Using the PC Card Adapter

1.
Insert the Express Card Modem, label facing up, through the PC
Card Adapter opening, with the Express Card to PCMCIA Adapter
label facing up.
[DO NOT force the Express Card into the PC Card Adapter].
2.
Ensure that the Express Card connects or locks with the connector
pins on the adapter.
3.
Properly insert into your computer's PC Card (PCMCIA) slot.

Viewing the User Guide

The user guide provides detailed information on the Windows and Mac
versions of the Sprint SmartView software.
In Windows, select
Guide.
– or –
On your Mac desktop, double-click

Removing the Express Card Modem

1.
Exit the Sprint SmartView software if it is open.
2.
Remove the Express Card Modem from your computer's Express
Card or PC Card slot by gripping both sides of the Express Card
Modem and pulling straight out
WARNING When inserting or removing your Express Card Modem, always grip it
by its sides, as this prevents damage to the Express Card Modem.
ADD IMAGE: EX720
PC Card Adapter
Start > All Programs > Sprint > Sprint SmartView User
Section 2B. Using Your Express Card Modem
Sprint SmartView User Guide.PDF
.
13
