  • Page 1 HDCVI Camera User’s Manual Version 1.0.0...

  • Page 2: Table Of Contents

    Table of Contents General Introduction ........................1 Overview ........................1 Features ......................... 1 Device Structure ......................... 2 Dimension ........................2 Cable Port ........................4 Installation............................ 6 Installation for Model A ....................6 Installation for Model B ....................7 Installation for Model C ....................9 Installation for model D ....................
  • Page 3 Welcome Thank you for purchasing our HDCVI camera! This user’s manual is designed to be a reference tool for your system. Please read the following safeguard and warnings carefully before you use this series product! Please keep this user’s manual well for future reference! Important Safeguards and Warnings 1．Electrical safety ...
  • Page 4  Please do not provide two or more power supply modes for the device, otherwise it may cause damage to the device. Statement  Please refer to the actual product for more details; the manual is just for reference.  The manual will be regularly upgraded according to the product update;...

  • Page 5: General Introduction

    1 General Introduction 1.1 Overview This series HDCVI camera conforms to the HDCVI standard. It supports video signal high- speed long distance transmission without any delay. It can be controlled by the HCVR conforming to the HDCVI. 1.2 Features  Adopt high performance CMOS image sensor, megapixel definition.

  • Page 6: Device Structure

    2 Device Structure 2.1 Dimension Refer to Figure 2-1, Figure 2-2 and Figure 2-3 for the dimension of model A. The unit is mm. Figure 2-1 Figure 2-2 Figure 2-3...
  • Page 7 Refer to Figure 2-4 for the dimension of model B. The unit is mm. Figure 2-4 Refer to Figure 2-5 for the dimension of model C. The unit is mm. Figure 2-5 Refer to Figure 2-6 for the dimension of model D1. The unit is mm. Figure 2-6 Refer to Figure 2-7 and Figure 2-8 for the dimension of model D2 and model D3.

  • Page 8: Cable Port

    Figure 2-8 2.2 Cable Port Note  The following figures are for reference only, which are only used to know the function of cable port.  Different devices may have different cables, please refer to the actual device for more details.
  • Page 9 Figure 2-12 Note  When the two cables become short circuit, then it can realize from HD video output to SD video output. On the contrary, it will switch back to HD video output when the two cables become open circuit. ...

  • Page 10: Installation

    3 Installation Attention:  Please install the device in time after it is taken apart, which is to avoid the camera module being exposed to damp environment for too long.  Before the installation, please make sure the installation surface is thick enough to sustain at least 3X weight of the camera.

  • Page 11: Installation For Model B

    Figure 3-2 Step1 Install the camera ④ together with the bracket ② on the fixed surface ① and secure the installation screw ③ firmly. Step 2 Adjust the camera ④ angle and tighten the locking screw ⑤ on the enclosure firmly . Step 3 Connect the video output port of device cable to the rear-end HCVR device and connect the power port to power.
  • Page 12 Figure 3-3 Step 1 Take down the pedestal ③. Unscrew the locking screws ⑦ and ⑧ anticlockwise to make it separate. Step 2 Take out the installation position map from the device accessories bag, paste it on the installation surface ①, and then dig holes on the installation surface according to the installation position map.

  • Page 13: Installation For Model C

    Figure 3-4 Note Adjust the locking screws ① and ② shown in the figure above. Step 6 Connect the device cable to the back-end HCVR device. So far, the device installation and cable connection have been completed, you can check monitoring image via rear-end coding device.

  • Page 14: Installation For Model D

    Step 1 Take down the bracket ③. Unscrew the locking screws anticlockwise to make it separate. Step 2 Use tools to fix the expansion bolts ⑤ on the installation board ⑥ according to the fixing holes of bolt. Step 3 Adjust bracket location.

  • Page 15: Installation For Model D2 And D3 (With Bracket)

    Paste some glass sealant on the back of the joint between camera and installation board, which is to fix it more firmly. Step 3 Connect the device cable to the back-end HCVR device.  For mobile model: Connect aviation head cable to the back-end HCVR device. ...

  • Page 16: Menu

    4 Menu 4.1 HCVR Settings This HDCVI camera series can adjust OSD menu via coaxial control. After connected the camera to the HDCVI series HCVR, from Main Menu->Setting->System->PTZ, you need to select the channel number for access and set control mode as HDCVI and the protocol as HD- CVI.
  • Page 17 Figure 4-3 See Table 4-1 for the details of button functions. Button Function Open menu Select menu item 、 Select menu value 、 Table 4-1 If there is “ ”, click the “Enter” button in “Menu Operation” interface to go to the 2nd menu. Click “Return”...

  • Page 18: Appendix Ⅰ Maintenance

    Appendix Ⅰ Maintenance Caution Please maintain the device according to the following instructions in order to ensure the image effect and long-term stable operation of the device. Maintenance for lens and mirror surface The lens and mirror surface are covered with antireflection coating, so it may produce hazardous substance and lead to performance reduction or scratch, dimness etc.
