1133550/2
IM-P113-04
CMGT Issue 2
UIB45
Sealed Inverted Bucket Steam Trap
for use with Pipeline Connectors
Installation and Maintenance Instructions
1. Safety information
2. General product information
3. Installation
4. Commissioning
5. Operation
6. Maintenance
7. Spare parts
UIB45 Sealed Inverted Bucket Steam Trap for use with Pipeline Connectors
© Copyright 2022
1
IM-P113-04 CMGT Issue 2
Printed in GB
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Spirax Sarco UIB45
Summary of Contents for Spirax Sarco UIB45
- Page 1 Installation and Maintenance Instructions 1. Safety information 2. General product information 3. Installation 4. Commissioning 5. Operation 6. Maintenance 7. Spare parts UIB45 Sealed Inverted Bucket Steam Trap for use with Pipeline Connectors © Copyright 2022 IM-P113-04 CMGT Issue 2 Printed in GB...
- Page 2 UIB45 Sealed Inverted Bucket Steam Trap for use with Pipeline Connectors IM-P113-04 CMGT Issue 2...
-
Page 3: Safety Information
It should be noted that products within this category are required by the Directive not to carry mark. i) The UIB45 has been specifically designed for use on steam, air or condensate/water which is in Group 2 of the above mentioned Pressure Equipment Directive. The products’ use on other fluids may be possible but, if this is contemplated, Spirax Sarco should be contacted to confirm the suitability of the product for the application being considered. -
Page 4: Protective Clothing
You are advised to assess the risks taking into account the task, the individual, the load and the working environment and use the appropriate handling method depending on the circumstances of the work being done. UIB45 Sealed Inverted Bucket Steam Trap for use with Pipeline Connectors IM-P113-04 CMGT Issue 2... -
Page 5: Residual Hazards
Customers and stockists are reminded that under EC Health, Safety and Environment Law, when returning products to Spirax Sarco they must provide information on any hazards and the precautions to be taken due to contamination residues or mechanical damage which may present a health, safety or environmental risk. -
Page 6: General Product Information
(with the cover hanging downwards). When installed with a suitable pipeline connector (available separately from Spirax Sarco) the UIB45 can easily and simply be removed without breaking into the pipeline, thus speeding up trap replacement with minimal system downtime. Pipeline connectors are available with screwed, socket weld and flanged end connections. -
Page 7: Pressure/Temperature Limits
8.5 bar (123 psi) UIB45/10 4.5 bar (65 psi) Designed for a maximum cold hydraulic test pressure of: 149 bar g (2 161 psi g) UIB45 Sealed Inverted Bucket Steam Trap for use with Pipeline Connectors IM-P113-04 CMGT Issue 2... -
Page 8: Installation
Remove protection covers from all connections and protective film from all name-plates, where appropriate, before installation on steam or other high temperature applications. The UIB45 can be installed on any pipeline connector. See separate Installation and Maintenance Instructions for Spirax Sarco pipeline connectors (IM-P128-06, IM-P128-11 and IM-P128-13). - Page 9 (22 - 26) 4. Commissioning After installation or maintenance ensure that the system is fully functioning. Carry out tests on any alarms or protective devices. UIB45 Sealed Inverted Bucket Steam Trap for use with Pipeline Connectors IM-P113-04 CMGT Issue 2...
-
Page 10: Operation
Note: Before actioning any maintenance programme observe the 'Safety information' in Section 1. Warning The inner and outer gaskets used when installing/maintaining the UIB45 to a PC_ pipeline connector contain thin stainless steel support rings which may cause physical injury if not handled and disposed of carefully. -
Page 11: Spare Parts
Always order spare parts by using the description given in the column headed 'Available spares' and state the size, model no. and pressure rating of the trap. Example: 1 - Connector screw and gasket set for a Spirax Sarco UIB45 sealed stainless steel bucket steam trap (for use with pipeline connectors). - Page 12 UIB45 Sealed Inverted Bucket Steam Trap for use with Pipeline Connectors IM-P113-04 CMGT Issue 2...
