
  • Page 28 Power OK -5 Volts PIN 1 +5 Volts +5 Volts PSON# -12 Volts +3 Volts ® +3 Volts +3 Volts PIN 1 TUF X470-PLUS GAMING ATX power connectors • For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12 V Specification 2.0 (or later version) and provides a minimum power of 350 W. • Do not forget to connect the 8-pin EATX12 V power plug. Otherwise, the system will not boot. • We recommend that you use a PSU with a higher power output when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. •...
  • Page 29 M.2 sockets (M.2_1; M.2_2) These sockets allow you to install M.2 SSD modules. M.2_1(SOCKET3) 22110 2280 2260 2242 M.2_2(SOCKET3) ® 2280 2260 2242 TUF X470-PLUS GAMING M.2 sockets • AMD Ryzen™ 2 Generation/ Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ 1 Generation Processors, the M.2_1 socket supports PCIe 3.0 x4 mode and SATA mode M Key design and type 2242 / 2260 / 2280 / 22110 storage devices. • AMD 7th Generation A-Series/ Athlon X4 Processors, the M.2_1 socket supports SATA mode M Key design and type 2242 / 2260 / 2280 / 22110 storage devices. • The M.2_2 socket supports PCIe 3.0 x2 mode and SATA mode M Key design and type 2242/ 2260/ 2280 storage devices. The M.2 SSD module is purchased separately. Processors 7th Generation Ryzen™ with Ryzen™ Ryzen™ 2 A-Series/ Radeon™...
  • Page 30 AURA RGB header (4-pin RGB_HEADER) This connector is for RGB LED strips. RGB_HEADER +12V PIN 1 ® TUF X470-PLUS GAMING RGB Header The RGB header supports 5050 RGB multi-color LED strips (12V/G/R/B), with a maximum power rating of 3A (12V), and no longer than 3 m. Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. • Actual lighting and color will vary with LED strip. • If your LED strip does not light up, check if the RGB LED extension cable and the RGB LED strip is connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard. • The LED strip will only light up when the system is operating. • The LED strip is purchased separately. Chapter 1: Product Introduction 1-16...

  • Page 31: Chapter 2: Basic Installation

    2.1.1 Motherboard installation Install the ASUS I/O Shield to the chassis rear I/O panel. Place the motherboard into the chassis, ensuring that its rear I/O ports are aligned to the chassis’ rear I/O panel.
  • Page 32 Place eight (8) screws into the holes indicated by circles to secure the motherboard to the chassis. ® DO NOT over tighten the screws! Doing so can damage the motherboard. Chapter 2: Basic Installation...

  • Page 33: Cpu Installation

    The AMD AM4 socket is compatible with AMD AM4 processors. Ensure you use a CPU designed for the AM4 socket. The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU! ASUS TUF X470-PLUS GAMING...

  • Page 34: Cpu Heatsink And Fan Assembly Installation

    2.1.3 CPU heatsink and fan assembly installation Apply the Thermal Interface Material to the CPU heatsink and CPU before you install the heatsink and fan if necessary. Type 1 Chapter 2: Basic Installation...
  • Page 35 Type 2 When using this type of CPU fan, remove the screws and the retention module only. Do not remove the plate on the bottom. ASUS TUF X470-PLUS GAMING...

  • Page 36: Dimm Installation

    2.1.4 DIMM installation To remove a DIMM Chapter 2: Basic Installation...

  • Page 37: Atx Power Connection

    2.1.5 ATX power connection Ensure to connect the 8-pin power plug. 2.1.6 SATA device connection ASUS TUF X470-PLUS GAMING...

  • Page 38: Front I/O Connector

    2.1.7 Front I/O connector To install the front panel connector To install front panel audio connector AAFP To install USB 3.1 Gen 1 connector To install USB 2.0 connector USB 3.1 Gen 1 USB 2.0 Chapter 2: Basic Installation...

  • Page 39: Expansion Card Installation

    2.1.8 Expansion card installation To install PCIe x16 cards To install PCIe x1 cards ASUS TUF X470-PLUS GAMING...

  • Page 40: Installation

    2.1.9 M.2 installation Supported M.2 type varies per motherboard. Chapter 2: Basic Installation 2-10...

  • Page 41: Motherboard Rear And Audio Connections

    2.0 and USB 3.1 Gen 1 / Gen 2 ports are controlled by the xHCI controller. • We strongly recommend that you connect USB 3.1 Gen 2 devices to USB 3.1 Gen 2 ports for faster and better performance from your USB 3.1 Gen 2 devices. ASUS TUF X470-PLUS GAMING 2-11...

