Summary of Contents for MuxLab 500413
- Page 1 HDMI 4x4 Matrix Switch Kit, HDBT, PoC, 4K/60 Installation & Operation Manual 500413 © MuxLab Inc. 2019 94-000913-A / SE-000913-A...
- Page 2 Unpack the equipment carefully and save the original box and packing material for possible future shipment. Please read this user manual carefully before using the product. © MuxLab Inc. 2019...
-
Page 3: Table Of Contents
5.3.1. RS232 connection ................13 5.3.2. Basic Settings ..................13 5.3.3. RS232 Communication Commands ........... 14 5.3.4. Control Modes ................... 18 5.3.5. Web-Interface GUI for TCP/IP control ..........19 Troubleshooting & Maintenance ................22 Regulatory Compliance ....................24 © MuxLab Inc. 2019... -
Page 4: Introduction
The HDBT Receivers are powered by the matrix switch via PoC technology. LED indicators show real-time switching status. Controllable via front panel, RS232, IR and TCP/IP. Built-in Graphical User Interface (GUI) for TCP/IP control. Powerful EDID management. Easy installation, and is rack-mountable. © MuxLab Inc. 2019... -
Page 5: Package Content
Two (2) Power Cord - European One (1) 48V/2.5A DC PoH Power Adapter One (1) 48VDC/2A DC Power Adapter Please verify that the product and the accessories are all included; if not, please contact your dealer. © MuxLab Inc. 2019... -
Page 6: Specification
One (1) 2-pin power connector for unit 48VDC power supply. Audio Digital Audio: PCM, Dolby TrueHD, DTS-HD Master Audio Cable HDMI cable of appropriate length for video resolution selected cat 5e/6 or better twisted pair cable required © MuxLab Inc. 2019... - Page 7 Humidity: Up to 90% non-condensing Enclosure Metal enclosure Bracket Includes rack and wall mount bracket Dimensions 500413 Matrix Switch: 17.5” x 3.7” x 9” (444.5mm x 94mm x 229mm) Shipping Weight 13.8 lbs (6.25 kg) Compliance Regulatory: FCC, CE, RoHS...
-
Page 8: Panel Description
1 to 8 Menu Menu button: Press to enter Menu mode. Enter button: Press to confirm and save the setting. UP button: Press to change menu options. Down button: Press to change menu options. © MuxLab Inc. 2019... -
Page 9: Hdmi 4X4 Matrix Switch Rear Panel
(e.g. PC). RS232 HDBT Serial ports for HDBT control Ports Connects with a PC over the network for TCP/IP Ethernet 48V/2.5A DC Power over HDBaseT connector PoH Power 48VDC/2A DC Power connector Power © MuxLab Inc. 2019... -
Page 10: System Connections
Matrix Switch using TCP/IP protocol. Connect an IR Sensor to the IR Sensor port, and an IR Emitter to the IR Emitter port. The IR signal can be transmitted bi-directionally between the HDMI 8x8 Matrix Switch and the HDBT Receiver(s). © MuxLab Inc. 2019... -
Page 11: Connection With The Hdbt Receiver
HDMI 8x8 Matrix Switch Kit, HDBT, PoC, 4K/60 Installation & Operation Manual Connect both the 48V/2.5A DC PoH connector and 48VDC/2A DC power adapter to their respective ports of the 500413. Note: Connect the HDBT ports of the Matrix Switch and far-end HDBT Receiver with straight-through cable. -
Page 12: System Operations
Note: LED Indicators of the pressed buttons above will blink green for three times if the connections were completed successfully, then the LED will switch OFF. If the connection failed, they the LEDs will turn OFF immediately. © MuxLab Inc. 2019... -
Page 13: Ir Control
HDMI 8x8 Matrix Switch Kit, HDBT, PoC, 4K/60 Installation & Operation Manual 5.2. IR Control 5.2.1. IR Remote Users can control the 500413 through the included IR remote. Here is a brief introduction to the IR remote. Output Channels Selection ① Input Channels Selection ②... -
Page 14: Rs232 Communication Commands
8] [0 = All, y = 2, 5; 2 = 2K -> 4K, 5 = HDBT mode] Sets external audio output SET OUTx EXA EN/DIS enable/disable x to input y [x = 0-8] [0 = All] © MuxLab Inc. 2019... - Page 15 [3 = 1080p_3D_2CH] [4 = 1080p_3D_6CH] [5 = 1080p_3D_8CH] SET INx EDID y [6 = 4K30Hz_3D_2CH] [7 = 4K30Hz_3D_6CH] [8 = 4K30Hz_3D_8CH] [9 = 4K60HzY420_3D_2CH] [10 = 4K60HzY420_3D_6CH] [11 = 4K60HzY420_3D_8CH] [12 = 4K60Hz_3D_2CH] [13 = 4K60Hz_3D_6CH] © MuxLab Inc. 2019...
