UBio-X Face Premium User Guide
Version kor-1.0
Copyright 2000 By Union Community Co., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UBio-X Face Premium and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Union Community UBio-X Face Premium

Summary of Contents for Union Community UBio-X Face Premium

  • Page 1 UBio-X Face Premium User Guide Version kor-1.0 Copyright 2000 By Union Community Co., LTD.
  • Page 2 UBio-X Face Premium User Guide <Revison History> Version Date Description Firmware Version 2022-02-18 Initial Release UNIONCOMMUNITY Co., Ltd. Address: 12F, Munjeong Daemyeong Valeon bldg, 127 Beobwon-ro Songpa-gu, Seoul, Korea (zip code: 05836) Tel : 02-6488-3000 , Fax : 02-6488-3099, E-Mail :sales@unioncomm.co.kr...
  • Page 3 UBio-X Face Premium User Guide <Glossary>  Admin, Administrator - A user who can enter into the terminal menu mode, he/she can register/modify/delete terminal users and change the operating environment by changing settings. - If there is no administrator for a terminal, anyone can change the settings. In this regard, it is recommended to register at least one administrator.

  • Page 4: Table Of Contents

    UBio-X Face Premium User Guide Table of Contents <Revison History> ..................2 <Glossary> ....................3 Table of contents ..................4 1. Before use ....................7 1.1. Safety Precautions ..................7 1.2. Specific names of the terminal ..............8 1.3. Windows after operation ................9 1.3.1.
  • Page 5 UBio-X Face Premium User Guide 3.6. System ..................... 51 3.6.1. System ....................51 3.6.2. Fingerprint .................... 52 3.6.3. Face...................... 54 3.6.4. Auth ..................... 55 3.6.5. Set the current time................56 3.6.6. Database ....................57 3.6.6.1. Delete all users ................57 3.6.6.2.
  • Page 6 UBio-X Face Premium User Guide UNIONCOMMUNITY Co., Ltd. Address: 12F, Munjeong Daemyeong Valeon bldg, 127 Beobwon-ro Songpa-gu, Seoul, Korea (zip code: 05836) Tel : 02-6488-3000 , Fax : 02-6488-3099, E-Mail :sales@unioncomm.co.kr http://www.unioncomm.co.kr...

  • Page 7: Before Use

    UBio-X Face Premium User Guide 1. Before use 1.1. Safety Precautions Warning  Handling with wet hands or allowing liquid to flow Do not place a fire into it is prohibited. source near -> It may cause an terminal. electric shock ->...

  • Page 8: Specific Names Of The Terminal

    UBio-X Face Premium User Guide pecific names of the termin 1.2. S IR LED Dual camera Illumination sensor Touch LCD Card sensing area USB Input Speaker UNIONCOMMUNITY Co., Ltd. Address: 12F, Munjeong Daemyeong Valeon bldg, 127 Beobwon-ro Songpa-gu, Seoul, Korea (zip code: 05836) Tel : 02-6488-3000 , Fax : 02-6488-3099, E-Mail :sales@unioncomm.co.kr...

  • Page 9: Windows After Operation

    UBio-X Face Premium User Guide 1.3. Windows after operation Icon for network status ① Icon for door status ② A warning sign such as dismantling the terminal ③ Icon for illumination detection ④ Menu button Current time Camera video display...

  • Page 10: Messages

    UBio-X Face Premium User Guide None : Normal status ④ Tamper Switch : Tamper switch is activated. (Terminal is disassembled.) Door status is not sensed. : Door is closed. ⑤ Door Status : Door is opened. : Door is opened abnormally : LAN cable is not connected.
  • Page 11 UBio-X Face Premium User Guide - When authentication is failed - When unregistered user ID is entered - When unregistered card is entered - Passback error when using anti-passback function - When using for meal management When a user tried the authentication more than twice in one meal time when using as meal management UNIONCOMMUNITY Co., Ltd.
  • Page 12 UBio-X Face Premium User Guide When server does respond during authentication attempt to the server When network disconnected during authentication attempt to the serve - Registration without authentication right or authentication attempt when the entrance is not permitted - When the user is designated in the blacklist...
  • Page 13 UBio-X Face Premium User Guide - The waiting status for the input of user ID - The waiting status for the input of password - The waiting status for the input of fingerprint UNIONCOMMUNITY Co., Ltd. Address: 12F, Munjeong Daemyeong Valeon bldg, 127 Beobwon-ro Songpa-gu, Seoul, Korea (zip code: 05836) Tel : 02-6488-3000 , Fax : 02-6488-3099, E-Mail :sales@unioncomm.co.kr...
  • Page 14 UBio-X Face Premium User Guide - The waiting status for the input of card - When the terminal program is being upgraded (In this state, you should not turn off the terminal.) If the elevated skin temperature is less than 37.5℃, it shows the ‘Success’...
  • Page 15 UBio-X Face Premium User Guide f the user doesn’t wear the mask properly, this message is shown. Ex) If the user wears the mask under the nose The waiting status to measure the user’s temperature If the user is out of the temperature checking area, this message is shown.

