VALUPAK-II,
low temperature burners
Contents
1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2 Checking the usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3 Application requirements . . . . . . . . . . . . . . . . . . . . . . . . 2
4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
5 Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
6 Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
7 Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
8 VALUPAK package and back pressure . . . . . . . . . . . . . 4
9 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
10 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
11 Logistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
12 Certification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
13 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
oPeRAtInG InstRUCtIons

1 sAFetY

1.1 Please read and keep in a safe place
Please read through these instructions carefully before
installing or operating. Following the installation, pass the instructions
on to the operator. This unit must be installed and commissioned
in accordance with the regulations and standards in force. These
instructions can also be found at www.docuthek.com.
1.2 explanation of symbols
1  , 2  , 3  , a  , b  , c  = Action
➔ = Instruction
1.3 Liability
We will not be held liable for damage resulting from non-observance
of the instructions and non-compliant use.
1.4 safety instructions
Information that is relevant for safety is indicated in the instructions
as follows:
DAnGeR
Indicates potentially fatal situations.
WARnInG
Indicates possible danger to life and limb.
CAUtIon
Indicates possible material damage.
All interventions may only be carried out by qualified gas techni-
cians. Electrical interventions may only be carried out by qualified
electricians.
1.5 Conversion, spare parts
All technical changes are prohibited. Only use OEM spare parts.
1.6 Instructions provided by the company
Instructions provided by the company or individual responsible for the
manufacture and/or overall installation of a complete system incor-
porating MAXON burners take precedence over the installation and
operating instructions provided by MAXON. If any of the instructions
provided by MAXON are in conflict with local codes or regulations,
please contact MAXON before initial start-up of equipment.
· Edition 11.22 · 32-00270 · EN

Advertisement

Table of Contents
loading

Summary of Contents for Honeywell Maxon VALUPAK-II

  • Page 1: Table Of Contents

    VALUPAK-II, low temperature burners oPeRAtInG InstRUCtIons · Edition 11.22 · 32-00270 · EN 1 sAFetY 1.1 Please read and keep in a safe place Please read through these instructions carefully before installing or operating. Following the installation, pass the instructions on to the operator.
  • Page 2: Checking The Usage

    2 CHeCKInG tHe UsAGe 4 InstALLAtIon The VALUPAK-II is designed for process air heating applications. 4.1 Handling of VALUPAK-II burners This function is only guaranteed when used within the specified limits ➔ VALUPAK-II burners are shipped as complete units. Handle burn- –...
  • Page 3: Start

    4.5 Burner mounting 4.6.2 spark ignitor arrangement Burner will typically be installed through an oven wall or insulated air Detail X duct. Cut opening at least 25 mm larger in diameter than discharge sleeve to allow for sleeve expansion. Additional burner support may be required in conjunction with a stiffener plate to support burner package weight (20–25 kg).
  • Page 4: Valupak Package And Back Pressure

    ➔ A 5-fold refresh rate should be minimum. At the end of the purge Please observe the following to ensure that no damage occurs: – Before initiating the following start-up and adjustment proce- time of the burner flame safeguard programming relay ignition is dure, it is important that a check be made to verify that all of energized and the main gas valve will be energized shortly after.
  • Page 5: Maintenance

    8.2 Variable back pressures The burner can still be used but must be commissioned at highest possible back pressure. – Reducing the back pressure will result in leaner gas/air ratio, combustion will still be reliable but with increased CO and .
  • Page 6 10.1 VP-II burner specification, 60 Hz Capacity and selection data in kW, 60 Hz operation. Gross heating value = 10.9 kWh/m (st), d = 0,6 All figures are for balanced - 0 mbar - duct pressure Burner VP-II-60 VP-II-150 Blower UHC102 UHC122 UMI300 UHC122 UMI300 20 mbar Maximum heat release...
  • Page 7 10.2 VP-II burner specification, 50 Hz Capacity and selection data in kW, 50 Hz operation. Gross heating value = 10.9 kWh/m (st), d = 0,6 All figures are for balanced - 0 mbar - duct pressure Burner VP-II-60 VP-II-150 Blower UHC102 UHC122 UMI300 UHC122 UMI300 20 mbar Maximum heat release...
  • Page 8: Logistics

    On request, old units may be returned carriage paid to the manufac- turer in accordance with the relevant waste legislation requirements. FoR MoRe InFoRMAtIon The Honeywell Thermal Solutions family of products includes Honeywell Combustion Safety, Eclipse, Exothermics, Hauck, Kromschröder and Maxon. To learn more about our products, visit ThermalSolutions.
