Summary of Contents for MSI MS-7199
- Page 1 Fuzzy CN700G Series MS-7199(V2.X) Mainboard G52-71991X2...
-
Page 2: Copyright Notice
Alternatively, please try the following help resources for further guidance. Visit the MSI website for FAQ, technical guide, BIOS updates, driver updates, an d oth er in forma tion : htt p:// glob al.m si.com.tw /ind ex.p hp? func=faqIndex Contact our technical staff at: http://support.msi.com.tw... -
Page 3: Safety Instructions
Safety Instructions Always read the safety instructions carefully. Keep this User’s Manual for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equip- ment from overheating. -
Page 4: Fcc-B Radio Frequency Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Micro-Star International MS-7199... -
Page 5: Weee (Waste Electrical And Electronic Equipment) Statement
WEEE (Waste Electrical and Electronic Equipment) Statement... -
Page 8: Table Of Contents
Copyright Notice ... ii Tr ademar ks ... ii Revision History ... ii Technical Support ... ii Safety Instructions ... iii FCC-B Radio Frequency Interference Statement ... iv WEEE (Waste Electrical and Electronic Equipment) Statement ... v Chapter 1. Getting Started ... 1-1 Mainboard Specifications ... -
Page 9: Chapter 1. Getting Started
Getting Started Chapter 1 Getting Started Thank you for choosing the Fuzzy CN700G Series (MS-7199) V2.X Min i-ITX main board. The Fuzzy ® CN700G Series mainboard is based on VIA CN700 and VT8237R+ chipsets for optimal system efficiency. The Fuzzy CN700G Series mainboard delivers a high p erforman ce an d profession al desktop pl atform solution. -
Page 10: Mainboard Specifications
MS-7199 Mainboard Mainboard Specifications Processor Support ® - VIA C7 1/ 1.5/ 2.0 GHz/ 21x21mm nano BGA2 package - TDP max 1GHz@9W/ 1.5GHz@12W/ 2.0GHz@20W - Supports VRM mobile (down to 0.7V) - Thermal design margin up to 100c Tcase - 3D instructions SSE/ SSE2/ SSE3... - Page 11 Getting Started Connectors Back Panel - 1 PS/2 mouse port - 1 PS/2 keyboard port - 2 serial ports (COMA and COMB) - 2 USB 2.0 ports - 1 LAN jack - 3 flexible audio jacks - 1 S-video port - 1 DVI port - 1 VGA port On-Board Pinheaders...
-
Page 12: Mainboard Layout
Top: LAN Jack Bottom: USB ports RTL8110SC Top : COMA Bottom: COMB F_AUDIO T:Line-In M:Line-Out B:Mic CD_IN VT1618 PCI 1 (MS-7199) V2.X Mini-ITX Mainboard ATXPWR CN700 VT1622A VT8237R Plus JCI1 JBAT1 SATA1 SATA2 BATT BIOS Fuzzy CN700G Series CPUFAN JFP2... -
Page 13: Packing Checklist
Getting Started Packing Checklist SATA Cable MSI Driver/Utility CD MSI mainboard Power Cable Standard Cable for User’s Guide IDE Devices * This picture is for reference only. Your packing contents may vary depending on the model you purchased. -
Page 15: Chapter 2. Hardware Setup
Hardware Setup Chapter 2 Hardware Setup This chapter provides you with the information about hardware setup procedures. While doing the installation, be careful in holding the components and follow the installation procedures. For some components, if you install in the wrong orientation, the components will not work properly. -
Page 16: Quick Components Guide
MS-7199 Mainboard Quick Components Guide Back Panel, p.2-5 F_AUDIO, p.2-9 PCI Slot, p.2-13 ATXPWR, p.2-4 CPUFAN, p.2-9 J9, p.2-11 JCI1, p.2-10 CD_IN, p.2-9 JBAT1, p.2-12 DDR2 DIMM, p.2-3 J3/J4/J5, p.2-11 IDE1, p.2-7 SATA1~2, p.2-8 JFP2, p.2-10 JFP1, p.2-10... -
Page 17: Memory
Memory This DIMM slot is used for installing memory modules. DDR2 240-pin, 1.8V Installing Memory Modules 1. The memory module has only one notch on the center and will only fit in the right orientation. 2. Insert the memory module vertically into the DIMM slot. Then push it in until the golden finger on the memory module is deeply inserted in the DIMM slot. -
