Eaton IZM32 Instruction Manual page 14

Section 2: Receiving, handling, and installation
(Front View)
Extension Rails
1
2
Extension Rail Cutout
3 Secondary Plug-in Connectors
4
Secondary Terminal Blocks
5
Arc Hood
6
Optional Cell (TOC) Switch
7
Optional Key Interlock
8 Earthing Bar
9
Open Safety Shutters
10
Primary Terminals
(Rear View)
Figure 2-11 Drawout cassette features (front and rear views)
10 IZM32 / IN32 low voltage air circuit breaker MN013017EN May 2022 www.eaton.com
4
2
1
6
7
3
9
9
8
4
5
10
10
6
2
1
7
