- Page 1 B2SC1-CPU USER’S MANUAL Revision 1.0...
- Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
- Page 3 It provides information for the installation and use of the B2SC1-CPU motherboard. About This Motherboard The B2SC1-CPU motherboard supports an Intel® Xeon E-2100, 8th Gen Core i3, Pentium, and Celeron processor in an LGA1151 socket. This motherboard provides maximum performance,...
- Page 4 Super B2SC1-CPU User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
-
Page 5: Table Of Contents
Table of Contents Table of Contents Chapter 1 Introduction 1.1 Checklist ..........................8 Quick Reference Table ......................11 Motherboard Features .......................12 1.2 Processor and Chipset Overview ..................15 1.3 Special Features ........................15 Recovery from AC Power Loss ..................15 1.4 System Health Monitoring ....................16 Onboard Voltage Monitors ....................16 Fan Status Monitor with Firmware Control ...............16 Environmental Temperature Control .................16... - Page 6 Super B2SC1-CPU User's Manual Installing the Motherboard into the Mounting Tray ............27 Installing the Motherboard into the Microblade Chassis ...........28 2.5 Connectors .........................29 2.8 Jumper Settings .........................34 How Jumpers Work ......................34 2.9 LED Indicators ........................39 Chapter 3 Troubleshooting 3.1 Troubleshooting Procedures ....................40 Before Power On ......................40...
- Page 7 Table of Contents...
-
Page 8: Chapter 1 Introduction
Introduction Congratulations on purchasing your computer motherboard from an acknowledged leader in the industry. Supermicro boards are designed with the utmost attention to detail to provide you with the highest standards in quality and performance. Please check that the following items have all been included with your motherboard. If anything listed here is damaged or missing, contact your retailer. - Page 9 Chapter 1: Introduction Figure 1-1. B2SC1-CPU Motherboard Image Note: All graphics shown in this manual were based upon the latest PCB revision available at the time of publication of the manual. The motherboard you received may or may not look exactly the same as the graphics shown in this manual.
- Page 10 Super B2SC1-CPU User's Manual Figure 1-2. Motherboard Layout (not drawn to scale) JPG1 JPME2 JPME2 JPG1 JKVM1 JDBG2 JPME1 JPME1 JKVM1 JBR1 JBR1 M.2-H SRW2 BMC_HB_LED1 BMC_HB_LED1 SRW2 SRW1 SRW1 BAR CODE JSD1 MAC CODE JSD1 JTPM1 I-SATA1 JBT1 BIOS LICENSE...
-
Page 11: Quick Reference Table
Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBR1 BIOS Recovery Pins 1-2 (Enable) JBT1 CMOS Clear Open (Normal) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPME1 ME Recovery Pins 1-2 (Enable) JPME2 Manufacturing Mode Pins 1-2 (Normal) JWD1 Watch Dog Timer Pins 1-2 (Reset) Connector... -
Page 12: Motherboard Features
Super B2SC1-CPU User's Manual Motherboard Features Motherboard Features • Supports an Intel Xeon E-2100, 8th Gen Core i3, Pentium, and Celeron processor in an LGA1151 socket. Memory • Supports up to 64GB of Very Low Profile (VLP) ECC UDIMM DDR4 memory with speeds of up to 2666MHz in four slots. - Page 13 Chapter 1: Introduction Motherboard Features System Health Monitoring • Onboard voltage monitoring for +1.8V, +3.3V, +3.3V Stdby, +5V, +5V Stdby, +12V, VBAT, HT, Memory • 6+2 CPU switching phase voltage regulator • CPU Thermal Trip support System Management • Trusted Platform Module (TPM) support •...
- Page 14 Super B2SC1-CPU User's Manual Figure 1-3. B2SC1-CPU System Block Diagram SVID IMVP8 IMVP8 INTEL LGA1151 SATA-III DDR4 (CHA) 6Gb/s DIMMA0 PCIe3.0x4 PCIe3.0_x12 2666MHz DIMMA1 (Socket-H4) 8.0GT/s 8.0GT/s SATA-III DDR4 (CHB) DIMMB0 6Gb/s 2666MHz PCIe3.0x4 DIMMB1 8.0GT/s x4 DMI 8GT/s SATA-III...
