Assembly Instructions
CM4220-3PK
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
assembling a specific product (with 1 being
(Included)
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 9
Rev.14-10-17
Advertisement
Related Manuals for Furniture of America CM4220-3PK
Summary of Contents for Furniture of America CM4220-3PK
- Page 1 Assembly Instructions CM4220-3PK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 9...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 2 pcs #A x 18 pcs C/T Leg Stand Bolt 1/4”x5/8” #B x 12 pcs #2 x 1 pc Bolt 1/4”x1-1/8”...
- Page 4 #A x 4 pcs Insert the coffee table stand support (#2) onto the 2 coffee table leg stands (#1). Insert 4 bolts (#A) through the brackets of the coffee table stand support (#2) and secure those bolts (#A) using the Turn right (clockwise) to tighten Allen wrench (#D) to lock them with the 2 coffee...
- Page 5 Align the assembled #B x 4 pcs coffee table leg stands (#1) with the pre-drilled holes on the coffee table frame (#3). Insert 4 bolts (#B) through the coffee table leg stands (#1) and secure those bolts (#B) using the Allen wrench (#D) to lock them with the coffee table frame (#3).
- Page 6 With the help of another person, carefully place the coffee table glass top (#4) over the spacers (#D) and the table frame (#3). Make sure the coffee table is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened.
- Page 7 #A x 8 pcs Insert the end table stand support (#6) onto the 2 end table leg stands (#5). Insert 4 bolts (#A) through the brackets of the end table stand support (#6) and secure those bolts Turn right (clockwise) to tighten (#A) using the Allen wrench (#D) to lock them with the 2 end...
- Page 8 Align the assembled end table #B x 8 pcs leg stands (#5) with the pre- drilled holes on the end table frame (#7). Insert 4 bolts (#B) through the end table leg stands (#5) and secure those bolts (#B) using the Allen wrench (#D) to lock them with the end table frame (#7).
- Page 9 Carefully place the end table glass top (#8) over the spacers (#D) and the table frame (#7). Make sure the end tables are rested on a flat surface and do not feel loose or wobbly. If they do, double check that the bolts/screws are secured and properly tightened.
