- Page 1 Multi-Wrist Shaker Model No. 3589 3589-1CE 057-621-00 • 3/13/08...
-
Page 2: Table Of Contents
Table of Contents Safety Information ................................3 Alert Signals ................................3 Warnings................................3 Description..................................5 Specifications ................................6 Electrical Requirements ............................6 Shaking Speed ..............................6 Maximum Load ..............................6 Dimensions ................................6 Shipping Weight ..............................6 Declaration of Conformity ............................7 Unitʼs Environmental Operating Conditions ......................7 Unpacking and Installation ............................8 Shipping Carton ..............................8 Installing Side Arms ..............................8 Tri-Grip Clamps ..............................9... -
Page 3: Safety Information
Safety Information Alert Signals Your Thermo Scientific Lab-Line Multi-Wrist Shaker has been designed with function, reliability and safety in mind. It is your responsibility to install it in conformance with local electrical codes. For safe operation, please pay at- Warning tention to the alert signals throughout the manual. - Page 4 AFETY NFORMATION To eliminate hazard of electrical shock, make sure floor around machine is dry in the event of accidental spilling or splashing of liquids, clean up and/or neutralize the spilled liquids before continuing. Do not use equipment for other than its intended purpose.
-
Page 5: Description
Description The Lab-Line Model 3589 Multi-Wrist Shaker is a general- purpose laboratory shaker designed to simulate hand mixing. Its action can be varied from a gentle swishing motion to vigorous agitation. The shaking arms (ordered separately) rotate through an arc of less than 2 degrees to produce a great deal of torque using very little power. -
Page 6: Specifications
Specifications Electrical Requirements 3589: 120 Volts, 60 Hz, 65 Watts, 0.5 Amps 3589-1CE: 220/240 Volts, 50/60 Hz, 30 Watts, 0.4 Amps Shaking Speed 30-750 rpm (speed range is dependent on weight of glassware and contents) Maximum Load 10 lbs. (4.5 kg) -
Page 7: Declaration Of Conformity
PECIFICATIONS Declaration of Conformity (for CE models only) We hereby declare under our sole responsibility that this product conforms with the technical requirements of the following standards: EMC: EN 61000-3-2 Limits for harmonic current emissions EN 61000-3-3 Limits for voltage fluctuations and flicker EN 61326-1 Electrical equipment for measurement, control, and laboratory use;... -
Page 8: Unpacking And Installation
Unpacking and Installation Shipping Carton The shipping carton should be inspected upon delivery. When received, carefully examine for any shipping dam- age before unpacking. If damage is discovered, the deliv- ering carrier should both specify and sign for the damage on your copy of the delivery receipt. -
Page 9: Tri-Grip Clamps
NPACKING AND NSTALLATION Tri-Grip Clamps The side arms are shipped with the tri-grip clamps already mounted. In the event that the clamps need to be removed, note that they are mounted to the side arms by a single setscrew on the bottom of the side arm and that a sequence of assembly is followed. -
Page 10: Electrical Connection
NPACKING AND NSTALLATION Electrical Connection Model 3589 requires a 120V, 60 Hz power source. It is supplied with a 3-wire line cord. It should be connected to an outlet designed for 3-prong plugs. If an extension cord is used, it also should be the 3-wire grounded type. -
Page 11: Operation
Operation Warning Do not use in the presence of flam- mable or combustible materials or explosive gases. Do not use in the Metal Tab presence of pressurized or sealed containers—fire or explosion may result, causing death or severe injury. Note Depress metal tab prior to rotating knob—the tab fixes knob setting and prevents inadvertent motion of the... -
Page 12: In Case Of Electrical Overload
PERATION Set the timer for the desired time period (up to one hour) or turn counterclockwise to CONSTANT posi- tion for continuous shaking. Note In order to overcome initial inertia of the load, turn Depending on load, this may be the speed control to point where shaking just starts. -
Page 13: Maintenance
Maintenance A Multi-Wrist Shaker requires regular inspection for loose clamps, side arms and accessories. Every 6 months an Warning examination should be made of the motor brushes for Disconnect from the power supply wear. Because it has sealed ball bearings, the motor prior to maintenance and servicing. -
Page 14: Replacement Parts
227-841-00 Speed Control, 240V: 229-419-00 Knob: 560-223-00 Knob, Locking Tab: 600-125-00 Line Filter: 330-345-00 Motor – 1/17 hp (3589): MT1473X1 Motor – 1/17 hp (3589-1CE): MT1473X2 Status Lamp Base: 360-249-01 Status Lamp Lens, Green: 360-238-00 Setscrew, 1/4-20 x 3/8": 566-301-00... -
Page 15: Ordering Procedures
Ordering Procedures Please refer to the Specification Plate for the complete model number, serial number, and series number when requesting service, replacement parts or in any corre- spondence concerning this unit. All parts listed herein may be ordered from the Thermo Scientific dealer from whom you purchased this unit or can be obtained promptly from the factory. -
Page 16: Two Year Limited Warranty
(ii) misuse (including use inconsistent with written operating instructions for the product), mishandling, contamination, overheating, modification or alteration of the product by any customer or third party or (iii) use of replacement parts that are obtained from a party who is not an authorized dealer of Thermo Scientific prod- ucts.