  • Page 16: Voice Sounds In Operation

    UBio-X Face Premium User Guide 1.4. Voice sounds in operation Operation type Voice sound Success to authorize You are authorized. Fail to authorize Please try again. 1.5. Beep sound in operation Notice When the card was read for reading Pick...
  • Page 17 UBio-X Face Premium User Guide - Do not install under the light bulb. - Not recommended in the circumstance of backlight or direct light Proper fingerprint registration and input methods 1.7. Correct fingerprint registration methods  Place your index finger on the window just as you do with a finger stamp.

  • Page 18: Product Introduction

    UBio-X Face Premium User Guide use a password instead in this case.  When a finger is dry, breathe on the finger for smooth operation.  For kids, it may be tricky or impossible to use the terminal because their fingerprints are too small or very unclear.
  • Page 19 UBio-X Face Premium User Guide Password Password registration Password authentication Card Card, fingerprint registration or Fingerprint Card or fingerprint authentication Fingerprint authentication after ID input Card & Fingerprint Card, fingerprint registration Fingerprint authentication after card authentication ID input > Card authentication > Fingerprint authentication...
  • Page 20 UBio-X Face Premium User Guide Card Card, fingerprint, face registration or Fingerprint Card or fingerprint or face authentication or Face ID input > Fingerprint authentication > if failed. Face authentication Card Card, fingerprint, and password registration & Fingerprint Fingerprint password...

  • Page 21: Product Components

    UBio-X Face Premium User Guide 2.2. Product components 2.2.1. Standalone use(Access) DC15V Adapter Electric lock (Lock+, Lock-, Monitor) 2.2.2. Connected with Server (Access, Attendance, Meal management) TCP/IP TCP/IP TCP/IP Fingerprint authentication Internet / server (Static IP) WAN / LAN UDB server...

  • Page 22: Product Specification

    UBio-X Face Premium User Guide 2.3. Product specification Types SPEC REMARK 1GHz Quad Core CPU 5.0 inch Touch LCD(480*800) 16G Bytes Flash MEMORY 2GBytes RAM External SD Card Backup data / FW upgrade Support Camera Dual Camera (Color & IR) 100,000 User / 100,000 Card 100,000 Finger (1:N1:100,000)

  • Page 23: Environment Setting

    UBio-X Face Premium User Guide SIZE 88.0mm * 175.0mm * 43.4mm 3. Environment setting 3.1. Checks before setting the environment 3.1.1. Entering the menu If you click the [ ]] icon at the basic window, you can enter the main menu window as follows.

  • Page 24: How To Enter The Menu Without Administrator Authentication

    UBio-X Face Premium User Guide ▶ Administrator authentication If you enter the administrator ID, the administrator authentication fulfilled along with authentication method of the administrator such as card, face, or password. The administrator authentication only appears when registered administrator exists.
  • Page 25 UBio-X Face Premium User Guide 3.1.4. How to save the set values If you click the [Complete] button at each menu to save the changed value after the change of settings, the set value of the window is saved and the following message box appears.

  • Page 26: Menu Composition

    UBio-X Face Premium User Guide 3.2. Menu composition 1. User 1. Add 2. Modify 3. Delete 4. Delete All 5. View 2. Network IP address Static IP / DHCP ▶IP address ▶Subnet Mask ▶Gateway ▶DNS server1 ▶DNS server 2 Server IP ▶Server IP...

  • Page 27: System

    UBio-X Face Premium User Guide 4. System 1. System ▶ User ID length [2~8] ▶ Authentication: Terminal/Server, Terminal Only ▶ Mandatory Registration □Face □Finger print □Card □Password □Name 2. Finger ▶1:N Level [3~9] ▶1:1 Level [1~9] ▶ Fake Finger Detection ▶...

