MSI Mega Player P200 User Manual

MSI Mega Player P200 User Manual

Msi mega player p200: user guide
Hide thumbs

Advertisement

Quick Links

Download this manual
Precautions
1． Do not store the product at high-temperatures.
2． Never operate or listen to player while driving.
3． Do not operate the player in a humid, wet or dusty environment.
4． Do not apply pressure to the LCD panel.
5． The manufacturer will not take any responsibility for damage caused
by abnormal operation or physical stress.
6． The manufacturer will not take any responsibility for files stored on
the device.
7． Do not clean the product with alcohol, paint thinner or benzene.
8． Do not disassemble the product.
9． Never listen to music at the highest volume level over a long period
of time
GB - 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mega Player P200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MSI Mega Player P200

Summary of Contents for MSI Mega Player P200

  • Page 1 Precautions 1． Do not store the product at high-temperatures. 2． Never operate or listen to player while driving. 3． Do not operate the player in a humid, wet or dusty environment. 4． Do not apply pressure to the LCD panel. 5．...
  • Page 2 1.when initially operating, the icons of the remaining capacity may not readable. (enough) (middle) * Please change a new battery in the following cases, When the icon blinks signaling battery low level or empty. (Time unit: hour) Mp3 player (low) (empty) GB - 2...

  • Page 3: Player Overview

    2. .when using a general battery type instead of Alkaline, the player could stop working, even though the battery capacity icon shows medium level. Player overview Hol d Batte ry com pa rtment MODE Power OFF/S TOP L any ard loop VOL+ Pow er on /P l ay/pause For war d...
  • Page 4 Accessories Bat ter y Le vel So ng co unter Rep eat m ode B it r at e EQ mode ID 3 Display Play mode NO.o f so ng Music mo de AL L HA P PY E VE RY DAY .MP 3 Ho ld Turning the power on/off Press the PLAY button momentarily for 2 seconds and the MP3...
  • Page 5 2. The backlit durations can be preset in the “Back Light” menu. Pressing PLAY button for more than 3 seconds until the “Good Bye” appears will turn off the MP3 Ultra Flash Player. Key Lock Function Push the hold switch and the screen will show out “Key Lock!” Playing MP3 music 1.
  • Page 6 2. PLAY/ PAUSE status Short press PLAY KEY after turning on MP3, the music is played; Short press PLAY key again when music is being played, it will pause forward/back 3. If you want to select song, turn the Mode switch wheel left or right to get the track.
  • Page 7 backward/fast forward in the selected song Subfolder function This function can help user to separate songs in MP3 and put different songs into different subfolders so as to find the songs you like to listen. You can establish subfolders in computer when MP3 is connected with PC. When MP3 is under MODE status, long press Mode key and the following window popped up: You can see all subfolders which you set up yourself under root folder,...
  • Page 8 Menu A. Menu under the playing mode 1.Turn on the MP3 Player 2.When it is playing song, press the Mode Switch (In the middle of the rolling wheel), you can see the function menu as following:...
  • Page 9 list in the menu by short press PLAY key.There are six EQ in the list as following: You can adjust the modes by the EQ menu. You could experience perfect Classic, Live, Pop, Rock, DBB would effect by choosing suitable corresponding mode.
  • Page 10 If you’d like to listen to a song again and again, then you need change the Repeat mode. Under the music play mode, press the mode key, and then enter the Repeat mode. Or when the music pause, presses the mode key, choose the Repeat mode with adjust forward/back key and confirm with play key, and the Play Repeat mode can be changed.
  • Page 11 All the options are listed in the above table. 1.You may select every item by the rolling left or right of Mode switch and press Play/Stop key to enter the function. 2.When you select “File Delete”, you will enter the Delete interface. More information is to be mentioned behind.
  • Page 12 3.With no button being pressed, it will return to Play interface after 2 seconds. Voice Playing and Recording Function Notice: should press play key to record the recording documents, so please confirm the power of battery, if the power is not enough, the document can’t be recorded.
  • Page 13 TRACK:001 MIC_ 0 01.WAV 3.In Main Menu, you will see Voice Recording item. Select it to start voice recording. The Recording interface is showed as the following right figure. You could stop recording by short pressing PLAY/STOP button momentarily and exit from Voice Recording mode and switch to MP3 function by select Main menu.
  • Page 14 4.Short Press the Play/Stop to confirm. And then if will return to Music mode. Line-in recording When you want to transfer song from another MP3 player to your MP3 player, you only need to use the Line-in cable (not included), shown as diagram:...
  • Page 15 Press Play key to start record sounding, if you at this time put on headphones can still enjoy the wonderful music. Line-in recording process is shown as diagram below: After completing recording, there will be a LINE_REC folder for storage of Line-in recording files in your player, you are able to choose the recorded file you wanted.
  • Page 16 There are 3 kinds of modes of searching. Choose FM mode: under the FM mode, search the program with forward/back key, the bound of frequency is 87.5—108.5MHz. Automatic search: Keep the PLAY key forward or backward, the frequency will be increased or decreased automatically. Hand search: Just roll the PLAY key once, the frequency will be increased 100kHz(91.8MHz-91.9MHz) Under reception condition...
  • Page 17 “PRESET”: Automatically searching the channels. When it find a qualified channel, it will stop searching. If you think the channel is not satisfied, you can keep the PLAY key forward or backward again to go on searching, if you just roll the PLAY key once, the frequency will return back to the frequency of channel 01 saved( if there is no saved channel, it will return to 87.50MHz) “FREQUENCY”: Hand search mode.The only difference with Automatically...
  • Page 18 key and choose this item, then the frequency can be save as channel01 or channel02 as you like; “CLR PRESET”: If you want to delete any channel saved, choose this item and press the PLAY key to confirm. FM sensitivity: Under the FM mode, press mode key to enter FM menu, and choose ‘FM sensitivity’...
  • Page 19 After that, there will be a ‘FM_REC’ folder to storage recording files. Our MP3 player can record the program the when you are listening FM, and the recording quality and be adjusted, it can be divided into 32kbps,64kbps,96kbps,112kbps,128kbps, 192kbps, Of six grades .The following diagram shows:...
  • Page 20 Delete files If you want to delete the files in the player, you may do it by using the delete function in the menu. 1.Press Menu button (in the middle of the rolling wheel) to get the Main menu. 2.Select “File Delete” by short pressing PLAY key and the following display will appear.

