CM3 413 PC -2PK / CM3194PC-2PK
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 5
(Included)
(Not Included)
Rev:18- 12 - 20
Advertisement
Related Manuals for Furniture of America CM3413PC-2PK
Summary of Contents for Furniture of America CM3413PC-2PK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3 413 PC -2PK / CM3194PC-2PK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc x2 #A x 4pcs x 2 Bolt Ø1/4" x 3 -1/8 " Chair Back #2 x 1pc x2 #B x 4pcs x 2 Bolt Ø1/4"...
- Page 4 Prepare 2 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#C). Align cushion frame (#2) to the holes of the chair back (#1). Secure holes of the cushion frame (#2) to the chair back (#1) by using bolts (#C).
- Page 5 Prepare 4 bolts assembly by inserting lock washer (#D), then flat washer (#E) onto bolts (#B). Align and secure front legs (#3R/L) to the bench by using bolts (#B). Align side stretchers (#5R/L) and front stretchers (#4) to the gaps of the legs. Fully tighten bolts (#B) on the front legs (#3R/L). #B x 4pcs #D x 4pcs #E x 4pcs...
