Summary of Contents for ONFORU CTB24BL
- Page 1 LED LIGHT Product Manual MODEL: CTB24BL CTB48BL CTB72BL CTB96BL...
- Page 2 COMPONENTS AND STRUCTURE CTB24BL CTB48BL CTB72BL CTB96BL 1. Tempered Glass Lid 2. LED Light Source 3. Lamp Bracket 3x18AWG (US) 1.5m(4.92ft)
-
Page 3: Parts List
PARTS LIST Screw Machine Screw Expansion Rubber Plug QTY: 2 QTY: 4 QTY: 4 Lamp Brackets Hex Screw Key QTY: 2 QTY: 1... -
Page 4: Specifications
SPECIFICATIONS LED FLOODLIGHT Model CTB24BL CTB48BL CTB72BL CTB96BL Input Voltage 100-120V～60Hz Input Current 0.31A 0.6A 0.9A 1.1A Rated Power Color Power Factor ≥0.5 Chromaticity coordinate x=0.2053，y=0.192 Beam Angle 120° -20-40°C/-4°F-104°F Luminaire Location SUITABLE FOR WET LOCATIONS DIMENSIONS Model CTB24BL CTB72BL... - Page 5 APP INSTALLATIONS STEP 1 Happy Lighting STEP 2 Trick-xxxx...
- Page 6 APP OPERATING INSTRUCTIONS Brightness Selection Interface： Music Mode Interface： You could adjust the brightness. You could control the brightness and dynamic changes of the light by playing local music in the phone.
- Page 7 APP OPERATING INSTRUCTIONS Dynamic Mode Interface: Mobile Speaker: The light has 5 dynamic modes (Gradient, The dynamic modes can change with the Breathing, Strobe, Jump, Auto), and speed sound inside the phone or other external can be adjusted. sounds.
- Page 8 APP OPERATING INSTRUCTIONS Timing Interface： You can turn on or turn off the light regularly.
- Page 9 PREPARATION Check all components for damage, do not use the product if it is damaged. Estimated Assembly Time:10-30 minutes TOOLS REQUIRED（not included） Flathead Screwdriver Electric drill Eye Protection Pliers Step Ladder screwdriver WARNING: THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
-
Page 10: Installation Steps
WARNING: INSTALLING THIS LIGHT IN AN UNGROUNDED ELECTRICAL SYSTEM MAY CAUSE THE METAL PARTS OF THE LIGHT TO CARRY CURRENT IF ANY WIRES OR WIRE CONNECTIONS ARE DAMAGED OR LOOSE. IN THIS CASE, ANYONE WHO TOUCHES THE LIGHT WILL RECEIVE AN ELECTRIC SHOCK, RESULTING IN INJURY OR DEATH. - Page 11 FCC ID 2A3W8D100BLA FCC Warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may...
- Page 12 Manufacturer / Hersteller: Shen Zhen Shi Meng Zhi Tuo Ke Ji You Xian Gong Si Address: qian wan yi lu 1 hao A dong 201 shi qian hai shen gang he zuo qu Shen Zhen, Guang Dong, 518000, CN support@onforuled.com www.onforuleds.com EU REP MDH LIGHTING LTD Suite 302, 292 Strovolos Avenue, 2048 Strovolos Nicosia, Cyprus | support@onforuled.com UK REP MDH LIGHTING LTD 69 Aberdeen Avenue, Cambridge CB2 8DL, United Kingdom | support@onforuled.com Made in China...
