Assembly Instructions
Alu-Line
• Screw the X-nut flange plate
aluminum profile
M8x16 and the sliding blocks
L1
inserted; Only tighten the screws so far that the
flange plate X-nut can still be moved.
• Move the portal until the recirculating ball nut
clamping block
46
.
8
• Screw clamping block
. Use the cylinder screws M5x30
8
(tightening torque: 2 Nm) and the cylinder
screws M5x40
C6
(tightening torque: 6 Nm).
F
• Move the portal as far as possible towards the
face plate on the drive side
ball screw (red arrow in Fig. 23).
20
• Tighten the fastening screws of the flange plate
X nut / aluminum profile
8
above).
• Tighten the fastening screws
bearing unit. Tightening torque: 6 Nm
• Move the portal by turning the ball screw
far as possible towards the end plate on the
floating bearing side
• Tighten the fixing screws
bearing unit. Tightening torque: 6 Nm.
• Drive the cylinder pins
from the rear until they protrude by approx.
9
3 ... 4 mm at the front.
Note:
The clamping block
way that the lubricating nipple points upwards as
shown in Fig. 25/26. The floating bearing must
point to the right side of the machine as shown.
• Place the clamping block
recirculating ball nut on the stop edges on the
back of the guide plate Y (red arrows in Figure
25) and screw with cylinder screws M5x35
Tightening torque: 6 Nm.
www.sorotec.de
to the
8
using flat-head screws
37
already
H
is over the X nut flange plate
to flange plate X nut
46
C4
with hammer nuts slot 8 M5
by turning the
47
festziehen (see
37
on the fixed
C4
(Fig. 24).
48
for the floating
C4
into the guide plate Y
Z
must be aligned in such a
46
with the
46
37
Fig. 22: Connection of X-spindle nut and portal beam
47
Fig. 23: Adjustment of the X-spindle (1)
as
20
48
Fig. 24: Adjustment of the X-spindle (2)
24
.
C5
Fig. 25: Pre-assembly of guide plate Y and Y spindle
Page 22/33
