  • Page 1 Installation Manual for CL-65+...

  • Page 2: Table Of Contents

    Table of Contents Safety Information ..................................Pg. 3 Parts List ....................................... Pg. 4 Warranty Information ................................Pg. 5 Return Policy ....................................Pg. 6 Installation ....................................Pg. 7 Paneling & Cable Management ..............................Pg. 10 TV Mounting ....................................Pg. 17 Adjustments & Fine Tuning ................................. Pg. 20 Version: 1.1.1 Date:...

  • Page 3: Safety Information

    Disclaimer: Nexus 21 disclaims any liability for modifications, improper installations, or installations over the specified weight range. Nexus 21 will not be liable for any damages arising out of the use of, or inability to use, Nexus 21 products. Nexus 21 bears no responsibility for incidental or consequential damages. This includes, but is not limited to, any labor charges for the servicing of Nexus 21 products performed by anyone other than Nexus 21.

  • Page 4: Parts List

    Parts List CL-65+ Lift System (Bottom View) Installation Hardware Pack Contents (16) #10 - 32 x 1-1/4” FHMS (4) #8 x ¾” FHWS (1) 14” Long T-Handle (16) #8 x 1-1/4” BHWS Square Drive (4) 3/8” x 2.5” Lag Bolt (1) 5/16 Hex 6”...

  • Page 5: Warranty Information

    In the event that you do need a replacement part or system, we’ll ship it to you right away, along with a prepaid UPS return shipping label and a package for the defective part or system to be returned to our offi ce. Nexus 21 will cover the shipping cost of the replacement part or system within the continental United States and Canada (excludes Hawaii, Alaska and Puerto Rico).

  • Page 6: Return Policy

    Within 30 Days of Delivery: Customers may return a Nexus 21 product(s) for any reason within 30 days of the date it is received for a full refund of the purchase price. Shipping charges associated with your order are not eligible for refund. To initiate a product-return request, please review the following conditions: •...

  • Page 7: Installation

    Installation The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs.
  • Page 8 1. Raise your system into the ceiling and fasten it to your trusses, joists, all-thread, etc. using either of the mounting methods shown above. Important Note: Do not lift the system from the Inner Frame (shown in red) as this will cause damage to the motors.
  • Page 9 Alternate Control Panel Location Power Port Wired Backup Switch Down 2. Connect the Power Cord to the Control Box and lower the Lift System by pressing the “Down” button on the Wired Backup Switch. If necessary, press “Up” at any time to stop. Ensure the Wired Backup Switch remains accessible at all times during and after installation.

  • Page 10: Paneling & Cable Management

    Paneling & Cable Management The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs.
  • Page 11 = Remove these Screws = Loosen these Screws 3. Remove the (4) Phillips Screws below the Cable Cover, then loosen the top (4) Phillips Screws and slide the Cable Cover up and off. Note: Leave the top (4) Phillips Screws in place, do not remove them as they will help relocate the Cable Cover when you put it back on.
  • Page 12 = Remove these Screws = Loosen these Screws 4. Using the image above, remove the screws indicated by a circle and loosen the screws indicated by a diamond, then slide each of the panels up to remove them. Note: If you are unable to access these screws, press and hold the “Down’ button on the Wired Backup Switch for 5 seconds to initialize the system.
  • Page 13 Through-Bolt x 12 Wood-Screws x 12 x 12 5. Align your Flip-Down Panel with the Top of the Sub-Frame, center it, then fasten it to the Sub-Frame using either of the mounting methods listed below: Through-Bolt: Mount your Flip-Down panel using (12) #10-32 x 1.25” FHMS Screws to through-bolt it to the Sub-Frame from the back side. Wood Screw: Mount your Flip-Down panel to the Sub-Frame using (12) #8 x 1.25”...
  • Page 14 6. Align the slot at the bottom of Sub-Frame Covers with the screws at the bottom of the Sub-Frame and use the previously removed screws to fasten them. Note: The Sub-Frame Covers are identical, so they can be used on either side of the Sub-Frame.
  • Page 15 Opening 8. Replace your Cable Cover by hanging it on the screws at the top of the Sub-Frame and use the previously removed screws to fasten it. Note: Ensure you cables are collected within the opening at the bottom of the Cable Cover prior to fastening it.
  • Page 16 7. Route your cables along the path indicated in the image above. Several Cable Straps are provided along the way to secure your cables in place. Note: If needed, your cables can also be routed to the left side of the lift system.

  • Page 17: Tv Mounting

    TV Mounting The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs.
  • Page 18 9a. Attach the Vertical Mounting Bars to the back of your TV using the provided Assorted TV Hardware Pack. 9b. Place the Screen Locks into one of the three hooks on each of the Vertical Mounting Bars and secure them by tightening both Philips Screws. Note: 3 sets of hooks are available on the Vertical Mounting Bars to allow adjustment to the Vertical Position of your TV.
  • Page 19 10. Adjust the vertical position of your Screen Back Plate, hang your TV on the it, then connect all AV cables ensuring enough slack is available. Once the cables are connected, center your TV, then secure it to the Screen Back Plate by tightening the Hex Screw on the Screen Locks.

  • Page 20: Adjustments & Fine Tuning

    Adjustments & Fine Tuning The combined weight of the TV + Flip-Down Panel + Cables/Components cannot exceed 100 lbs.
  • Page 21 11a. Raise the system into the ceiling to determine whether your Flip-Down Panel is too high or too low, then fully lower the system. 11b. Loosen but do not remove the Socket Cap Screws, then use the Fine Adjustment Screws to adjust the position of your Flip-Down Panel. Test the position of the Flip Down Panel by raising the system.
  • Page 22 Flip-Down Panel Trim Panels 1/4” Gap 12. Size your Trim Panels or bring the surrounding ceiling in, so there is an 1/4” gap between them and the Flip-Down Panel.
  • Page 23 Your installation is now complete, reference the documentation contained in your lift system controls for information regarding Controls and Integration.