  • Page 42: Audio I/O Connections

    * LAN ports LED indications ACT/LINK SPEED Activity Link LED Speed LED Status Description Status Description No link 10 Mbps connection Orange Linked Orange 100 Mbps connection LAN port Orange (Blinking) Data activity Green 1 Gbps connection Orange (Blinking Ready to wake up then steady) from S5 mode ** Audio 2, 4, 6 or 8-channel configuration...
  • Page 43 Connect to Stereo Speakers Connect to 2.1 channel Speakers Connect to 4.1 channel Speakers ASUS TUF X470-PLUS GAMING 2-13...
  • Page 44 Connect to 5.1 channel Speakers Use only the light blue audio port for Side Speaker Out in a 5.1 channel configuration. Connect to 7.1 channel Speakers Chapter 2: Basic Installation 2-14...

  • Page 45: Starting Up For The First Time

    While the system is ON, press the power button for less than four seconds to put the system on sleep mode or soft-off mode, depending on the BIOS setting. Press the power button for more than four seconds to let the system enter the soft-off mode regardless of the BIOS setting. ASUS TUF X470-PLUS GAMING 2-15...
  • Page 46 Chapter 2: Basic Installation 2-16...

  • Page 47: Chapter 3: Bios Setup

    BIOS Setup Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 48: Bios Setup Program

    RTC RAM via the Clear CMOS button. • The BIOS setup program does not support the Bluetooth devices. Please visit ASUS website for the detailed BIOS content manual. BIOS menu screen The BIOS Setup program can be used under two modes: EZ Mode and Advanced Mode.

  • Page 49: Ez Mode

    Click to go to Advanced mode Loads optimized Search on the FAQ default settings Click to display boot devices Selects the boot device priority The boot device options vary depending on the devices you installed to the system. ASUS TUF X470-PLUS GAMING...

  • Page 50: Advanced Mode

    3.2.2 Advanced Mode The Advanced Mode provides advanced options for experienced end-users to configure the BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. To switch from EZ Mode to Advanced Mode, click Advanced Mode(F7) or press the <F7> hotkey.
  • Page 51 Refer to section 3.2.3 QFan Control for more information. Search (F9) This button allows you to search by BIOS item name, enter the item name to find the related item listing. ASUS TUF X470-PLUS GAMING...
  • Page 52 Move your mouse over this button to show a QR code, scan this QR code on your mobile device to connect to the BIOS FAQ web page of the ASUS support website. You can also scan the following QR code: Hot keys This button above the menu bar contains the navigation keys for the BIOS setup program.

  • Page 53: Q-Fan Control

    Click to activate DC Mode configured PWM Mode Select a profile to Click to apply the fan setting apply to your fans Click to undo the Click to go back to main menu changes Select to manually configure your fans ASUS TUF X470-PLUS GAMING...
  • Page 54 Configuring fans manually Select Manual from the list of profiles to manually configure your fans’ operating speed. Speed points Select to manually configure your fans To configure your fans: Select the fan that you want to configure and to view its current status. Click and drag the speed points to adjust the fans’...

  • Page 55: My Favorites

    My Favorites is your personal space where you can easily save and access your favorite BIOS items. My Favorites comes with several performance, power saving, and fast boot related items by default. You can personalize this screen by adding or removing items. ASUS TUF X470-PLUS GAMING...
  • Page 56 Adding items to My Favorites To add BIOS items: Press <F3> on your keyboard or click from the BIOS screen to open Setup Tree Map screen. On the Setup Tree Map screen, select the BIOS items that you want to save in My Favorites screen.

  • Page 57: Main Menu

    EPU Power Saving Mode The ASUS EPU (Energy Processing Unit) sets the CPU in its minimum power consumption settings. Enable this item to set lower CPU core/cache voltage and achieve the best energy saving condition. Configuration options: [Disabled] [Enabled]...

  • Page 58: Advanced Menu

    OC Tuner The OC tuner automatically overclocks the CPU and DRAM frequencies and voltages respectively to enhance the system performance. It also boosts the CPU graphics performance according to the CPU graphics loading. Configuration options: [Keep Current Settings] [OC Tuner] To keep the current overclocking tuner status, select [Keep Current Settings].

  • Page 59: Sata Configuration

    SATA6G_1~6 (Gray), M.2_1 (Gray), M.2_2 (Gray) Select one item and click Enter to assign a new name for the item. Hot Plug These items allow you to enable/disable SATA Hot Plug Support. Configuration options: [Disabled] [Enabled] ASUS TUF X470-PLUS GAMING 3-13...

