Furniture of America CM3195PC-2PK Assembly Instructions

Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3195PC-2PK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
Page 1 of 5
(Included)
(Not Included)
Rev: 19-01-28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CM3195PC-2PK and is the answer not in the manual?

Questions and answers

Related Manuals for Furniture of America CM3195PC-2PK

Summary of Contents for Furniture of America CM3195PC-2PK

  • Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3195PC-2PK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
  • Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
  • Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc x 2 #A x 4pcs x 2 Chair Back Bolt Ø1/4" x 3" #2 x 1pc x 2 #B x 4pcs x 2 Chair Seat...
  • Page 4 Align chair seat (#2) to chair back (#1), then secure by using bolts (#C) with washers (#D,E). #C x 2pcs #D x 2pcs #E x 2pcs DO NOT FULLY TIGHTEN ALL BOLTS UNTIL FULL ASSEMBLY IS COMPLETED. Secure corner holes of the seat (#2) to chair back (#1) by using bolts (#A) with washers (#D,E).
  • Page 5 Align legs (#3R/L) and stretchers (#4R/L,5) to each other as shown in the diagram, then secure legs (#3R/L) to seat (#2) by using bolts (#B) with washers (#D,E). #B x 4pcs #D x 4pcs #E x 4pcs Secure all stretchers to legs by using screws (#F). #F x 6pcs Page 5 of 5...
