- Page 1 LED LIGHT Product Manual MODEL: CTB24UV CTB48UV CTB72UV CTB96UV...
- Page 2 COMPONENTS AND STRUCTURE CTB24UV CTB48UV CTB72UV CTB96UV 1. Tempered Glass Lid 2. LED Light Source 3. Lamp Bracket 3x18AWG (US) 1.5m(4.92ft)
-
Page 3: Parts List
PARTS LIST Screw Machine Screw Expansion Rubber Plug QTY: 2 QTY: 4 QTY: 4 Lamp Brackets Hex Screw Key QTY: 2 QTY: 1... -
Page 4: Specifications
SPECIFICATIONS LED FLOODLIGHT Model CTB24UV CTB48UV CTB72UV CTB96UV Input Voltage 100-120V～60Hz Input Current 0.2A 0.42A 0.6A 0.82A Rated Power Wavelength 385-400nm Power Factor ≥0.9 Chromaticity coordinate x=0.1763 y=0.0317 -1.9 Beam Angle 120° -20-40°C/-4°F-104°F SUITABLE FOR WET LOCATIONS Luminaire Location DIMENSIONS... - Page 5 PREPARATION Check all components for damage, do not use the product if it is damaged. Estimated Assembly Time:10-30 minutes TOOLS REQUIRED（not included） Flathead Screwdriver Electric drill Eye Protection Pliers Step Ladder screwdriver WARNING: THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
- Page 6 CAUTION: PLEASE MAKE SURE YOUR WALL SWITCH AND POWER AT MAIN CIRCUIT BREAKER BOTH ARE OFF. IF IN DOUBT ABOUT ELECTRICAL INSTALLATION, CONSULT A LICENSED ELECTRICIAN. WARNING: INSTALLING THIS LIGHT IN AN UNGROUNDED ELECTRICAL SYSTEM MAY CAUSE THE METAL PARTS OF THE LIGHT TO CARRY CURRENT IF ANY WIRES OR WIRE CONNECTIONS ARE DAMAGED OR LOOSE.
-
Page 7: Installation Steps
INSTALLATION STEPS Product appearance may vary from image shown. Step 2 Step 1 Step 4 Step 3 STEP 1: Fix the bracket on the lamp with the combination screw. (as shown in the image) STEP 2: According to the spacing (see the “A” part of the picture) of four holes on the lamp brackets, drill four mounting holes. - Page 8 Manufacturer / Hersteller: Shen Zhen Shi Meng Zhi Tuo Ke Ji You Xian Gong Si Address: qian wan yi lu 1 hao A dong 201 shi qian hai shen gang he zuo qu Shen Zhen, Guang Dong, 518000, CN support@onforuled.com www.onforuleds.com EU REP MDH LIGHTING LTD Suite 302, 292 Strovolos Avenue, 2048 Strovolos Nicosia, Cyprus | support@onforuled.com UK REP MDH LIGHTING LTD 69 Aberdeen Avenue, Cambridge CB2 8DL, United Kingdom | support@onforuled.com Made in China...
