Furniture of America CM3195BN Assembly Instructions

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM3195BN

DIFFICULT

Tools Required For Assembly:

Allen Wrench

Phillips Screwdriver

2 PERSONS RECOMMENDED

Page 1 of 5

(Included)

(Not Included)

Rev: 19-01-28

Table of Contents

Do you have a question about the CM3195BN and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3195BN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Top Panel Bolt Ø5/16" x 2-1/2" #2 x 2pcs #B x 12pcs Bolt Ø5/16"...
Page 4 Align top and bottom stretchers (#4,3) to the holes of the legs (#2), then secure by using bolts (#A) with washers (#C). #A x 8pcs #C x 8pcs Align mounting plates (#5) to the legs (#2), then secure by using bolts (#B) with washers (#C). #B x 4pcs #C x 4pcs Page 4 of 5...
Page 5 Align mounting plates (#5) on the legs (#2) to the top panel (#1), then secure by using bolts (#B) with washers (#C,D). #B x 8pcs #C x 8pcs #D x 8pcs Secure top stretcher (#4) to the top panel (#1) by using screws (#F).