  • Page 28: Input

    UBio-X Face Premium User Guide 3. Input ▶M0 ▶M1 ▶M2 ▶IO ▶ Warn door open (sec) □ Tamper alarm 4. Lock ▶Lock1 Option ▶Lock2 Option ▶Lock1 duration (ms) ▶Lock2 duration (ms) 5. External Device ▶RS232 ▶RS485 ▶Wiegand Site Code Wiegand Output Wiegand Input 6.

  • Page 29: User

    UBio-X Face Premium User Guide 3. Network ▶ Network Info <Ethernet> 4. User ▶ User 5. Log ▶ Log 6. About ▶About 8. SD Card 1. Export 1. User Data 2. Event Log 3. System Option 4. Export All 5. Picture 2.
  • Page 30 UBio-X Face Premium User Guide 3.3.1. Add If you select [User] -> [Add] in the main menu, the following screen appears Input the user ID to be registered and click [OK] button. In this case, the ID which can be registered is shown on the screen automatically, so you can register conveniently.
  • Page 31 UBio-X Face Premium User Guide ※ Only user who is registered as administrator can change the operating method of the terminal and can register/modify/delete the information of all the saved users, so be careful to register the administrator. 3.3.1.1. Photo registration...
  • Page 32 UBio-X Face Premium User Guide 3.3.1.3. Fingerprint registration ① Register by clicking [Fingerprint] button at the [Add User] screen. Click [ ] button to cancel the registration and return. Choose the finger to be registered when the left screen appears.
  • Page 33 UBio-X Face Premium User Guide ② ‘Enter the fingerprint with referring ‘1.7 Proper fingerprint registration and input methods’. Enter the fingerprint twice according to the screen instruction as follows. When the light is turned on at the fingerprint sensor with the message ‘Register FP’, put your finger on the input screen and wait for 2~3 seconds until the light is turned off.
  • Page 34 UBio-X Face Premium User Guide If it is similar with the fingerprint already registered, the message “Already registered finger!” appears like the left side, and you can start again from the procedure of ② if you click the [Retry] button.
  • Page 35 UBio-X Face Premium User Guide 3.3.1.4. Face Registration ‘Register with referring ‘1.6. How to register and authorize the face properly’. ① As shown on the left screen, align the red guide that recognizes the face with the center of blue outline and register.
  • Page 36 UBio-X Face Premium User Guide ③ When the registration is ended, ‘Completed!’ message is shown on the screen. If you click [OK] button, the face registration is completed and the screen is moved to the previous screen. If you want to register again, click [Start] button to start from the procedure of ②.
  • Page 37 UBio-X Face Premium User Guide 3.3.1.5. Password registration If you enter the password in 1~8 characters into the password input window and click [OK] button, the input focus is moved to the ‘password confirm’ window at below. Enter the same password again and click [OK]...
  • Page 38 UBio-X Face Premium User Guide 3.3.1.6. Card registration Register with clicking [Card] button in the [Add User] button. Click [ ] button to cancel and return. ※If you entered the card already registered, the following message appears. ※If a user tried over than 10 registrations, the following message appears UNIONCOMMUNITY Co., Ltd.

