MSMP1EVK
MSMP1EVK
Version:
1.0
Created on:
Jul 13, 2022
Created by:
Diana Korchmar
© ARIES Embedded GmbH. The information contained in this document is strictly confiden-
tial. This document may not be copied, reproduced, translated, changed or distributed
without the written approval of ARIES Embedded GmbH
Page 1 of 44
Advertisement
Table of Contents
Related Manuals for Aries Embedded MSMP1EVK
Summary of Contents for Aries Embedded MSMP1EVK
- Page 1 Jul 13, 2022 Created by: Diana Korchmar © ARIES Embedded GmbH. The information contained in this document is strictly confiden- tial. This document may not be copied, reproduced, translated, changed or distributed without the written approval of ARIES Embedded GmbH...
-
Page 2: Table Of Contents
2 Overview 2.1 MSMP1EVK .......... -
Page 3: About This Manual
ARIES Embedded. ARIES Embedded explicitly reserves the rights to change or add to the contents of this Preliminary User’s Manual or parts of it without notification. -
Page 4: Copyright
1.3 Copyright This document may not be copied, reproduced, translated, changed or distributed, completely or partially in any form without the written approval of ARIES Embedded GmbH. 1.4 Registered Trademarks The contents of this document may be subject of intellectual property rights (including but not limited to copyright, trademark, or patent rights). -
Page 5: Overview
CHAPTER OVERVIEW 2.1 MSMP1EVK The MSMP1EVK supports a quick start-up of CPU projects and can easily be used as a fast-prototype platform. The MSMP1EVK contains the Open Standard Module compliant System-In-Package based on ST Micro- electronics STMP1 Family architecture offering high-performance single/dual CortexA7 cores in combination with a CortexM4 core. -
Page 6: Feature Set
– Cortex-M4, up to 209MHz – 512MB LPDDR3 RAM – 4GB eMMC – -25. . . +85°C Please contact ARIES Embedded for more information about the availability of other standard products of MSMP1EVK or custom configurations. Chapter 2. Overview Page 6 of 44... -
Page 7: Block Diagram
MSMP1EVK 2.4 Block Diagram Chapter 2. Overview Page 7 of 44... -
Page 8: Dimensions
MSMP1EVK 2.5 Dimensions Chapter 2. Overview Page 8 of 44... -
Page 9: Part Overview
MSMP1EVK 2.6 Part Overview 2.7 Handling Recommendations To avoid mechanical damage to the components populated on MSMP1 it is strongly recommended not to apply mechanical force on the Ball Grid Array (BGA) components. The BGA components are marked as shaded in the figure below: Chapter 2. -
Page 10: Resources
MSMP1EVK CHAPTER THREE RESOURCES 3.1 Components 3.1.1 Ethernet MSMP1EVK offers 10/100 MBit Ethernet Channel on connector X3. For best flexibility the Ethernet-PHY KSZ8081 (Micrel) is populated on the MSMP1EVK baseboard. Connector X3: Function MSMP1EVK Function MSMP1 Pads PB17/FEC0 MDIO ETH_MDIO... -
Page 11: Uart
Slope control • To enable slope control – jumper JP1 has to be closed for CAN interface 1 – jumper JP3 has to be closed for CAN interface 2 Connector X4: Function MSMP1EVK Function MSMP1 Pads ePB23/SPI1_NCS2/ FDCAN1_TX AC17... -
Page 12: Reset And Wake Up Button
• To connect the UART signals to the SP3222 RS232 line drive: – JP18, JP19, JP20, JP21 for UART0 – JP22, JP23, JP24, JP25 for UART1 have to be closed accordingly Connector X6: Function MSMP1EVK Function MSMP1 Pads PD12/RXD0 AA11... -
Page 13: User Leds
