1.BOM List

Before installation, you should prepare following items as shown in
Graph 1.
Item
Power Cable
(DC)
RJ45 Cable
PC (Personal
Computer)
Battery
Inverter
Remarks
Conductor cross-section: 50 mm² to
95 mm²
Cable diameters: 14 mm to 25 mm
Only copper cables may be used.
The DC cables must be sized for the
maximum battery voltage and the
maximum battery current.
RS485 communicationTerminal
(RJ45 port) follow RS485 protocol, to
output batteries information.
Self-Provide.
48100R / 48100C / 4850
Voltronic Axpert King
Graph 1.
Quantity
Depends on the number of
batteries and the
connection method
1
1
Depends on the number of
batteries and the
connection method
1
3