  • Page 60: Onboard Devices Configuration

    3.6.5 Onboard Devices Configuration The items in this menu allow you to switch between PCIe Lanes and configure onboard devices. HD Audio Controller This item allows you to use the Azalia High Definition Audio Controller. Configuration options: [Disabled] [Enabled] PCIEX16_1 Bandwidth This item displays on AMD Ryzen™...

  • Page 61: Pci Subsytem Settings

    The Mass Storage Devices item shows the auto-detected values. If no USB device is detected, the item shows None. USB Single Port Control This item allows you to enable or disable the individual USB ports. Refer to section 1.1.2 Motherboard layout for the location of the USB ports. ASUS TUF X470-PLUS GAMING 3-15...

  • Page 62: Monitor Menu

    Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings. Q-Fan Configuration The subitems in this menu allow you to configure the Q-Fan features. Qfan Tuning Click this item to automatically detect the lowest speed and configure the minimum duty cycle for each fan.

  • Page 63: Tool Menu

    3.9.1 ASUS EZ Flash 3 Utility This item allows you to run ASUS EZ Flash 3. When you press <Enter>, a confirmation message appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to confirm your choice.

  • Page 64: Asus User Profile

    3.9.2 ASUS User Profile This item allows you to store or load multiple BIOS settings. Load from Profile This item allows you to load the previous BIOS settings saved in the BIOS Flash. Key in the profile number that saved your BIOS settings, press <Enter>, and then select Yes.

  • Page 65: Updating Bios

    ® ASUS EZ Flash 3: Updates the BIOS using a USB flash drive. ASUS CrashFree BIOS 3: Restores the BIOS using the motherboard support DVD or a USB flash drive when the BIOS file fails or gets corrupted. 3.11.1...

  • Page 66: Asus Ez Flash 3

    3.11.2 ASUS EZ Flash 3 ASUS EZ Flash 3 allows you to download and update to the latest BIOS through the Internet without having to use a bootable floppy disk or an OS-based utility. Updating through the Internet varies per region and Internet conditions. Check your local Internet connection before updating through the Internet.
  • Page 67 To update the BIOS by Internet: Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select ASUS EZ Flash Utility and press <Enter>. Select via Internet. Press the Left/Right arrow keys to select an Internet connection method, and then press <Enter>.

  • Page 68: Asus Crashfree Bios 3

    The BIOS file in the motherboard support DVD may be older than the BIOS file published on the ASUS official website. If you want to use the newer BIOS file, download the file at https://www.asus.com/support/ and save it to a USB flash drive.

  • Page 69: Chapter 4: Raid Support

    The motherboard comes with the RaidXpert2 Configuration Utility that supports Volume, RAIDABLE, RAID 0, RAID 1, and RAID 10 (depends on system licensing) configurations. For more information on configuring your RAID sets, please refer to the RAID Configuration Guide which you can find at https://www.asus.com/support. 4.1.1 RAID definitions Volume provides the ability to link-together storage from one or several disks, regardless of the size of the space on those disks.

  • Page 70: Appendix

    Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. ASUS TUF X470-PLUS GAMING...
  • Page 71 Compliance Statement of Innovation, Science and Economic Development Canada (ISED) This device complies with Innovation, Science and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 72 ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
  • Page 73 доступний на: www.asus.com/support Cijeli tekst EU izjave o sukladnosti dostupan je na: www.asus.com/support Türkçe AsusTek Computer Inc., bu aygıtın temel gereksinimlerle ve ilişkili Čeština Společnost ASUSTeK Computer Inc. tímto prohlašuje, že toto Yönergelerin diğer ilgili koşullarıyla uyumlu olduğunu beyan eder.

  • Page 74: Asus Contact Information

    +1-510-739-3777 +1-510-608-4555 Web site http://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 Telephone +1-812-282-2787 Online support http://qr.asus.com/techserv ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, 40880 Ratingen, Germany +49-2102-959931 Web site http://www.asus.com/de Online contact http://eu-rma.asus.com/sales Technical Support Telephone +49-2102-5789555 Support Fax...
  • Page 75 CA 94539. Phone/Fax No: (510)739-3777/(510)608-4555 hereby declares that the product Product Name : Motherboard Model Number : TUF X470-PLUS GAMING Conforms to the following specifications: FCC Part 15, Subpart B, Unintentional Radiators Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is subject to the...
