- Page 1 MODEL # CM4265DK-SQ Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 7...
- Page 5 COFFEE TABLE CM4265DK-SQ PARTS #2 1pc #3 4pcs Table Top Shelf HARDWARE #C 12pcs #A 12pcs #B 12pcs #D 1pc Allen Wrench 4mm Flat Washer 5/16" Lock Washer 5/16" BOLT Ø5/16 X 2" 5 / 7...
- Page 6 1. Carefully place the table top (#1) face down onto a protected surface. 2. Prepare 6 bolt assemblies by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#B) onto that same bolt (#A). 3. Align 3 legs (#3) to three corners of the table top (#1). Insert 2 bolt x 1pc Part assemblies into each leg and secure using the Allen wrench (#D).
- Page 7 1. Prepare 3 bolt assemblies by first inserting a lock washer (#C) onto the bolt (#A) then a flat washer (#B) onto that same bolt (#A). #3 x 1pc Part Hardware #A x3pcs Hardware x3pcs Hardware x3pcs 2. Align the fourth leg (#3) to the final corner and insert a bolt assembly into each hole.
