Chapter 2 Hardware Installation

2.1 Physical details
2.1.1 Front LEDs
LEDs:
LED Function
POWER Power indication
System status
Status
indicators
WAN WAN port activity
WLAN Wireless activity
Link status
Link
Figure 2-1 Front LEDs
Color Status
Green On Power is being applied to this product.
Green Blinking
On
Green
Blinking
Green Blinking
Green On
9
Description
Status is flashing once per second to
indicate that the system is alive.
The WAN port is linked.
The WAN port is sending or receiving data.
Sending or receiving data via wireless
An active station is connected.
