MSMP1EVK

3.1 Components

3.1.1 Ethernet

MSMP1EVK offers 10/100 MBit Ethernet Channel on connector X3. For best flexibility the Ethernet-PHY
KSZ8081 (Micrel) is populated on the MSMP1EVK baseboard.
Connector X3:
Function MSMP1EVK
PB17/FEC0 MDIO
PB16/FEC0 MDC
PB0/FEC0 TXCK
PB8/FEC0 RX0
PB9/FEC0 RX1
PB6/FEC0 RXDV
PB7/FEC0 RXER
PB12/FEC0 TX0
PB13/FEC0 TX1
PB2/FEC0 TXEN
3.3V NRST

3.1.2 CAN

Please note that the CAN interface can only be functional in case one or two of the optional CAN interfaces
on the MA5D4 System on Module are populated.The CAN interfaces 1 and 2 are available on connectors
X4 and X5.
Chapter 3. Resources
Pin MPU Function MSMP1
Pin
174 AB2 ETH_MDIO
173 AB3 ETH_MDC
189 V4 ETH_RGMII_RX_CLK
181 AB6 ETH_RGMII_RXD0
182 AA6 ETH_RGMII_RXD1
183 Y9 ETH_RGMII_RX_CTL
184 W1 ETH_GMII_RX_ER
177 AA1 ETH_RGMII_TXD0
178 AA2 ETH_RGMII_TXD1
187 Y5 ETH_RGMII_TX_CTL
– – –
CHAPTER
THREE

RESOURCES

SiP
Pads
T15
T16
R15
K15
L15
M15
L16
H15
G15
K16
–
