- Page 1 SM5c Product Manual English...
-
Page 2: Important Safety Instructions
Any malfunctions caused by unauthorized disassembly are not covered by the warranty. The user may pay for maintenance. We recommend only using the original Aputure or amaran cable accessories. Please note that any malfunc- tions caused by using unauthorized accessories are not covered by the warranty. The user may pay for maintenance. -
Page 3: Fcc Compliance Statement
SAVE THESE INSTRUCTIONS FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired opera- tion. -
Page 4: Product Details
CCT HSI HX Extension Strip light DC in strip light Connecting pin Connecting pin Power adapter *The amaran SM5c extension is sold separately. 2. Control box Data out Indicator light Microphone CCT/HSI/FX mode switch button Music mode/Bluetooth reset button Switch/WIFI reset button... - Page 5 Setting Up the Light Installing strip light 1. Choose a dry, clean and smooth surface to install the strip light. ✘ ✘ ✘ ✘ *Do not install strip light on surfaces such as fabric, dusty walls, rough plastic, and frosted glass. 2.
- Page 6 Powering up the Light 1. Connect the control box and the strip light. CCT HSI FX Strip light Control box 2. Connect the light strip and the extension light strip. Light strip and extension light strip are connected via connector Extension strip light Strip light...
-
Page 7: Operating The Light
WARNING Trimming of the light strip(s) should be avoided as it will result in a delayed boot-up process and certain Pixel FX will be incomplete, including Snake, Timing, Pinball, Clock, and Fuse. Operating the Light 1. Manual Control ON-OFF / Wi-Fi reset button: Short press the button to switch the strip light on and off, press and hold the button for three seconds to reset Wi-Fi connection. - Page 8 3.3 Open the "Tuya Smart" APP, and follow the instructions to add the SM5c strip light. After successfully connecting to the SM5c, you can control the strip light through the "Tuya Smart" APP.
- Page 9 4.1.2. Search for "Tuya Smart" in the search box, and then tap 4.1.3. Select the country your account belongs to and enter the account and password of your "Tuya Smart" account, and complete the linking process. - 8 -...
- Page 10 4.2.2. Search for "Tuya Smart" in the list and open it, enter your “Tuya Smart” App account and password, and to to complete the linking process. *To use smart voice control with the SM5c, customers must connect the fixture to a stable Wi-Fi network and a compatible smart speaker/smart assistant. Smart speakers must be purchased separately by the customer.
-
Page 11: Specification
5. Precautions 1) Do not use/turn on the strip light in the spool for long periods of time to avoid overheating and damage to the strip light. 2) The minimum bending diameter of the strip light is 5cm. Do not wrap the strip light around objects with a diameter of less than 5cm or fold the strip light in half. - Page 12 Trademarks ● Amazon Alexa is a trademark registered by Amazon Technologies, Inc. in China and other countries. ● Google Assistant is a trademark registered by Google LLC in China and other countries. ● Tuya is a trademark registered by Tuya Global Inc. in China and other countries. - 11 -...