  • Page 21: Setting Options

    MIC_ 002.WAV 3.Now you are allowed to choose the files to be deleted by dial Mode forward/back Switch . In this dialog box ,short press Play/Stop key to confirm and if you will not delete the file press any key to exit. Setting Options Choose Setting item in the Main menu, you can see the system setting list as following:...
  • Page 22 Language function establishes 1. Open the main menu, and enter into “Setting” ,choose “Language” item by short pressing PLAY/STOP button, then the following diagram to show: Language Lyric Display LCD Contrast Back Light Bitrate Format Momory Reset setting Memory Info. S/W Version GB - 22...

  • Page 23: Lyrics Display

    2.Enter the language to establish the item, and can see English, simplified Chinese character（GB2312）, and traditional Chinese character （Big5）,Korean, Japanese, German, French, Italian, Spanish, etc. following diagram to show: Choose the language you prefer to set up the languages MP3 displaying. Lyrics display 1.
  • Page 24 The software in the CD driver offer you to modify, and delete, and edit lyric of song. Install the software in the CD driver , choose the " LP Setup .exe" and press" Next" the key according to the guidance on window popped up. 2.Use the lyrics synchronous GB - 24...
  • Page 25 The detailed information that lyrics edit pleases see the helps. 3.Press to open the machine key to open to broadcast the MP3 player . Under the music pause the mode, regulate the function menu, and pass to go forward/ retreat the key choice the lyrics to show the options.

  • Page 26: Lcd Contrast

    LCD Contrast The Backlight You can setup how long the backlight will last according to your demands. 1.Select Backlight in the setting submenu. 2.You may choose to turn off the backlight or let the backlight on for 5, 10, 15. 20 seconds and ON each time the button is pressed 10 S 5 Seconds GB - 26...
  • Page 27 Recording speed（FM Reaording and Circuit record speed） You can use the menu to regulate the FM recording speed, recording speed can is divided into 32kbps,64kbps,96kbps,112kbps,128kbps,192kbps of six grades .The following diagram shows: diagram shows 1 diagram shows 2 Format Memory GB - 27...