- Page 16 Network Setup Command xxx = [000 – 255], zzzz = [0001 – 9999] route address SET RIP xxx.xxx.xxx.xxx xxx.xxx.xxx.xxx SET HIP xxx.xxx.xxx.xxx Set Host IP address to xxx.xxx.xxx.xxx SET NMK xxx.xxx.xxx.xxx Set Net mask to xxx.xxx.xxx.xxx SET TIP zzzz Set TCP/IP port to zzzz © MuxLab Inc. 2019...
- Page 17 SET IR SYS xx.yy yy=[00-FFH]} Set IR Data Code {x=[1-8], y=[1-8], zz SET IR OUTx INy CODE zz = [00-FFH]} GET IR SYS Get IR Custom Code GET IR OUTx INy CODE Get IR Data Code © MuxLab Inc. 2019...
-
Page 18: Control Modes
Step2. Set the PC’s network segment to the same as the Matrix Switch’s. However if the PC has the same network segment as the Router or Ethernet Switch then please take note of the PC’s original network segment before changing it, © MuxLab Inc. 2019... -
Page 19: Web-Interface Gui For Tcp/Ip Control
LAN are able to then control the Matrix Switch through its web- interface GUI. 5.3.5. Web-Interface GUI for TCP/IP control The 500413 supports a web-interface GUI for convenient TCP/IP control. The GUI allows users to interact with this Kit through graphical icons. Type http://192.168.1.239... - Page 20 This page allows you to set the video settings not only for the HDMI outputs but also for the HDBT ones. Audio Setting Screen: It allows you to change audio output status. EDID Manage Screen: This page manages EDID configuration. See the screenshot below for further details: © MuxLab Inc. 2019...
- Page 21 HDMI 8x8 Matrix Switch Kit, HDBT, PoC, 4K/60 Installation & Operation Manual System Setting Screen: View and configure the network settings, including MAC address, IP, TCP port and port alias configuration. © MuxLab Inc. 2019...
-
Page 22: Troubleshooting & Maintenance
Troubleshooting & Maintenance The following table describes some of the symptoms, probable causes and possible solutions with respect to the installation of the 500413 HDMI 8x8 Matrix Switch. Problems Causes Solutions The connecting cables Check whether the cables may not be connected... - Page 23 RS232 / IR remote / The device is damaged. dealer for repair. front panel buttons If you still cannot diagnose the problem, please call MuxLab Customer Technical Support at 877-689-5228 (toll-free in North America) or at (+1) 514-905-0588 (International).
-
Page 24: Regulatory Compliance
Regulatory Compliance Disclaimer Information in this document is subject to change without notice. The manufacturer does not make any representations or warranties (implied or otherwise) regarding the accuracy and completeness of this document and shall in no event be liable for any loss of profit or any other commercial damage, including but not limited to special, incidental, consequential, or other damages. - Page 25 2321 Cohen St, Montreal, Quebec, Canada. H4R 2N7 Tel: (514) 905-0588 Fax: (514) 905-0589 Toll Free (North America): (877) 689-5228...