-
Page 15: Processor And Chipset Overview
64GB DDR4 Very Low Profile UDIMM memory support with speeds of up to 2666MHz 1.3 Special Features This section describes the health monitoring features of the B2SC1-CPU motherboard. The motherboard has an onboard System Hardware Monitor chip that supports system health monitoring. -
Page 16: System Health Monitoring
Super B2SC1-CPU User's Manual 1.4 System Health Monitoring Onboard Voltage Monitors The onboard voltage monitor will continuously scan crucial voltage levels. Once a voltage becomes unstable, it will give a warning or send an error message to the screen. The user can adjust the voltage thresholds to define the sensitivity of the voltage monitor. -
Page 17: Acpi Features
Chapter 1: Introduction 1.5 ACPI Features ACPI stands for Advanced Configuration and Power Interface. The ACPI specification defines a flexible and abstract hardware interface that provides a standard way to integrate power management features throughout a computer system including its hardware, operating system, and application software. -
Page 18: Chapter 2 Installation
Super B2SC1-CPU User's Manual Chapter 2 Installation 2.1 Static-Sensitive Devices Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid damaging your motherboard and your system, it is important to handle it very carefully. The following measures are generally sufficient to protect your equipment from ESD. -
Page 19: Processor And Heatsink Installation
CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. Installing the LGA1151 Processor 1. Press the load lever down to release the load plate from its locking position. - Page 20 Super B2SC1-CPU User's Manual 2. Gently lift the load lever to open the load plate. Remove the plastic protective cover. Do not touch the CPU socket contacts. 3. Locate the triangle on the CPU and CPU socket, which indicates the location of Pin 1.
- Page 21 Chapter 2: Installation 5. Close the load plate, then gently push down the load lever into its locking position. CPU properly installed Load lever locked into place Note: You can only install the CPU in one direction. Make sure it is properly inserted into the socket before closing the load plate.
-
Page 22: Installing A Passive Cpu Heatsink
Super B2SC1-CPU User's Manual Installing a Passive CPU Heatsink 1. Do not apply any thermal grease to the heatsink or the CPU. The required amount has already been applied. 2. Place the heatsink on top of the CPU so its mounting holes align with the mounting holes on the motherboard. -
Page 23: Removing The Heatsink
Chapter 2: Installation Removing the Heatsink Note: We do not recommend that the CPU or the heatsink be removed. However, if you do need to remove the heatsink, follow the instructions below to prevent damage to the CPU or the socket. 1. -
Page 24: Memory Support And Installation
2.3 Memory Support and Installation Memory Support The B2SC1-CPU motherboard supports up to 64GB of DDR4 ECC UDIMM with speeds of up to 2666MHz in four slots. Populating the DIMM slots with a pair of memory modules of the same type, speed and size will result in interleaved memory, which improves performance. -
Page 25: Dimm Installation
3. Align the key of the DIMM module with the receptive point on the memory slot. 4. Align the notches on both ends of the module against the receptive points on the B2SC1-CPU REV:1.00 ends of the slot. DESIGNED IN USA 5. -
Page 26: Motherboard Installation
Super B2SC1-CPU User's Manual 2.4 Motherboard Installation All motherboards have standard mounting holes to fit different types of chassis. Make sure that the locations of all the mounting holes for both the motherboard and the chassis match. Although a chassis may have both plastic and metal mounting fasteners, metal ones are highly recommended because they ground the motherboard to the chassis. -
Page 27: Installing The Motherboard Into The Mounting Tray
Chapter 2: Installation Installing the Motherboard into the Mounting Tray 1. Locate the mounting holes on the motherboard and the mounting tray. Refer to the previous page for the mounting holes. 2. Install the standoffs on the mounting tray. Align the mounting holes on the motherboard against the mounting holes on the tray. -
Page 28: Installing The Motherboard Into The Microblade Chassis
Super B2SC1-CPU User's Manual Installing the Motherboard into the Microblade Chassis 1. When the motherboard is securely installed on the mounting tray, push the tray into the Microblade chassis as shown below. 2. Once the mounting tray is pushed in the chassis, the connectors on the motherboard's edge will make contact with the chassis' backplane, which provides the connections to the chassis power, network, and other I/O devices. -
Page 29: Connectors
Pin Definitions Pin# Definition Ground Ground 1. KVM Connector JPME2 JPG1 2. SATA DOM Power JKVM1 JDBG2 JPME1 JBR1 M.2-H BMC_HB_LED1 SRW1 SRW2 BAR CODE MAC CODE JSD1 JBT1 BIOS LICENSE JDBG1 JWD1 I-SATA1 B2SC1-CPU REV:1.00 DESIGNED IN USA JVR1... - Page 30 SSD devices. I-SATA 3.0 Port The B2SC1-CPU has one I-SATA 3.0 port (I-SATA1). The port can be used with Supermicro SuperDOMs that are yellow SATA DOM connectors with power pins built in, and do not require external power cables. Supermicro SuperDOMs are backward compatible with regular SATA HDDs or SATA DOMs that need external power cables.
