HDO 10 x 12 Gazebo
Model No.: A101005603
Model UPC: 041226176452
Quality Guaranteed:
If you are not completely satisfied with this product, return it
for refund or replacement.
Comments or questions? 800-697-2448
www.interamericanproducts.com
Distributed by Inter-American Products, Cincinnati, OH 45202
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sunjoy A101005603
Summary of Contents for Sunjoy A101005603
- Page 1 HDO 10 x 12 Gazebo Model No.: A101005603 Model UPC: 041226176452 Quality Guaranteed: If you are not completely satisfied with this product, return it for refund or replacement. Comments or questions? 800-697-2448 www.interamericanproducts.com Distributed by Inter-American Products, Cincinnati, OH 45202...
- Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY • Please read and understand this entire manual before attempting to assemble or install the product. • Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. • The assembled gazebo should be located at least 6 feet from any obstruction such as fence, garage, house, overhanging branches, laundry lines or electrical wires. • Some parts may contain sharp edges. Wear protective gloves if necessary, during assembly. • Check all nuts and bolts periodically for tightness and, when required, tighten them again. • Pay attention to the parts orientation. WARNINGS • Install the gazebo on level ground. Stakes are provided to secure the gazebo to the ground. • Do not assemble the gazebo on sandy, muddy or loose soil, as stakes do not have enough anchorage in these types of soil. • If you wish to secure the gazebo to a wood deck or concrete surface, use anchors suited to these surfaces. • Snow must be cleared off regularly during snowy days. • Do not leave the gazebo where there is a risk of high wind, as possible damage will occur to the structure. • Any assembly or maintenance of the product must be carried out by adults only. • Please check your state and local regulations prior to purchasing. Some jurisdictions may require permits for installation and use. Some special procedures may be valid in your area. • If any scratch paint, please touch up to prevent rusting. • For outdoor use only. WARNING KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC THIS TENT IS MADE WITH FLAME RESISTANT FABRIC WHICH MEETS CPAI-84 SPECIFICATIONS.
-
Page 3: Maintenance
MAINTENANCE • Steel components for this gazebo are treated with rust inhibiting paint that protects it from rusting. However, due to the nature of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is not a defect and thus not covered by the warranty. • To minimize this condition, it is recommended to use care when assembling and handling the product to prevent scratching the paint. Should any scratching or damage occur, it is recommended to cover the scratch immediately with rust inhibiting paint (not included). • Surface rust can also be easily removed with a very light application of regular cooking oil or WD‐40. If surface oxidation (rusting) occurs and if no measure is taken to prevent this, the oxidation may start dripping onto deck or patio and caused damaging stains, which may be difficult to remove. This can be prevented if the above‐mentioned measures are taken to keep the product from oxidizing. • Do not use bleach, acid, or other abrasive cleaners on the roof or frame parts. • Keep instruction manual for future reference. • Keep the original packaging to store the gazebo. • Periodically check and ensure that all bolts are well‐tighten during use. Tools Recommended (Not Included) Included ... -
Page 4: Exploded Drawing
Exploded Drawing ... -
Page 5: Parts List
Parts List Label Part Number Description Qty Part Image A P00020072801 Post 4 C P006100069 Base Cover 4 D P000100106 Post Base 4 E1 P000401043 Long Screen (Left) 2 Long Screen E2 P000401044 2 (Right) F1 P000401045 Short Screen (Left) 2 Short Screen ... - Page 6 M P000500473 Small Connector 1 Rafter (Small N P000601821 4 Roof) O P005800001 Hook 1 P1 P005700773 Long Netting Rod 4 P2 P005700774 Short Netting Rod 4 R P001100622 Small Canopy 1 S P001100623 Big Canopy 1 T P001200242 Mosquito Netting 1 ...
-
Page 7: Hardware Pack
Hardware Pack Label Part Number Description Qty Spare Part Image AA H010010003 Bolt M6*15 56 3 Bolt M6*35 BB H010010004 8 1 CC H050030001 Flat washer M6 80 4 DD H040010004 Nut M6 16 1 Stake ￠6*230 EE H070010001 8 0 FF P005100264 Ring 104 6 ... - Page 8 ...
- Page 9 ...
- Page 10 ...
- Page 11 ...
- Page 12 ...
- Page 13 ...
- Page 14 ...
- Page 15 ...
- Page 16 ...
- Page 17 ...
- Page 18 ...
- Page 19 ...
- Page 20 ...
- Page 21 ...
- Page 22 ...
- Page 23 ...
- Page 24 Please do the matching of zippers for different panels as showing the picture ...
- Page 25 Please do the matching of zippers for different panels as showing the picture ...
- Page 26 Country of Origin: China n: Chin Production Number: 2022200003...