  • Page 39: Authentication

    UBio-X Face Premium User Guide 3.3.1.7. Authentication option ▶’FP Level’ (Basic setting: ’0’) It decides the fingerprint authentication level of each user, and the registered users can have different authentication level by modifying this value. If you set ‘0’, the authentication uses the level of fingerprint authentication.
  • Page 40 UBio-X Face Premium User Guide Password, it will be limited 2 authentication methods) 3.3.1.9. Save Click the [Save] button to save when all the registration procedure is finished. At this point, if you click [Cancel] or [BACK] button to return, the user is not saved.
  • Page 41 UBio-X Face Premium User Guide In [Register FP], the case you tried to registered the fingerprint already registered. (But, you can input the same fingerprint with the same user ID). ※ If you want to register the same fingerprint in the different ID, you should uncheck the ‘System →...
  • Page 42 UBio-X Face Premium User Guide When it is deleted normally. When unregistered ID was entered 3.3.3. Modify The following window appears if you click the [User]  [Modify] in the main menu Input the user ID to be modified and click [OK] button.
  • Page 43 UBio-X Face Premium User Guide The icons at the left side means as follows. : The number of registered faces : The number of registered fingerprints (X,1~10) : Existence of password registration (X: Not registered, 1: Registered) : The number of registered cards (X,1~10)
  • Page 44 UBio-X Face Premium User Guide 3.3.5. View If you click the [User]  [View] in the main menu, all the users registered can be searched as follows The user list appears by the order of ID, and if you slide the screen upward, you can search the additional user list.
  • Page 45 UBio-X Face Premium User Guide ▶ [Name] : If you input the user name by clicking [Name] button, the registered user list including the characters is shown. If you click [BACK] button in this window, you can move to the ‘3.3. User management’ menu.
  • Page 46 [BACK] button. ▶[Wi-Fi] When the Wi-Fi dongle is connected to the USB port on backward of the UBio-X Face Premium device, this icon [ ] will be come up automatically on the Network screen as same as left picture.
  • Page 47 UBio-X Face Premium User Guide When the check box [Wireless Enabled] was checked, the AP list around will be scanned automatically as like the left picture. Selecting the AP name from the AP list, the AP password will be asked and then UBio-X Face Premium device will be connected to this AP when inputting the proper AP password.
  • Page 48 UBio-X Face Premium User Guide It is the screen appearing when you select the [TnA]. Click the [OK] button to apply the changes, and click [BACK] button to cancel and return ▶ Schedule (00:00~23:59): You can set the time for each authentication mode and if you do not need the function, set ’00:00-00:00’.
  • Page 49 UBio-X Face Premium User Guide 3.5.1.2. Meal setting It is the screen appearing when selecting the meal Management. You can set the time period of each meal type. And if the setting is not needed, set ‘00:00-00:00’. ▶ Allow duplicate: If it is unchecked (...
  • Page 50 UBio-X Face Premium User Guide Click the [OK] button to apply the changes, and click [BACK] button to cancel and return. ▶ If you select button, you can see the added access mode as you set in ‘Extended Key’. And if you select among F1 to F4, it changes into the selected authentication mode.
  • Page 51 UBio-X Face Premium User Guide 3.6. System 3.6.1. System The following window appears if you select the [System]  [System] in the main menu. ▶ Basic setting: Same with the window at the left side ▶ User ID Length It sets the length of the user ID, and it can be 2~8 characters and should be the same with the length of the registered ID of the server program.

