- Page 1 USER MANUAL Anti-Vibration Table (MIRI AVT) ® Rev. 4.0 Date of revised 16.06.2022 Rx only...
- Page 2 Esco Medical Technologies, UAB Draugyste s g. 19 • Kaunas, Lithuania Tel +370 37 470 000 www.esco-medical.com • support-medical@escolifesciences.com For Technical Service, contact Europe Esco Medical Technologies, UAB Draugyste s g. 19 • Kaunas, Lithuania Tel +370 37 470 000 www.esco-medical.com •...
- Page 3 (2) years from the original purchase date, provided the instrument is calibrated and maintained following this manual. During the warranty period, Esco Medical will, at our option, either repair or replace a product Anti-Vibration Table (MIRI AVT) User Manual Rev.
- Page 4 This warranty is limited to repairing the instrument per Esco Medical's specifications. When you return an instrument to Esco Medical for service, repair or calibration, we recommend shipment using the original shipping foam and container. If the original packing materials are not available, we recommend the following guide for repackaging: •...
- Page 5 In an event where the seal must be broken to gain internal access to the instrument, you must first contact Esco Medical Ltd. You will be required to provide us with the serial number for your instrument, as well as a valid reason for breaking the Quality Seal.
-
Page 6: Table Of Contents
6.1 Before installation ..........................9 6.2 During installation ..........................9 6.3 Post-installation ..........................9 6.4 Bring the following to the installation site ................9 7 Assembling Esco Medical MIRI AVT ....................9 ® 8 Cleaning instructions ..........................13 9 Maintenance ............................... 14 10 User troubleshooting.......................... -
Page 7: How To Use This Manual
• If the equipment is used in a manner not specified by this manual, the protection provided by this equipment may be impaired. 3 About the product Esco Medical MIRI AVT is an anti-vibration table intended to be used with high ®... -
Page 8: Accessories Supplied
The anti-vibration mechanism works as a passive damping device and only partially damps the vibration that is generated on the AVT platform itself. The microscope must be placed on the anti-vibration float. In all buildings, floors vibrate at low frequencies, which may affect the performance of a high-magnification microscope. -
Page 9: Important Safety Instructions And Warnings
6 Important safety instructions and warnings 6.1 Before installation 1. Do not use the product if the package is damaged. Contact Esco Medical or the local representative. 2. Read the User manual completely before use. 3. Always keep these instructions easily accessible near the device. - Page 10 Figure 7.1 Leveling table legs Put on gloves. The 3 springs are already installed in the MIRI AVT. ® Figure 7.2 Three springs in the MIRI ® The unit comes with already safety guard installed. It is screwed with 3 screws on the left, right and the bottom side.
- Page 11 The floated part labeled 1 should be placed on the springs and equal distance left from the hole on all sides to have space for centering the floating platform. The holding screws should be facing up. Figure 7.4 No contact between the floating plate and the table It is essential that there would be no contact between the floating platform and the table.
- Page 12 Figure 7.6 Float element is placed too high In the picture above, the floated element is too high. The adjustment can only be made after the microscope has been placed on the float, as the weight will push it down. It is the fully laden float that should be level.
-
Page 13: Cleaning Instructions
After adjustment, tighten the four securing bolts again. If this is done improperly, the table will go out of adjustment while in use. The spanner key for leg adjustment can be placed under the MIRI AVT in the right ® corner. -
Page 14: Maintenance
3. Inspect the device – if it is visually clean, consider it ready for use. If the device is not visually clean, repeat the process from step 1. 9 Maintenance Esco Medical MIRI AVT is designed to be easy to use and requires almost no ®... -
Page 15: Specifications
11 Specifications Table 11.1 MIRI AVT specifications ® Technical specifications MIRI ® Overall dimensions (W x D x H) 1200 × 800 × 785 mm Weight 117 kg Material Powder painted mild steel/Stainless steel Float Size 540 × 340 Recommended load weight 26 –...
