100508
User Manual
4x4 HDMI Matrix Switch, 4K/60

Advertisement

loading
Need help?

Need help?

Do you have a question about the 100508 and is the answer not in the manual?

Questions and answers

Related Manuals for MuxLab 100508

Summary of Contents for MuxLab 100508

  • Page 1 100508 User Manual 4x4 HDMI Matrix Switch, 4K/60...
  • Page 2 Overview This product is a 4 in 4 out HDMI Matrix with Ultra HD up to 4k60 4:4:4 8bit HDR and HDCP2.2. It reliably distributes four HDMI source signal to four HDMI displays. Also provide audio de-embedded via coaxial port for each HDMI port. All output port support 4K scale down to 1080P.

  • Page 3: Product Photo

    PRODUCT PHOTO...
  • Page 4 INTRODUCTION FEATURES ⚫ Distributes four HDMI sources signal to four HDMI displays ⚫ HDMI2.0 with 4K@60 4:4:4 8bit and HDCP 2.2 compliant ⚫ Support HDR 10 and Dolby version ⚫ Support 4K scale down to 1080P ⚫ Support remote control, button, RS232, Telnet & Web GUI ⚫...

  • Page 5: Specifications

    SPECIFICATIONS: 1) HDMI version………………………….. HDMI 2.0 2) HDCP version…………………………..HDCP2.2 3) HDMI resolution….…..24/50/60fs/4K*2K/1080p /1080i/720p/576p/576i/480p/480i 4) Support video format ..24bit/30bit,36bit deep color 5) Support audio format…………………….DTS-HD/ Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD/Dolby Atoms 6) Max bandwidth……………………………..600MHz 7) Max baud rate.……………………………..6Gbps 8) Input/Output TMDS signal ..0.5~1.5Volts p-p(TTL) 9) Input/Output DDC signal ………… 5Volts p-p (TTL) 12) Max working current……………………..1.5A 13.Power adapter format..
  • Page 6 Operating and Connecting： 1.Connect one cable from each HDMI source devices to HDMI input. 2.Connect one cable from each display (monitor or projector) to the HDMI outputs.
  • Page 7 Setting RS232 control Advanced user may need to control the matrix via RS232, connect a PC or control system. Professional rs232 serial interface software (e.g. UART Assist) may be needed as well. Before executing API commands through RS232, ensure the RS232 port of the matrix and control PC are set correctly.
  • Page 8 EZS OUTx EXA EN Set Ex-Audio Output Enable {x=[0~4](0=ALL)} EZS OUTx EXA DIS Set Ex-Audio Output Disable {x=[0~4](0=ALL)} EZS OUTx STREAM ON Set Output x Stream ON {x=[0~4](0=ALL)} EZS OUTx STREAM OFF Set Output x Stream OFF{x=[0~4](0=ALL)} EZS INx EDID y Set Input x EDID{x=[0~4](0=ALL), y=[0~32]} EZS HIP xxx.xxx.xxx.xxx Set Host IP Address to xxx.xxx.xxx.xxx...
  • Page 9 Sense Switch, select inputs for each output. Audio Setting, turn on/off audio breakout...
  • Page 10 EDID Manage, select EDID for each input, there are more than 40 kinds of EDID options. System setting, set IP address and alias name.
  • Page 11 Scaler setting Press the output select button for 3 seconds until the LED flash 3times, the output port scaler function will be on and will make 4K signal scale down to 1080p. Press the output select button for 3 seconds until the LED flash 1times and the output port scaler function will be off.