- Page 31 1. System Reset Header JPME2 JPG1 JKVM1 JDBG2 JPME1 2. CPLD Programming Header JBR1 M.2-H 3. VRM I2C Debug Header BMC_HB_LED1 SRW2 SRW1 BAR CODE MAC CODE JSD1 JBT1 BIOS LICENSE JDBG1 JWD1 I-SATA1 B2SC1-CPU REV:1.00 DESIGNED IN USA JVR1...
- Page 32 Super B2SC1-CPU User's Manual TPM Header The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from a third-party vendor. A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.
- Page 33 Pin Definitions Pin# Definition SMBus Clock SMBus Data Ground 1. VRM SMBus Header JPME2 JPG1 JKVM1 JDBG2 JPME1 JBR1 M.2-H BMC_HB_LED1 SRW1 SRW2 BAR CODE MAC CODE JSD1 JBT1 BIOS LICENSE JDBG1 JWD1 I-SATA1 B2SC1-CPU REV:1.00 DESIGNED IN USA JVR1...
-
Page 34: Jumper Settings
Super B2SC1-CPU User's Manual 2.8 Jumper Settings How Jumpers Work To modify the operation of the motherboard, jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board. See the diagram at right for an example of jumping pins 1 and 2. - Page 35 Note: Clearing CMOS will also clear all passwords. JBT1 contact pads JPME2 JPG1 JKVM1 JDBG2 JPME1 JBR1 M.2-H 1. Clear CMOS BMC_HB_LED1 SRW1 SRW2 BAR CODE MAC CODE JSD1 JBT1 BIOS LICENSE JDBG1 JWD1 I-SATA1 B2SC1-CPU REV:1.00 DESIGNED IN USA JVR1...
- Page 36 Super B2SC1-CPU User's Manual BIOS Recovery Close pins 2-3 of jumper JBR1 for BIOS recovery. The default setting is on pins 1 and 2 for normal operation. Refer to the table below for jumper settings. The default setting is Normal.
- Page 37 Normal (Default) Pins 2-3 Manufacturing Mode 1. ME Recovery JPME2 JPG1 JKVM1 JDBG2 2. ME Manufacturing Mode JPME1 JBR1 M.2-H BMC_HB_LED1 SRW2 SRW1 BAR CODE MAC CODE JSD1 JBT1 BIOS LICENSE JDBG1 JWD1 I-SATA1 B2SC1-CPU REV:1.00 DESIGNED IN USA JVR1...
- Page 38 Super B2SC1-CPU User's Manual Watch Dog JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for the application that hangs.
-
Page 39: Led Indicators
BMC LED Indicator LED Color Definition Blinking Green BMC Normal JPME2 JPG1 JKVM1 JDBG2 1. BMC LED JPME1 JBR1 M.2-H BMC_HB_LED1 SRW2 SRW1 BAR CODE MAC CODE JSD1 JBT1 BIOS LICENSE JDBG1 JWD1 I-SATA1 B2SC1-CPU REV:1.00 DESIGNED IN USA JVR1... -
Page 40: Chapter 3 Troubleshooting
Super B2SC1-CPU User's Manual Chapter 3 Troubleshooting 3.1 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the ‘Technical Support Procedures’ and/ or ‘Returning Merchandise for Service’ section(s) in this chapter. Always disconnect the AC power cord before adding, changing or installing any non hot-swap hardware components. -
Page 41: No Video
Chapter 3: Troubleshooting No Video 1. If the power is on but you have no video, remove all the add-on cards and cables. 2. Use the speaker to determine if any beep codes exist. Refer to Appendix A for details on beep codes. -
Page 42: Losing The System's Setup Configuration
Super B2SC1-CPU User's Manual Losing the System's Setup Configuration 1. Make sure that you are using a high quality power supply. A poor quality power supply may cause the system to lose the CMOS setup information. Refer to Section 1.6 for details on recommended power supplies. - Page 43 Chapter 3: Troubleshooting 3. Using the minimum configuration for troubleshooting: Remove all unnecessary components (starting with add-on cards first), and use the minimum configuration (but with a CPU and a memory module installed) to identify the trouble areas. Refer to the steps listed in Section A above for proper troubleshooting procedures.
