- Page 1 DO NOT RETURN TO RETAILER IF YOU HAVE ANY QUESTIONS OR CONCERNS PLEASE VISIT OUR WEBSITE AT: www.sunjoyonline.com OR TOLL FREE AT: 1-866-578-6569 8:00 AM EST to 8:00 PM PST OR EMAIL AT customersupport@sunjoygroup.com Production Number：2021200007...
- Page 2 ASSEMBLY INS TRUCTIONS ITEM# A101002600 SKU#236830 OXFORD 10’x12’ GAZEBO...
-
Page 3: Safety Information
Safety Information Please read and understand this entire manual before attempting to assemble or install the product. When installing and assembling the item, it is recommended two or more adults are involved • This product is intended for outdoor use only and should be placed on flat, horizontal ground •... -
Page 4: Parts List
Parts List P00020039801 Post P00010029801 Post Base P00610015401 Base Protector P00040114101 Short Beam (1) P00040114201 Short Beam (2) P00040114301 Long Beam (1) P00040114401 Long Beam (2) Slanting Bar P00050025201 Connector P00500035101 Support Bar P00060203301 Big Top Bar P00060203401 Connect Bar P00060203501 Short Side Bar Long Side Bar... -
Page 5: Hardware Pack
Hardware Pack 1 H010110016 M6X15 bolt 8PCS H050030001 M6 flat washer 64PCS H010010003 M6X15 bolt 40PCS H010010004 M6X35 bolt 16PCS H090010017 M6 wrench 1 PC Fig.1: Fit the Base protector (C) onto the Post (A), connect the Post base (B) and post (A) by using bolt (AA) and flat washer (BB). - Page 6 Fig.4: Attach Netting bar N (M) to Beam D (E, F, G) by using bolt (CC) and washer (BB). Fig.5: Fix Support bar (I) to Beam G (D, E, F) and Post (A) by using bolt (CC) and washer (BB). Hardware Pack 2 H050030001 M6 flat washer...
- Page 7 Fig.6: Insert the Connect bar (J2) to the big top bar (J1), fix them by using bolt (CC) and washer (BB). Fig.6-1: Insert Big top bar (J1) to Big top connector (O), screw Pothook (P) to Big top connector (O). Fig.7: Attach the Connect bar (J2) to the post (A) by using screw (EE), washer (BB) and nut...
- Page 8 Fig.12: Hang Mosquito netting (V) to netting bar N (M) by using Plastic ring (HH). Fig.13: Hang Wall (U) to beam (F, D, E, G) by using Plastic ring (II). Fig.14: Lift Base protector (C), fix assembled gazebo with Peg (GG). Now, your Gazebo is ready for use.
