Summary of Contents for V2C Trydan

  • Page 1 TRYDAN...

  • Page 2: Table Of Contents

    Dear Customer, The entire V2C team would like to thank you for purchasing one of our e-Chargers. Our passion for design and innovation makes all our products leaders in technology and design. If you have any suggestions for improvement, you can send us an email to info@v2charge.com.

  • Page 3: Safety Warnings

    1. SAFETY WARNINGS · The owner is obliged to comply with the safety instructions. V2C accepts no liability for any claims arising from such non-compliance. · This mode 3 charging point is classified in accordance with section 5 of UNE-EN 61851-1 in an EV power supply system connected to an AC mains supply.

  • Page 4: General Characteristics

    Protections charge status Hose support Display Power plate e-Charger: Trydan Color: Black Material: Polycarbonate MVR Weight: 2 kg (without hose) / 2,5 kg (with hose and protections) Hose length: 5 m / 10 m Hose type: Lisa / De muelle Operating temperature: -15º...

  • Page 5: V2C Led Lighting Indications

    4. V2C LED LIGHTING INDICATIONS. The V2C logo on the front of the e-Charger lights up according to the charging status: White: the vehicle is not connected. White flashing: e-Charger disabled. Blue flashing: Vehicle is charging. The speed of the flashing is directly related to the directly related to the intensity of the charge.
  • Page 6 Add your e-Charger 1. On the main screen of the app, click on the '+' icon at the top right. 2. Enter the ID number of the charging point manually or by scanning the QR code on the sticker on the charger. Find the label containing the serial number on the side of the e-Charger.
  • Page 7 Global statistics Statistics of a single charge Update your e-Charger When your charger needs updating you will receive a notification. Make sure you have a stable WiFi connection. 2. Click on the 1. Select the 3. Scroll to the bottom settings icon at the charger.

  • Page 8: Dynamic Power Control

    6. DYNAMIC POWER CONTROL 1. Log in to the V2C 2. Select the e-Charger and 3. Click on 'Dynamic Cloud application. access its configuration. power control'. 4. Activate dynamic power 5. Go back to the configuration control and select the meter screen and access 'Configure...

  • Page 9: Alexa

    2. Pull the hose outwards, removing it out of the hose holder. 9. NAVEGATION MENU INTERFACE Trydan has two buttons at the top of the left side. With these two buttons we can change the parameters (by long presses) and change the property we wish to modify (by long presses).
  • Page 10 Dynamic control If you have a consumption meter connected to Trydan, you can select YES to the dynamic control so that the load intensity varies according to the current total consumption and the load is as efficient as possible. If you do not have such a meter, select NO and go to the 'Maximum intensity' section.
  • Page 11 Once the programmed power has been configured, we can select the maximum intensity at which we want the dynamic control to act. If the consumption of the home allows it, this intensity will be the maximum intensity at which Trydan will charge your vehicle (Limit 7 - 32A). Minimum intensity Once the maximum current has been set, we can now select the minimum current we want the dynamic control to operate at.
  • Page 12 The following parameter cannot be changed. This is the unique identification number of your Trydan. This code is also indicated on the sticker on the side of the e-Charger. With this code you can link the charger to your V2C Cloud account.
  • Page 13 After configuring this parameter, if necessary, the equipment will restart. It is recommended not to charge the vehicle while performing this manipulation, although this would not be a critical problem. Note: All these settings can be made from the V2C Cloud app.

  • Page 14: Support

    In the following link you can find frequently asked questions and useful information when setting up and using your e-Charger: https://v2charge.com/trydan/support/ At V2C we have a Technical Support Centre. Enter the following link, fill in the required fields and we will contact you as soon as possible: https://v2charge.atlassian.net/servicedesk/customer/portal/3/group/4/create/12...
  • Page 15 YOUR TOMORROW www.v2charge.com...