Page 18: Power Supply
MS-7199 Mainboard Power Supply ATX 20-Pin Power Connector: ATXPWR This connector allows you to connect to an ATX power supply. ATXPWR ATXPWR Pin Definition SIGNAL 3.3V 3.3V PW_OK 5V_SB SIGNAL 3.3V -12V PS_ON... -
Page 19: Back Panel
Back Panel VGA Port M ouse Keyboard DVI Port Mouse/Keyboard ® The standard PS/2 mouse/keyboard DIN connector is for a PS/2 VGA Port The DB15-pin female connector is provided for monitor. DVI Port The DVI (Digital Visual Interface) connector allows you to connect a LCD monitor. It provides a high-speed digital interconnection between the computer and its display device. - Page 20 MS-7199 Mainboard The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN). You can connect a network cable to it. Activity Indicator B Type 100M Cable Plug-in 1000M Cable Plug-in Audio Ports These audio connectors are used for audio devices. You can differentiate the color of the audio jacks for different audio sound effects.
-
Page 21: Connectors
Connectors IDE Connector: IDE1 This connector supports IDE hard disk drives, optical disk drives and other IDE devices. IDE1 Important If you install two IDE devices on the same cable, you must configure the drives separately to master / slave mode by setting jumpers. Refer to IDE devi ce’s documentation suppl i ed by the vendors for jumper setting instructions. - Page 22 MS-7199 Mainboard Serial ATA Connector: SATA1~SATA2 These connectors are high-speed Serial ATA interface ports. Each connector can connect to one Serial ATA device. SATA1 SATA2 Important Please do not fold the Serial ATA cable into 90-degree angle. Otherwise, data loss may occur during transmission.
- Page 23 Fan Power Connector: CPUFAN The fan power connector supports system cooling fan with +12V. When connecting the wire to the connector, always note that the red wire is the positive and should be connected to the +12V, the black wire is Ground and should be connected to GND. CD-In Connector: CD_IN This connector is provided for CD-ROM audio.
-
Page 24: Front Panel Connector
MS-7199 Mainboard Front Panel Connectors: JFP1, JFP2 These connectors are for electrical connection to the front panel switches and LEDs. The JFP1 is compliant with Intel Reset Switch JFP1 Power Power Switch Speaker JFP2 Power Chassis Intrusion Connector: JCI1 This connector connects to the chassis intrusion switch cable. If the chassis is opened, the chassis intrusion mechanism will be activated. - Page 25 Front USB Connector: J3,J4,J5 This connector, compliant with Intel necting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. J3/J4/J5 (USB 2.0) Important Note that the pins of VCC and GND must be connected correctly to avoid possible damage.
-
Page 26: Jumpers
MS-7199 Mainboard Jumpers Clear CMOS Jumper: JBAT1 There is a CMOS RAM onboard that has a power supply from an external battery to keep the data of system configuration. With the CMOS RAM, the system can auto- matically boot OS every time it is turned on. If you want to clear the system configuration, set the jumper to clear data. -
Page 27: Slots
Slot PCI (Peripheral Component Interconnect) Slot The PCI slot supports LAN card, SCSI card, USB card, and other add-on cards that comply with PCI specifications. PCI Interrupt Request Routing The IRQ, acronym of interrupt request line and pronounced I-R-Q, are hardware lines over which devices can send interrupt signals to the microprocessor.
