Art Series
I
Careful acoustic design and advanced materials
have resulted in an exceptional full range, full fidelity,
self-contained sound system. The ART200A provides
an ideal combination of high power, low distortion and
wide bandwidth for permanent installations.
I
The two-way design consists of a 12" woofer that
uses a massive magnet structure for accurate bass
reproduction and a CD horn loaded to a 1" exit com-
pression driver. The CD horn is a part of the molded
enclosure. Two discrete power amplifiers and an elec-
tronic crossover are matched to the two transducers
and provide time correction, CD horn compensation
and peak-limiting, as well as over-excursion and
thermal protection.
I
The ART200A will accept a balanced or unbalanced
(switch selected) microphone or line input, adjusted by
a single rotary control.
I
All components are housed in a lightweight, vented
enclosure formed from polypropylene that is extremely
rigid. The woofer is protected by a metal grille. All con-
trols and connectors are recessed on the rear. A 1-3/8"
stand socket and M10 threaded inserts are molded
into the cabinet to provide quick and easy installation
using specially designed accessory mounting hard-
ware.
I
This Mackie Industrial product is covered by an
exclusive, one-time, NO FAULT repair policy in addition
to a five year limited warranty.
ART200A
Two-Way Active Speaker System
Features
I
90° x 70° constant-directivity horn with 1"
exit compression driver
I
12" high-efficiency woofer
I
Internal bi-amplifier: 120W LF, 40W HF, and
driver-optimized electronic crossover
I
Switchable balanced mic/line input
I
Total system protection: over-excursion, thermal,
short circuit and peak limiting
I
Compact, lightweight polypropylene enclosure
I
Built-in hand grip, M10 fly points and stand socket
I
Optional installation accessories available
I
Exclusive Mackie Industrial — one-time, NO FAULT
repair policy
I
Five year limited warranty
I
Live Sound/Music Reinforcement
I
High-Level AV Playback
I
Large Speech Systems
I
Active Floor Monitors
1
O F 6 P A G E S
oF 6 PAGES
