VOLERO BATTEN AQUA
INSTRUCTION MANUAL
INDEX
Congratulations on choosing a Claypaky product!
We thank you for your custom.
Please note that this product, as all the others in the
rich Claypaky range, has been designed and made with
total quality to ensure excellent performance and best
meet your expectations and requirements.
CL3002
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Claypaky VOLERO BATTEN AQUA
Summary of Contents for Claypaky VOLERO BATTEN AQUA
-
Page 1: Table Of Contents
We thank you for your custom. Safety information Please note that this product, as all the others in the rich Claypaky range, has been designed and made with Unpacking and preparation total quality to ensure excellent performance and best Installation and start-up meet your expectations and requirements. -
Page 2: Safety Information
1. SAFETY INFORMATION SAFETY INFORMATION IMPORTANT: Claypaky recommends you carefully read and keep the safety information on this product, also available in digital format at the following link: www.claypaky.com Ref: FIS02F - Safety Information Volero Batten Aqua INFORMAZIONI DI SICUREZZA... -
Page 3: Unpacking And Preparation
Packing contents - Fig. 1 3. INSTALLATION AND START-UP 3.1 Fixture overview Basament align pin W-DMX Antenna Ethernet 5pin DMX IN/THRU Functional buttons LCD Display Safety loop Anti-moisture valve Fuse Tilt lock Neutrik PowerCON Frost lock holder TRUE1 (IN/OUT) Continue VOLERO BATTEN AQUA... -
Page 4: Installing The Fixture
WARNING: the safety chains must be installed except when the projector rests on the floor. (Code 2x 105041/801 available upon request). This must be secured to the projector support structure and then hooked to the two fastening points. VOLERO BATTEN AQUA... - Page 5 Floor Line array connection - Fig. 4 Continue VOLERO BATTEN AQUA...
-
Page 6: Connecting To Mains Supply
A terminating plug must be inserted on the last projector with a resistance of 120 (minimum 1/4 W) between terminals 2 and 3. IMPORTANT: The wires must not make contact with each other or with the metal casing of the connectors. The casing must be connected to the shield braid and pin 1 of the connectors. VOLERO BATTEN AQUA... -
Page 7: Switching On The Fixture And Basic Setup
Dmx Address Warning Message Switching on the projector - Fig. 8 Switch-on the fixture. The projector starts resetting the effects. At the same time, the following information scrolls on the display: Volero Batten Aqua Firmware version: ..address: ..On conclusion of resetting in case of absence of the dmx signal, Tilt move to the “Home” position (Tilt 128 bit). The control panel (Fig. 7) has a display and buttons for the complete programming and management of the projector menu. -
Page 8: Maintenance
30 seconds. 4. MAINTENANCE 4.1 Fuses replacing 10AT 250V Fuse replacing - Fig. 10 Each Volero Batten Aqua has 1 fuse 10AT 250V, associated with the main power cord connection. VOLERO BATTEN AQUA... -
Page 9: Periodical Cleaning & Caution
It is recommended that the projector undergoes an annual service by a qualified technician for special maintenance involving at least the following operations: - General cleaning of internal parts. - Restoring lubrication of all parts subject to friction, using lubricants specifically supplied by Claypaky. - General visual check of the internal components, cabling, mechanical parts, etc. -
Page 10: Battery Removal
4.3 Battery removal This product contains a rechargeable battery. To preserve the environment, please dispose the battery at the end of its life according to the regulation in force. VOLERO BATTEN AQUA... -
Page 11: Dimensions
Signal transmission cable faulty or disconnected. Replace the cables. Incorrect addressing. Check addresses (see instructions). Fault in the electronic circuits. Call an authorised technician. Optic fault. Call an authorised technician. Dust or grease deposits. Clean (see instructions). VOLERO BATTEN AQUA... - Page 12 CLAYPAKY - Via Pastrengo, 3/b - 24068 Seriate (BG) Italy - Tel. +39-035 -654311 - www.claypaky.com S.p.A.
