Pc Health - MSI E7320 Master-2S User Manual

This section shows the status of your CPU, fan, overall system status, etc. Monitor
function is available only if there is hardware monitoring mechanism onboard.
Main Advanced
Auto Fan Speed Control
Spread Spectrum
VTT(+1.2V)
+12V
+5V
1st VCC
2nd VCC
1st Vcore
2nd Vcore
CPU1 Temperature
CPU2 Temperature
CPU Fan 1 Speed
CPU Fan 2 Speed
CPU Fan 3 Speed
Power Fan 2 Speed =
Power Fan 3 Speed =
Power Fan 4 Speed =
F1 Help
Esc Exit
Auto Fan Speed Control
This setting controls the Fan PW M Duty Cycle. W hen setting to [Enabled], the duty
cycle will be controlled by BIOS. W hen setting to [Disabled], the duty cycle will be
controlled by fans.
Spread Spectrum
W hen the motherboard's clock generator pulses, the extreme values (spikes) of the
pulses creates EMI (Electromagnetic Interference). The Spread Spectrum function
reduces the EMI generated by modulating the pulses so that the spikes of the pulses
are reduced to flatter curves.

PC Health

PhoenixBIOS Setup Utility
Security Power
[Enabled]
[Enabled]
= 1.20V
= 12.0276V
= 5.1285V
= 3.2466V
= 3.2298V
= 1.3560V
= 1.3620V
o
= +61 C/+141
o
= +45 C/+113
= 2925 RPM
= 2920 RPM
= 0 RPM
0 RPM
0 RPM
0 RPM
Select Item -/+ Change Values
Select Menu Enter Select Sub-Menu F10 Save and Exit
Boot PC Health
Item Specific Help
o
F
o
F
F9 Setup Defaults
8
BIOS Setup
Exit
3-19