  • Page 52: Fingerprint Authentication

    UBio-X Face Premium User Guide 3.6.2. Finger The following screen appears if you select the [System]  [Finger] in the main menu. ▶ Basic setting: Same with the window at the left side ▶1: N Level (3~9) It is the authentication level used in the 1:N Fingerprint authentication.
  • Page 53 UBio-X Face Premium User Guide If you click the [OK] button, the new format is applied, and if you click the [Cancel] button, the format value before the change is maintained. ※ Notes If you change the fingerprint template format, all the registered fingerprints are deleted, so be cautions.
  • Page 54 UBio-X Face Premium User Guide 3.6.3. Face ▶ Basic setting: Same with the window at the left side ▶Matching level It is the level used in face authentication, and it can be set 1~4 levels according to the accordance degree with the registered face. And the authentication is successful when the accordance degree is higher than set authentication level.
  • Page 55 UBio-X Face Premium User Guide improve the symptom. Click [OK] button to apply the set value, and click [BACK] button to cancel and return. If you click [OK] button without changing the set value, it is moved to the upper menu automatically.
  • Page 56 UBio-X Face Premium User Guide authenticate. - Fingerprint: Though the user is registered with the authentication method requiring the card, face, or password in addition to the fingerprint, the terminal with the checking of the item, the fingerprint can authorize by itself. For fingerprint, face or...
  • Page 57 UBio-X Face Premium User Guide - dd-mmm-yyyy: Order of date, month (English), and year ▶ Set Date / Set Time It changes the present time of the terminal. If the server is connected and the [Time synchronization] is set [Auto], you don’t have to change since it is synchronized with the server time.
  • Page 58 UBio-X Face Premium User Guide If you want to delete all users, click [YES] button, and if you want to cancel, click [NO] or [X] button. If there is no signal for 5 seconds in this state, the message box disappears without deletion.
  • Page 59 UBio-X Face Premium User Guide If you want to delete all the authentication record in the terminal, click [YES] button, and if you want to cancel, click the [NO] or [ ] button. If there is no signal for five seconds in this state, the message box disappears without deletion.
  • Page 60 UBio-X Face Premium User Guide If you want to initialize the terminal in the factory setting, click [YES] button, and if you want to cancel, click [NO] or [ ] button. If there is no signal for five seconds in this state, the message box disappears without initialization.
  • Page 61 UBio-X Face Premium User Guide 3.7. Terminal 3.7.1. Sound If you select the [Terminal]  [Sound] in the main menu, the following window appears. ▶ Basic setting: Same with the window at the left side ▶ Voice volume Scroll from side to side in 0~15 degrees to set the voice volume.
  • Page 62 UBio-X Face Premium User Guide 3.7.2. Option If you select the [Terminal]  [Option] n the main menu, the following window appears. ▶Basic setting: Same with the window at the left side ▶Read Card number If the user put the card on the screen, the card number is displayed on the LCD.
  • Page 63 UBio-X Face Premium User Guide 10 Digit Decimal 1386022627 hexadecimal 529D06E3: 10 digits decimal 3,5 Digit Decimal 3808861522 hexadecimal E3069D52: 10 digits decimal 6 Digit Hexadecimal 069D52 Locate the foremost 3bytes backwards Click [OK] button to apply the set value, and click [BACK] button to cancel and return.
  • Page 64 UBio-X Face Premium User Guide sensor is connected. - Emergency detection NO or emergency detection NC’: When the emergency situation detection sensor is connected.  Set NO/NC according to the state of pin input in detection. ▶IO: Set when connecting the external access point to the Exit pin.
  • Page 65 UBio-X Face Premium User Guide 3.7.4. Lock If you select the [Terminal]  [Lock] in the main menu, the following windows appears. ▶ Basic setting: Same with the window at the left side.A ▶Lock1 Option - None: When it is not used Strike/Auto/OK: When the warning light is connected to indicate the strike type, auto door, or authentication success/failure on Lock1.
  • Page 66 UBio-X Face Premium User Guide Because it is set in ms unit, if you want to set 3 seconds, you should set 3000. Click [OK] button to apply the set value, and click [BACK] button to cancel and return. 3.7.5. External Device If you select [Terminal] ...
  • Page 67 UBio-X Face Premium User Guide ▶ Site code It sets the site code value sent in Wiegand output below. ▶Wiegand Output It is used only when the special controller is equipped running by the Wiegand input. When the authentication is finished, the data of the following format is sent to the Wiegand port of the terminal.
  • Page 68 UBio-X Face Premium User Guide Thermal 3.7.6. ETC. ( This product is an additional device to primarily check whether or not the skin temperature rises for unspecified people. Since it is possible to quickly check whether the skin surface temperature of the test target...
  • Page 69 UBio-X Face Premium User Guide ▶ thermal_mode Thermal mode Details authentication elevated skin Reguser temperature detection only for registered users authentication elevated skin UnReguser temperature detection for both registered and unregistered users. For registered and unregistered users, a phone number input window appears after detecting UnReguser+Phonenum the elevated skin temperature.
  • Page 70 UBio-X Face Premium User Guide ▶ Temperature around Temperature around Details Normal If your environment has the normal temperature, use ‘Normal’ High If your environment has the high temperature, use ‘High’ If your environment has the low temperature, use ‘Low ▶...
  • Page 71 UBio-X Face Premium User Guide For the registered user, it checks the user’s temperature and shows the temperature with the authentication success message. For this, it should set [Reguser] from [thermal mode]. For the unregistered user, it checks the users’...
