- Page 1 S L Æ D E K A N A L I N S T R U C T I O N M A N U A L type 25 C H A N N E L D U C T Type 25 Version 2.0...
-
Page 3: Table Of Contents
1.2 Field of application Small cars 300 m³/h ø80/ø100 The GEOVENT Channel Duct System is a rail system, Smaller private cars 400 m³/h ø100 developed for the extraction of exhaust fumes and wel- ding smoke. When one or several trolleys have been Private cars >... - Page 4 Channel Duct Sy- stem, where they are placed as well as how many duct Tryktabstabel for slædekanal type 25 connections – and how the duct connections for the fan are placed. In addition to this, the length and the dimension of the hose as well as the way in which it is suspended are decisive for the drop of pressure.
-
Page 5: Construction
Guide strap Trolley: Powder enamelled steel, complete with 6 – for increased under pressure in the Channel Duct. smooth-running nylon wheels. In some situations with high under pressure it will be necessary to use a guide strap in order to stabilise the Balancer: Safeguards that the hose does not take up Channel Duct. -
Page 6: Installation
Furthermore, the Channel Duct may also round channel for top mounting. be mounted on a column or on a carrying arm (special equipment). End cover, type 25 in galvanised steel (remember to use sealing agent). The drawing below shows the recommended installa- tion height. - Page 7 the end of the Channel Duct should only be used Procedure: on Channel Duct lengths of up to 18 meters. Go to item 8, if the connection is to be made at the end of Start by fi xing the bracket in the ceiling, on the wall the Channel Duct.
-
Page 8: Optional Equipment
Geovent can also offer the use of an assembly 13. Preparation and mounting of the Trolley (some trolley to facilitate the mounting of the rubber lips spring balancers may be factory-mounted (optional on the Channel Duct. Use the soapy substance extras)). -
Page 9: Trial Run - Exact Adjustment
Energy saving damper HMO-24 Trafo 24/230V Wire switch/ 230V micro switch To be coupled in parallel Connection diagram for HMO damper Automatic start/stop Wire switch for automatic start/stop of the fan. To be used in connection with conductor rail and LWS control Start/stop switch panel. -
Page 10: User Instruction - Application
4.0 Maintenance Periodic maintenance 3. Loosen the nut with a 2. Loosen the nut with a • At regular intervals, the Trolley must be serviced in 17 mm fork wrench. The 1. Loosen the nut with 17 mm fork wrench. The shaft may now be adjusted a 17 mm fork wrench. -
Page 11: Liability
Wear parts like trolley wheels, hoses, etc. are not inclu- ded in the warranty. User liability In order for Geovent to be capable of granting the de- clared warranty, the user/fi tter must follow this Instruc- tion Manual in all respects. -
Page 12: Declaration Of Conformity According To Bilag Iia
6.0 Declaration of Conformity according to Bilag IIA HOVEDGADEN 86 • DK-8831 LØGSTRUP (+45) 8664 2211 • salg@geovent.dk Declares as producer hereby that: Authorized to collect the technical fi le: Product: Channel Duct System Ole Madsen Model: Type 25 is in accordance with the following Directives and Stan-...
