- Page 1 P60x Product Manual English...
-
Page 2: Important Safety Instructions
(3200 K - 6500 K), power of 60 W, and maximum illuminance of 5070 lux@1 m (5600 K). The P60x is also excellent in terms of light quality, with a color rendering index of up to CRI 95+, TLCI 97, and no flicker at all. - Page 3 The use of an accessory attachment not recommended by the manufacturer may increase the risk ofre, electric shock, or injury to any persons operating the fixture. Power this fixture by connecting it to a grounded outlet. Please do not place the LED lighting fixture near any flammable object. Only use a dry microfiber cloth to clean the product.
-
Page 4: Fcc Compliance Statement
FCC compliance statement This device complies with Part 15 of the FCC rules. The operating equipment must meet the following two conditions: (1) This device will not cause harmful interference; (2) This device can withstand any external interference, including interference that may cause unintended operation. [Warning] If the user makes changes or modifications without the express permission of Aitus, he may lose the right to continue to operate the device. - Page 5 Componets List amaran P60x 1/4 - 20 in & 3/8 - 16 in Spigot AC Power cable Softbox Adapter Grid Carrying case - 4 -...
-
Page 6: Product Details
Product Details Transparent protective baffle LED chips Softbox support handle NP-F battery slot 1/4 screw hole LIGHTING Mode Button Power Button EFFECTS Mode OLED Display Button CCT Wheel Menu Button DC Input INT Wheel - 5 -... -
Page 7: Installation
Installation 1. The lamp fixing Screw the 1/4’’ to 3/8’’ screw clockwise into the 1/4’’ copper nut at the bottom (or side) of the LED lamp, and tighten it;Connect the 1/4’’ to 3/8’’ screw and the lamp holder through the lamp holder support column, adjust the appropriate angle and tighten it. -
Page 8: Power Supply
Power supply 1. Adapter power supply AC 100 V - 240 V Bluetooth Mode Brightness Remaining Operating time When disassembling the power cable, please rotate the spring lock button on the power cable before disassembling, do not pull it hard. - 7 -... - Page 9 2. Lithium battery power supply * This product uses a lithium battery model Sony NP-F Series: NP - F 960 / F 970. Battery Installation: Slide the lithium Battery Removing: Press the battery battery into the battery slot. lock button while gently pushing up the battery to remove the battery.
- Page 10 1. Turning on the Light After connecting the lamp body to an appropriate power source, press the power switch to start the P60x. 2. Manual Control * The speed at which you rotate the knob will result in different rates of change.
- Page 11 2.1 Press the LIGHTING button to enter CCT mode to adjust the CCT and INT of the light. 2.2 Press the EFFECTS button, the default current light effect mode takes effect ( a total of four light effects: paparazzi, Strobe, fireworks, Pulsing ). Paparazzi Strobe Fireworks...
- Page 12 3. Menu introduction 3.1 Fan Mode Press the MENU button to enter the menu interface, rotate the INT wheel to select and press to enter the Fan mode, rotate the INT wheel to select the smart/medium mode, and then short press the INT wheel to confirm the selection.
- Page 13 3.5 Language Press the MENU button to enter the menu interface, rotate the INT wheel to select and press to enter the Language menu. You can rotate the INT wheel to select English or Chinese, and then press the Select wheel to confirm the selection.
-
Page 14: Specifications
4. Use of Sidus Link APP You can download the Sidus Link app from the iOS App Store or Google Play Store for enhancing the functionality of the light. Please visit sidus.link /app/help for more details regarding how to use the app to control your Aputure lights. -
Page 15: Trademark Statement
Photometrics Distance 0.5 m 17570 4860 1280 3200 K 1632 17670 4940 1283 4300 K 1642 18120 5070 1328 5600 K 1683 18410 5180 1354 6500 K 1710 * This is an averaged result. The luminance of your individual unit may vary slightly from this data Trademark statement Sony is a trademark and product model of Sony Corporation in China or... - Page 16 Aputure Imaging Industries Co., Ltd. warrants the original consumer purchaser from defects in material and workmanship for a period of one (1) year after the date of purchase. For more details of warranty visit www.aputure.com Serial No. Item Name Purchase Date Buyer Name Buyer Phone Buyer Add...
