- Page 1 DO NOT RETURN TO RETAILER IF YOU HAVE ANY QUESTIONS OR CONCERNS PLEASE VISIT OUR WEBSITE AT: www.sunjoyonline.com OR TOLL FREE AT: 1-866-578-6569 8:00 AM EST to 8:00 PM PST OR EMAIL AT customersupport@sunjoygroup.com Production Number：2021300015...
- Page 2 ASSEMBLY INSTRUCTIONS ITEM# A101001910 SKU#236828 SHELTON 10’x12’ GAZEBO...
-
Page 3: Safety Information
Safety Information Please read and understand this entire manual before attempting to assemble or install the product. When installing and assembling the item, it is recommended two or more adults are involved • This product is intended for outdoor use only and should be placed on flat, horizontal ground •... -
Page 4: Parts List
Parts List Large Panel P00630000401 Left Panel P00630009401 Right Panel P00630010401 Long Cross Beam P00500035201 Short Cross Beam P00500035301 Long Netting Rod P00570001801 Short Netting Rod P00570035201 Corner Netting Rod P00570035301 Big Roof Connector P00050025501 Connector P00050025601 Top Oblique Beam1 P00060203801 Top Oblique Beam2 P00060203901... -
Page 5: Hardware Pack
Hardware Pack H010010010 M6×25mm screw 16pieces H010010087 M6×20mm screw 20pieces H010110016 M6x15 Screw 20 pieces H050030001 M6 washer 56pieces H070010003 Stake 8 pieces P005100264 Plastic ring 52PCS H090010017 M6 Wrench 1 pieces Spare Hardware Pack H010010010 M6×25mm screw 2pieces H010010087 M6×20mm screw 4pieces H050030001... - Page 6 Fig1-1、Fig1-2：Insert the pin on the left panel (B1) into the large panel (A), pull down the left panel (B1) to fix with t he large panel (A) as Fig.1-2, then connect B1 & A by using bolt (AA) and washer (CC). Connect the right panel (B2) to the large panel (A) in same way.
- Page 7 Fig2-1. Screw the hook (J) to the top center connector (E). ； Fig2-2. Insert the small top support bar (F) to the top center connector (E). Please note the parts label under the top center connector (E). Please noted the direction of the top center connector (E), the parts label “H2” face the long Cross beam (C1), and label “H1”...
- Page 8 Place the large canopy (K1) onto the big top. Please do not spread it here. Fig.3-1. Fig.3-2. Place the small Canopy (K2) to the small top along the small top support bar (F), aligning the corners and stretching it to fit. Tie the small canopy and large canopy together. Position the Gazebo and tighten all the screws using a (WW).
- Page 9 IMPORTANT: 1. When assembling and using this product, basic safety precautions should always be followed to reduce the risk of personal injury and damage to equipment. Please read all instructions before assembly and use. 2. Some parts may contain sharp edges, wear protective gloves if necessary. At least five or more people are recommended for safe assembly.