MSMP1EVK 3.1.6 User LEDs MSMP1EVK offers three user LEDs. They can be activated by either using a port-signal of the MPU or permanently activated by closing a jumper. Function MSMP1EVK Pull- Function MSMP1 down Pads PD28 PG15 PD29 R142 –... -
Page 14: Lcd Interface
MSMP1EVK 3.1.9 LCD Interface The LCD interface of MSMP1EVK is available on connectors X19 and X20. Connector X19: Function MSMP1EVK Function MSMP1 Pads PA28/LCD_PCK LCD_CLK PA2/LCD_D2/FEC1_TXCK LCD_B2 PA3/LCD_D3 LCD_B3 PA4/LCD_D4/FEC1_TXEN LCD_B4 PA5/LCD_D5 LCD_B5 PA6/LCD_D6 LCD_B6 PA7/LCD_D7 LCD_B7 PA10/LCD_D10/FEC1_RXDV LCD_G2 PA11/LCD_D11/FEC1_RXER... -
Page 15: Sd/Mmc Card
LCD_BL_CTRL Closing Jumper J8 will connect the LCD vbacklight to +5V. 3.1.10 SD/MMC Card MSMP1EVK offers a microSD-card interface on connector X23. The SD-card interface can be enabled by triggering the CPU pin PE17/SD_MMC0_PWR/EBI_A17 or closing jumper KP10. Function MSMP1EVK... -
Page 16: Image Sensor Interface
MSMP1EVK 3.1.11 Image Sensor Interface MSMP1EVK offers a Image Sensor Interface on connector X22. Function MSMP1EVK Function MSMP1 Pads PA31/I2C0_SCL I2C2_SCL AA15 PA30/I2C0_SDA I2C2_SDA AA16 PB3/ISI_VSYNC JTAG_TDO PB4/ISI_HSYNC JTAG_TDI ePB1/EN_PMIC_I2C JTAG_TCK PD31/SPI_NPCS2 JTAG_TMS PC26/ISI_D7 PA14 (GPIO/DBTRGO) PC25/ISI_D6 JTAG_NTRST PC24/ISI_D5 PA13 (GPIO/DBTRGI) - Page 17 MSMP1EVK Connector X27: Function MSMP1EVK Function MSMP1 Pads PE0/PMIC_IRQ/EBI_A0 PI5 (GPIO/TIM8_CH1) PE1/FEC0_IRQ/EBI_A1 PI6 (GPIO/TIM8_CH2) PE2/SD_MMC0_CD/EBI_A2 SD_CardDetect PE3/HDMI_IRQ/EBI_A3 – – – PE4/AUDIO_IRQ/EBI_A4 PG3 (GPIO/CAN_STBY) PE5/SD_NNC1_CD/EBI_A5 PI11 (GPIO) ePE6/CAN2_RX/EBI_A6 FDCAN2_RX AB19 ePE7/CAN2_TX/EBI_A7 FDCAN2_TX AC19 PE8/unused/EBI_A8 OTG_ID AB22 PE9/unused/EBI_A9 – – – PE10/USBA_EN/EBI_A10 –...
- Page 18 MSMP1EVK Connector X13: Function MSMP1EVK Function MSMP1 Pads PB10/AUDIO_MCLK PC0 (GPIO) PB14/unused PC3 (GPIO) PB15/HDMI_RST PC7 (GPIO) PB18/SPI1_MISO/CAN_DNU/ SPI1_MISO EBI_D8 PB19/SPI1_MOSI/CAN_DNU/ SPI1_MOSI EBI_D9 PB20/SPI1_SPCK/CAN_DNU/ SPI1_SCK EBI_A10 PB21/SPI1_NCS0/CAN_DEN/ SPI1_NSS EBI_D11 ePB22/SPI1_NCS1/CAN1_RX/ FDCAN2_RX AB19 EBI_D12 ePB23/SPI1_NCS2/CAN1_TX/ FDCAN1_TX AC17 EBI_D13 PB24/JTAG_TDI/EBI_D14 – –...
-
Page 19: Security Box Module
MSMP1EVK 3.1.13 Security Box Module The signals of the Security Box Module are available on a connecter X15. Function MSMP1EVK Function MSMP1 Pads PIOBU15 PG8 (GPIO/ETH_CLK) PIOBU14 – – – PIOBU13 USART2_CK (GPIO) PIOBU12 USART2_TX (GPIO) PIOBU11 USART2_RX (GPIO) PIOBU10... -
Page 20: Adc-Signals
MSMP1EVK 3.1.15 ADC-Signals The signals of the ADC are available on a connecter X14. Function MSMP1EVK Function MSMP1 Pads ADCVREF – – – ADC4 PA5/ADC1_IN19 (GPIO) ADC3 PB0/ADC2_IN9 (GPIO) ADC2 PA6/ADC2_IN3 (GPIO) ADC1 ANA1/ADC2_IN1 ADC0 ANA0/ADC1_IN0 3.1.16 MxM Edge Connector... - Page 21 MSMP1EVK Table 2 – continued from previous page Function MSMP1EVK Function MSMP1 Pads PE25/unused/EBI_NCS1# PD15 (GPIO/FMC_AD1) PE22/SD_MMC1_DA2/ EBI_A22 PD11 (GPIO/FMC_CLE) PE23/SD-MMC1_DA3/ EBI_A23 PD12 (GPIO/FMC_ALE) PE20/SD_MMC1_DA0/ EBI_A20 PD5 (GPIO/FMC_NWE) PE21/SD_MMC1_DA1/ EBI_A21 PD6 (GPIO/FMC_NWAIT) PE18/SD_MMC1_CK/ EBI_A18 PD0 (GPIO/FMC_AD2) PE19/SD_MMC1_CDA/ EBI_A19 PD1 (GPIO/FMC_AD3)
- Page 22 MSMP1EVK Table 2 – continued from previous page Function MSMP1EVK Function MSMP1 Pads – – PC24/ISI_D5 PA13 (GPIO/DBTRGI) PC25/ISI_D6 JTAG_NTRST PC22/ISI_D3 SPI4_MOSI PC23/ISI_D4 PI7 (GPIO/TIM8_CH3) PC20/ISI_D1 SPI4_NSS AA23 PC21/ISI_D2 SPI4_MISO – – PC19/ISI_D0 SPI4_SCK PC18/EBI_CLE I2S2_WS (TIM5_CH4) – – PC16/EBI_RDY#...
