Summary of Contents for Nexus 21 Transcend Pro Surface
- Page 1 Transcend Pro Surface Installation Instructions...
- Page 3 Fax: (480) 951-6879 Revised: 12/4/17 Below is a parts list describing all of the items included with the Transcend Pro Surface. You may also wish to refer to the dimensional diagram shown on “Supplemental Page A” (at the end of this document).
- Page 4 Parts List, continued Cables • Motor Cable 18inch (1) – Black cable with white, six-pin plugs. Use this cable to connect the Actuator to the Control Box. • Motor Cable 1m (1) – Black cable with white, six-pin plugs. Use this cable to connect the Actuator to the Control Box. •...
-
Page 5: Safety Information
Nexus 21 disclaims any liability for modifications, improper installations, or installations over the specified weight range. Nexus 21 will not be liable for any damages arising out of the use of, or inability to use, Nexus 21 products. Nexus 21 bears no responsibility for incidental or consequential damages. This includes, but is not limited to, any labor charges for the servicing of Nexus 21 products performed by anyone other than Nexus 21. - Page 6 Instructions for setting the Mount System travel limit are on Page 30. TIP: Planning to integrate the Mount with your UNIVERSAL REMOTE CONTROL? The RF version of the Nexus 21 controls won’t do it. Switch to IR. These are the parts included with RF controls: Backup Switch...
-
Page 7: Table Of Contents
Table of Contents Connecting the Mount Assembling the Mount Locating and Installing the Mount Attaching the TV to the Mount How to Set a Lower Limit How to Set the Tilt Vanity Plate Information Cable Management Information Maintenance... -
Page 8: Connecting The Mount
Connecting the Mount For these steps you will need the following parts: • Transcend Pro Mount • Control Box Mounting Plate • Control Box • (2) Motor Cables • Power Cord • Wired Backup Switch • CSI Control Kit or RF Control Kit •... - Page 9 Step 3: Connect the Wired Backup Switch to Port A1 on the Control Box. If you ordered the CSI Kit, connect the IR Receiver to Port A1 instead. Step 4: If you ordered the RF Kit, connect the RF Receiver to Port A2. If you ordered the CSI Kit, leave Port A2 empty.
-
Page 10: Assembling The Mount
Assembling the Mount For these steps you will need the following parts: • Screen Back Plate • Swivel Pivot Bolt • Swivel Pivot Nut • (2) Swivel Pivot Washers • Power Cord • Wired Backup Switch • CSI Control Kit or RF Control Kit Swivel Pivot Bolt Step 6: Attach the Screen Back Plate to the Mount using the Swivel Pivot Bolt, Swivel Pivot Nut, and (2) Washers using the diagram shown... -
Page 11: Locating And Installing The Mount
Step 9: Using the Mounting Template and tape, determine how high your mount needs to be located according to the [D] Shelf Depth measured in Step 8 and the below table. Note: The Transcend Pro Surface must always be able to lower its full travel with no obstructions. Step 8 Mount Height [H]... - Page 12 Location. Note: The Transcend Pro Surface can accommodate up to 16” Center Stud Spacing. For wider Stud Spacing, you can purchase the Extra Wall Support Accessory to accommodate up to 32” Stud Spacing. Step 11: Align the Mount with the Screw Locations on the Wall and Partially Fasten it to the Wall using (4) Lag Bolts.
-
Page 13: Attaching The Tv To The Mount
Attaching the TV to the Mount For these steps you will need the following parts: • Vertical Mounting Bars w/Washers & Screws • Assorted TV Hardware Pack Step 13: Attach Vertical Mounting Bars as high as possible to Back of the TV. This will ensure the most possible downward travel is obtained and that the mount is fully concealed when in the Top Position. - Page 14 Step 15: Fasten Vertical Mounting Bars to Screen Back Plate using the (2) Screws and (2) Washers that were fastened to each Vertical Mount Bar. Step 16: Test Run the Mount to ensure the Lower position does not interfere with the Shelf or Mantel below. Note: If needed a Lower Limit can be set.
-
Page 15: How To Set A Lower Limit
How to Set a Lower Limit Only the Lower Limit can be set on the Transcend Pro Surface, however it must be able to fully travel with no obstructions below it. This is because the Mount resets in the lowest position and will be unable to reset if it is obstructed. -
Page 16: How To Set The Tilt
How to Set the Tilt The Transcend Pro Surface has +/- 1 degree of Tilt in the Top Position, and +1/-2 Degrees in the Bottom and Out Positions. Below lists the steps on how to set the Tilt for each position. -
Page 17: Vanity Plate Information
Vanity Plate Information • The Vanity Plates and Plastic Clips are provided to cover the Controls and Outlets as well as any cables that are managed on the left and right of the system. • Each Vanity Plate is paintable and simply hooks over the Mount Lip as shown in the image below. •... -
Page 18: Cable Management Information
Cable Management Information • Wires can be routed through the wire routing holes and/or zip tied with the included zip ties as shown in the image below. Ensure enough slack remains so that the wires can freely move when the TV is swiveled left and right. -
Page 19: Maintenance
Maintenance To ensure the mount functions for the duration of its life. Please follow these simple procedures: 1. Lubricate all joints every 3 months. More lubrication may be required for outdoor installations. 2. Visually check all bolts every 3 months to ensure no unordinary noise or function occurs. - Page 20 866-500-5438...
