4. The bottom of the fuselage faces up. Carefully apply CA to the base and side of the rear fuselage slot.
Install the stabilizer into place. Ensure the control horn is face up as shown (fig5).
Note: Ensure the stabilizer horizontal axis is parallel to the wing as shown (fig6). Adjust any misalignment
before the glue dries thoroughly.
5. Carefully apply CA to the top rear fuselage slot. Install the vertical stabilizer into place.
Required Adhesives:
fig5
fig5
Required Adhesives:
fig7 fig7
6
Medium CA
Medium CA
fig6
fig6