-
Page 44: Technical Support Procedures
Super B2SC1-CPU User's Manual 3.2 Technical Support Procedures Before contacting Technical Support, please take the following steps. Also, note that as a motherboard manufacturer, we do not sell directly to end users, so it is best to first check with your distributor or reseller for troubleshooting services. -
Page 45: Frequently Asked Questions
3.3 Frequently Asked Questions Question: What type of memory does my motherboard support? Answer: The B2SC1-CPU up to 64GB of Very Low Profile (VLP) ECC UDIMM DDR4 memory with speeds of up to 2666MHz in four slots Question: How do I update my BIOS? Answer: It is recommended that you do not upgrade your BIOS if you are not experiencing any problems with your system. -
Page 46: Battery Removal And Installation
Super B2SC1-CPU User's Manual 3.4 Battery Removal and Installation Battery Removal To remove the onboard battery, follow the steps below: 1. Power off your system and unplug your power cable. 2. Using a tool such as a pen or a small screwdriver, push the battery lock outwards to unlock it. -
Page 47: Returning Merchandise For Service
Shipping and handling charges will be applied for all orders that must be mailed when service is complete. For faster service, RMA authorizations may be requested online at http://www.supermicro. com/RmaForm/. This warranty only covers normal consumer use and does not cover damages incurred in shipping or from failure due to the alteration, misuse, abuse or improper maintenance of products. -
Page 48: Appendix A Bios Codes
Super B2SC1-CPU User's Manual Appendix A BIOS Codes A.1 BIOS Error POST (Beep) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process. - Page 49 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOM-SPI80-V). For information on AMI updates, please refer to http://www.ami.com/products/.
-
Page 50: Appendix B Software Installation
The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to create a DVD of the drivers and utilities it contains. -
Page 51: Superdoctor 5
SATA settings back to your original settings. B.2 SuperDoctor ® The Supermicro SuperDoctor 5 is a hardware monitoring program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program monitors system health information such as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP). -
Page 52: Appendix C Standardized Warning Statements
The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. - Page 53 Appendix C: Standardized Warning Statements Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant. Jeter les piles usagées conformément aux instructions du fabricant. ¡Advertencia! Existe peligro de explosión si la batería se reemplaza de manera incorrecta.
- Page 54 Super B2SC1-CPU User's Manual Product Disposal Warning! Ultimate disposal of this product should be handled according to all national laws and regulations. 製品の廃棄 この製品を廃棄処分する場合、 国の関係する全ての法律 ・ 条例に従い処理する必要があります。 警告 本产品的废弃处理应根据所有国家的法律和规章进行。 警告 本產品的廢棄處理應根據所有國家的法律和規章進行。 Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen.
-
Page 55: Appendix D Uefi Bios Recovery
Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. - Page 56 Super B2SC1-CPU User's Manual The file system supported by the recovery block is FAT (including FAT12, FAT16, and FAT32), which is installed on a bootable or non-bootable USB-attached device. However, the BIOS might need several minutes to locate the SUPER.ROM file if the media size becomes too large due to the huge volumes of folders and files stored in the device.
- Page 57 Appendix D: UEFI BIOS Recovery 3. After locating the new BIOS binary image, the system will enter the BIOS Recovery menu as shown below: Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
- Page 58 Super B2SC1-CPU User's Manual 5. After the BIOS recovery process is completed, press any key to reboot the system. 6. Using a different system, extract the BIOS package into a USB flash drive. 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu.
- Page 59 Appendix D: UEFI BIOS Recovery 8. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 6. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process. Note: Do not interrupt this process until the BIOS flashing is complete.
