Eaton IZM32 Instruction Manual page 53

External PT Module for PXR25 P type trip unit
0-600 L-L INPUT
A B C
1 3 5
IZM circuit breaker - 3 pole - 3 wire
0-600 L-L INPUT
N A B C
1 3
IZM circuit breaker - 3 pole or 4 pole - 4 wire
Secondary
Contacts
32
31 PTVC
30 PTVB
29 PTVA
To additional
breakers (16 max)
BREAKER
Secondary
5
Contacts
32 PTVN
31 PTVC
30 PTVB
29 PTVA
To additional
breakers (16 max)
BREAKER
IZM32 / IN32 low voltage air circuit breaker MN013017EN May 2022 www.eaton.com
LA
TP2
PT
LB
MODULE
LC
LA
TP2
PT
LB
MODULE
LC
LN
Section 6: Wiring diagrams
49