  • Page 28: Reset Setting

    MP3 when battery power status is too low and change new battery before starting format. When formatting is in progress, please do not remove the battery. Reset setting By choosing this item, your MP3 player will be reverted to the default GB - 28...
  • Page 29 setting in manufacturer, such as the menu language will be back to English etc. R ese t Sett i ng Examine the internal memory size You could examine the memory size without being connected to the PC. 1.Select Memory Info in the menu in ”Setting” item 2.Short Press Play/Stop key to confirm.
  • Page 30 Firmware edition 1.Select S/W version in “SETTING”. The following diagram shows: 2.You can see this product now of the following diagram of information of firmware edition show: S/W version V.3003 USB Connection Once you connect with PC and you player will show “USB RDY” means GB - 30...

  • Page 31: Operation Introduction

    USB ready. Warning : Download operation of WMA music with DRM protection to MP3-Player On Window 98SE/ Window ME / Windows 2000/ Windows XP , WMA music with DRM should be transferred by Windows Media Player 9.0 and 10.0 version (10.0 version for Windows XP only) to MP3-Player Other download operation probably will cause MP3-Player can not read the WMA music with DRM file.
  • Page 32 Open Windows Media Player 9.0 In Windows Media Player 9.0 , open the desired WMA music with DRM System maybe requested to download the license in case if user does not download the WMA music with DRM properly from the website. In this case, user need download the license from music publisher as instruction of Microsoft Website.
  • Page 33 In the opening windows , choose the desired WMA music with DRM as step 2) And choose “Removable Disk” Then click Icon “Copy ” to transfer the WMA music with DRM to your Mp3-Player GB - 33...
  • Page 34 Safely remove your Mp3-Player from PC B) On Windows Media Player 10.0 version (Windows XP only) Connect your MP3-Player to PC Choose the desired WMA music with DRM GB - 34...
  • Page 35 Click Right button of mouse and choose “Add to Sync list” GB - 35...
  • Page 36 On the open windows , choose “Sync ” option GB - 36...
  • Page 37 On “Sync ” window , choose the desired WMA music with DRM as step 2) And choose “Removable Disk” Click “start Sync “ to transfer the WMA music with DRM to your MP3-Player GB - 37...

  • Page 38: System Requirment

    Safely remove your MP3-Player from PC. System requirment 1. 1set compatible personal computer 2. Pentium 166 MHz MMX or faster 3. Windows 98 SE, Windows 2000 or Windows XP GB - 38...
  • Page 39 4. USB Port 5. 32MB RAM or more (64MB is recommended for Windows 2000) 6. 20MB free hard disk space or more 7. 4Xcd-ROM drive or more Installation of windows 98 Driver: NO DRIVE INSTALLATION NECESSARY UNDER WIN ME/ 2000 / XP Put the Installation CD into CD-ROM Drive and then it will be installed automatically.
  • Page 40 The windows 98 Driver will be finished installation until the last window show out. Troubleshooting 1) The software does not work properly Refer to previous pages “ Set UP Environment” 2) The player does not work or nothing is displayed on LCD. Check the capacity of the batteries.
  • Page 41 Check and / or replace the battery; Check the hold switch is in the off position; Check the connection conditions. 6) MP3 player cannot connect to PC or USB port does not function. Check the configuration of the set-up is correct or not (refer to the “set up environment”)

  • Page 42: Specification

    4.Do not recharge or dispose of battery in fire as they may explode 5.Remove battery that isn't in use for a prolonged period of time as there is a risk of leakage. MP3 Electrical Specification： Request the item Dimension Support format Compression ratio for supporting Compression rate...
  • Page 43 Sampling rate Voice Recording USB Port Memory Battery Headphone Jack Playback time Voice Recording time Download speed S/N ratio Output power Operation voltage 16KHz-48KHz FM、 Line-inRecording MP3; rate:32-128KHZ MIC: WAV;Adopt the kind rate USB Spec 1.1 32M/64M/128M/256M/512M/1GB AAA battery 3.5mm HEAD PHONE JACK: Up to 10 Hours...
  • Page 44 Language FM radio FM recording Lyric display Line-in recording DRM9 ALL INFORMATION ARE SUBJECT TO BE CHANGED WITHOUT PRIOR NOTICE! English, Chinese GB2312,Korean, Japanese, German, French, Italian, Spanish 87.5—108MHZ FM recording Player MP3 of Lyric display. Circuit recording Support DRM9 GB - 44...
