Technical data

Measured variables
Measuring range
Types of input
Input signal
Current input, passive
Cable specification
(for optional sensors with
Memosens technology)
168
15 Technical data
15.1

Input

NH -N (ammonium nitrogen), NH
4
ppm]
CA80AM-**A1/S4:
CA80AM-**A2/S5:
CA80AM-**A3/S6:
Order version with dilution function (optional)
Measuring range to be configured [mg/l
(ppm) NH -N]
4
0.5 to 50
0.5 to 50
0.5 to 50
0.5 to 50
0.5 to 50
1) Only available for the measuring range A2 (S5)
2) Dilution function disabled
• 1 or 2 measuring channels (analyzer main parameter)
• 1 to 4 digital sensor inputs for sensors with Memosens protocol (optional)
• Analog current inputs (optional)
• Binary inputs (optional)
Depending on version
2 x 0/4 to 20 mA (optional), passive, potentially isolated
Span
> 0 to 20 mA
Signal characteristic
Linear
Internal resistance
Non-linear
Test voltage
500 V
Cable type
Memosens data cable CYK10 or sensor fixed cable, each with cable end sleeves or M12
round-pin connector (optional)
Cable length
Max. 100 m (330 ft)
+ (ammonium), NH (ammonia (equivalent)) [mg/l,
4 3
0 to 20 mg/l NH -N
4
0.5 to 50 mg/l NH -N
4
1 to 100 mg/l NH -N
4
1)
Dilution factor Effective measuring range [mg/l (ppm)
NH -N]
4
1 0.5 to 50
2 1.0 to 100
4 2.0 to 200
10 5 to 500
20 10 to 1 000
Liquiline System CA80AM
2)