  • Page 72 UBio-X Face Premium User Guide 3.8. Display 3.8.1. Theme If you select [Display]  [Theme] in the main menu, the following window appears. ▶ Basic setting: Same with the window at the left side. ▶ Background Since the camera is basically displayed, it is not available to select the background.
  • Page 73 UBio-X Face Premium User Guide 3.8.2. Camera If you select the [Display]  [Camera] in the main menu, the following window appears. ▶Basic setting: Same with the window at the left side ▶Display Option Select the image displayed in the message window...
  • Page 74 UBio-X Face Premium User Guide 3.8.3. Language If you select the [Display]  [Language] in the main menu, the following window appears. ▶Basic setting: ‘English’ ▶Language If you change the language and click ‘OK’ button, the voice message and language are changed to the set language.
  • Page 75 UBio-X Face Premium User Guide 3.8.4. Option If you select the [Display]  [Option] in the main menu, the following window appears. ▶ Basic setting: Same with the window at the left side ▶ Power saving mode (5sec ~ 10min) If there is no input for set duration, the LCD screen is turned off automatically.
  • Page 76 UBio-X Face Premium User Guide ▶ Basic setting: Same with the window at the left side ▶ Message Display (ms) It sets the time for which the authentication result window to be displayed. 0~5000 is available for the value, and the...
  • Page 77 UBio-X Face Premium User Guide 3.9. System 3.9.1. System If you select the [Terminal info]  [System] in the main menu, the following window appears. ▶System info The hardware and firmware version of terminal is shown ▶Ram (using size / Total size) The using size of RAM among the all size is represented.
  • Page 78 UBio-X Face Premium User Guide 3.9.2. Terminal If you select the [Terminal info]  [Terminal] in the main menu, the following window appears. ▶ Terminal info It represents the option setting value of the terminal. Click [Close] or [BACK] button to finish the inquiry and move to the upper menu.
  • Page 79 UBio-X Face Premium User Guide ▶ Network info It shows the setting value of the terminal. If you want to finish the inquiry and move to the upper menu, click [CLOSE] or [BACK] button. 3.9.4. User If you select the [Terminal info]  [User] in the main menu, the following window appears.
  • Page 80 UBio-X Face Premium User Guide 3.9.5. Log If you select the [Terminal info]  [log] in the main menu, the following window appears. ▶ Log Log: The number of logs saved in the terminal Image Log: The number of logs saved in the...
  • Page 81 UBio-X Face Premium User Guide ▶ View Log Log search result shows the information such as the date, time, ID and access result (success or failure). Click [BACK] or [NEXT] button to see the search information. If you want to finish the inquiry and move to the upper menu, click [Close] or [BACK] button.
  • Page 82 UBio-X Face Premium User Guide 3.10. USB If you select the [USB] at the main menu, the following screen appears. < When USB is inserted> < When USB is not inserted> ※ Work can only be done when USB is inserted, and the back side must be inserted forward as shown in the picture below.
  • Page 83 UBio-X Face Premium User Guide It is the feature to back up the data of the terminal via [Export]. You can copy the back-up data to the terminal via [Import] ▶ Export It copies the data from the terminal to the external USB.
  • Page 84 UBio-X Face Premium User Guide - Picture: The image log data is saved in the folder ‘UbioXfacePremium / Terminal ID (8 digits) / log / pictures’ in USB as jpg file. - Export all: It can export all things User Data, Event Log, and image log to USB.
  • Page 85 UBio-X Face Premium User Guide 3.11. Download the user file It is a function that allows the user to change the voice message if necessary. You can copy using USB or download and change user files from the server program.
  • Page 86 UBio-X Face Premium User Guide 4. How to use terminal The background image and composition of the basic window can be changed according to the administrator’s setting. In addition, if the administrator set the screen saver time, the LCD screen is turned off automatically if there is no action for set time, and when the user accessed to the terminal, tried the authentication with card, or touched the main screen, the LCD screen is turned on automatically.
  • Page 87 UBio-X Face Premium User Guide 4.2. How to input user ID If you click the button [ID] on the basic window, following the window “Input User ID” as below Enter the user ID to be certified and click [OK] button, then the input screen of face, card, or password depending on the authentication method of the user.
  • Page 88 UBio-X Face Premium User Guide   4.3.2. Fingerprint authentication ▶1:N authentication (Identification) If you put your fingerprint on the fingerprint sensor at the basic window, the fingerprint is entered with the light on the sensor with beeping. Do not take off your finger until the light of the sensor turns off completely.

  • Page 89: Card Authentication

    UBio-X Face Premium User Guide   4.3.3. Card authentication Place the card on the card picture <Fig. 4-1>. 4.3.4. Password authentication Input your ID by clicking [ID input] button as follows and input password when the password input window appears ...
  • Page 90 UBio-X Face Premium User Guide ▶ Duress password authentication. When entering a password, entering the registered password in reverse order will inform the administrator that the authentication is successful, but it is an attempt to authenticate the duress in the same way as the duress fingerprint.
  • Page 91 UBio-X Face Premium User Guide FCC compliance information Virdi / UBio-X Face Premium FCC Information This device complies with part 15 of the FCC Results. Operation is subject to the following two conditions : (1) This Device may not cause harmful interface, and (2) This device must accept any interference received, including interference that may cause undesired operation.
