Furniture of America CM3197T Assembly Instructions

For more information contact our team: service.ec@foagroup.com

CM3197T

ASSEMBLY RATING

Tools Required For Assembly:

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

Wrench

easy and 5 being difficult). For some

(Included)

products, two persons are recommended.

DIFFICULT

EASY

2 PERSONS RECOMMENDED

Page 1 of 5

Rev: 18-07-28

Table of Contents

Do you have a question about the CM3197T and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3197T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Wrench easy and 5 being difficult). For some (Included) products, two persons are recommended.
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 12pcs Bolt Ø5/16"x2-1/2" Table Top #2 x 4pcs #B x 12pcs Lock Washer Ø5/16"...
Page 4 Align legs (#2) to the table top (#1), then secure by using bolts (#A) with washers (#B,C). #A x 8pcs #B x 8pcs #C x 8pcs Align shelf (#3) to the legs (#2), then secure by using bolts (#A) with washers (#B,C). #A x 4pcs #B x 4pcs #C x 4pcs...
Page 5 Push tabs back on the bottom of table top (#1) to unfold table. ASSEMBLY IS COMPLETED Page 5 of 5...
