FMS F-16 Fighting Falcon V2 Operating Manual page 9

7. Install the front and main landing gear with the included screws (fig11/fig12).
Hex screws 3*4
8. Correctly mount the wing tip missiles with glue. The missiles are correctly mounted when the top of the
missiles are level with the surface of the main wing (fig13/fig14).
Note：
For your first flight, we recommend you do not install the under wing fuel tanks and rockets. These extra
scale accessories can cause unwanted drag which can effect takeoff, landing, and flight trimming of the
aircraft. Once you have a full understanding of the aircraft flight performance and characteristics, you can
install and re-trim as needed.
9. Install the clevis. Refer to the Clevis Installation on page 12.
KA 2.0x8
fig11
fig11
fig13
fig13
8
fig12
fig14
fig15
