4. Power Cable Connection
Step.1
Before connecting all wirings, please take off bottom cover by
removing two screws as shown Pic 4.1.
Step.2
Connect the red and black cables to the inverter DC connector as
shown in Pic 4.2.
Step.3
At the other end of the cable, connect to the battery as shown Pic 4.3.
Pic 4.1
BATTERY+
BATTERY-
Pic 4.2
6