- Page 23 MSMP1EVK Table 2 – continued from previous page Function MSMP1EVK Function MSMP1 Pads PIOBU14 – – – PIOBU15 PG8 (GPIO/ETH_CLK) PIOBU12 USART2_TX (GPIO) PIOBU13 USART2_CK (GPIO) PIOBU10 USART2_RTS (FMC_NOE) PIOBU11 USART2_RX (GPIO) PIOBU8 USART2_CTS (TIM1_BKIN) PIOBU9 PE6 (GPIO/TIM1_BKIN2) PIOBU6 PB1 (GPIO/TIM1_CH3N)
- Page 24 MSMP1EVK Table 2 – continued from previous page Function MSMP1EVK Function MSMP1 Pads PB21/SPI1_NCS0/CAN_DEN/ SPI1_NSS EBI_D11 PB18/SPI1_MISO/CAN_DNU/ SPI1_MISO EBI_D8 PB19/SPI1_MOSI/CAN_DNU/ SPI1_MOSI EBI_D9 – – – – PB16/FEC0 MDC ETH_MDC PB17/FEC0 MDIO ETH_MDIO PB14/unused PC3 (GPIO) PB15/HDMI_RST PC7 (GPIO) PB12/FEC0 TX0...
- Page 25 MSMP1EVK Table 2 – continued from previous page Function MSMP1EVK Function MSMP1 Pads PA14/LCD_D14/FEC1_TX0 LCD_G6 PA15/LCD_D15/FEC1_TX1 LCD_G7 PA12/LCD_D12/FEC1_RX0 LCD_G4 PA13/LCD_D13/FEC1_RX1 LCD_G5 PA10/LCD_D10/FEC1_RXDV LCD_G2 PA11/LCD_D11/FEC1_RXER LCD_G3 PA8/LCD_D8/JTAG_TCK LCD_G0 PA9/LCD_D9 LCD_G1 AA30 – – – – PA6/LCD_D6 LCD_B6 PA7/LCD_D7 LCD_B7 PA4/LCD_D4/FEC1_TXEN LCD_B4...
- Page 26 MSMP1EVK Chapter 3. Resources Page 26 of 44...
-
Page 27: Schematics
MSMP1EVK 3.2 Schematics 3.2.1 MSMP1 Adapter to MA5D4EVK Chapter 3. Resources Page 27 of 44... - Page 28 MSMP1EVK Chapter 3. Resources Page 28 of 44...
- Page 29 MSMP1EVK Chapter 3. Resources Page 29 of 44...
- Page 30 MSMP1EVK Chapter 3. Resources Page 30 of 44...
- Page 31 MSMP1EVK Chapter 3. Resources Page 31 of 44...
- Page 32 MSMP1EVK Chapter 3. Resources Page 32 of 44...
-
Page 33: Baseboard Ma5D4Evk
MSMP1EVK 3.2.2 Baseboard MA5D4EVK Chapter 3. Resources Page 33 of 44... - Page 34 MSMP1EVK Chapter 3. Resources Page 34 of 44...
- Page 35 MSMP1EVK Chapter 3. Resources Page 35 of 44...
- Page 36 MSMP1EVK Chapter 3. Resources Page 36 of 44...
- Page 37 MSMP1EVK Chapter 3. Resources Page 37 of 44...
- Page 38 MSMP1EVK Chapter 3. Resources Page 38 of 44...
- Page 39 MSMP1EVK Chapter 3. Resources Page 39 of 44...
- Page 40 MSMP1EVK Chapter 3. Resources Page 40 of 44...
- Page 41 MSMP1EVK Chapter 3. Resources Page 41 of 44...
- Page 42 MSMP1EVK Chapter 3. Resources Page 42 of 44...
- Page 43 MSMP1EVK Chapter 3. Resources Page 43 of 44...
- Page 44 MSMP1EVK Chapter 3. Resources Page 44 of 44...
