- Page 1 I N S T R U C T I O N M A N U A L R A I L S Y S T E M MRSP – Magnetic Rail System Premium www.geovent.com.pl Version 1.0 30-09-2020...
-
Page 3: Table Of Contents
Noise 3.0 Daily usage – user instruction ......7 4.0 Maintenance ............7 The Magnetic rail system Premium in itself does not pro- 4.1. Trouble shooting ........... 7 duce any noise. The noise level relies on a number of 5.0 Liability ..............8 factors, primarily the diameter of the hose and the extra- 6.0 Declaration of conformity ........ -
Page 4: Installation
2.0 Installation The Magnetic rail system is delivered in separate parts. The channel must be supported every 2 meters. Recommended height of installation is 3 to 5 meters. Use one suspension bracket every 2 meters of alu profile. Installation should be carried out by a trained profes- sional. - Page 5 GND is mount on the bend from the factory. Attach the two - socket to the GND. Forward direction of vehicle Assemble the two + sockets. The exhaust pipe The, side mounted exhaust pipe should be positioned according to the drawing and point at right angles or up to max.
-
Page 6: Coupling Diagram
2.1 Coupling diagram Disconnection switch X1 - 1 24VDC Disconnection switch X1 - 1 24VDC Control Panel Control panel X1 - 2 X1 - 2 307.GOV 307.GOV 24VDC 24VDC Supply Supply voltage voltage 230V 50Hz 230V 50Hz Nozzle Nozzle switch Switch 24VDC Nozzle Magnet... -
Page 7: Test Run
2.2 Test run Disconnection • Make sure the extraction hose is connected to the exhaust pipe and that it is firmly fastened to the anchor After installation, make sure that the trolly can move plate on the vehicle’s side. freely along the entire rail. Test that the nozzle stays at- tached to the vehicle while in motion and that it discon- •... -
Page 8: Liability
Wear on parts such as filter cartridges and hose is not included in the warranty. User liability In order for Geovent to be capable of granting the decla- red warranty, the user/fitter must follow this Instruction manual in all respects. -
Page 9: Declaration Of Conformity
Lise Cramer Hereby declares that: The product: Rail system Date: 30-09-2020 Models: MRSP - Magnetic rail system Premium Position: Director Name: Thomas Molsen has been manufactured in compliance with the following directives and standards: European Parliament and Council Directive 2006/42/ EC of 17 May 2006 on machinery, and amendments to Directive 95/16/EC. - Page 11 11 11...
