DIRT DEVIL
®
FULL SIZE UPRIGHT
UPRIGHT
WITH REMOVABLE HANDLE
USER MANUAL
MODEL: UD20124
IMPORTANT: READ ALL INSTRUCTIONS CAREFULLY BEFORE
ASSEMBLY AND USE.
This product is intended for Household use only.
If used Commercially warranty is VOID.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
READ ALL SAFETY WARNINGS AND INSTRUCTIONS BEFORE USING THIS PRODUCT.
WARNING:
WHEN USING AN
ELECTRICAL PRODUCT, BASIC PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED TO AVOID
ELECTRIC SHOCK, FIRE, AND/OR SERIOUS
INJURY, INCLUDING THE FOLLOWING:
Fully assemble product prior to use.
Operate cleaner only at voltage specifi ed on
data plate on bottom of cleaner.
Do not leave product when plugged in. Unplug
from outlet when not in use and before
cleaning or servicing.
Do not use outdoors or on wet surfaces.
Do not allow to be used as a toy. Not intended
for use by children age 12 and under. Close
attention is necessary when used by or near
children. To avoid injury or damage, keep
children away from product, and do not allow
children to place fi ngers or other objects into
any openings.
Use only as described in this users manual.
Use only manufacturer's recommended
attachments.
Do not use with damaged cord or plug. If
product is not working as it should, has been
dropped, damaged, left outdoors, or dropped
into water, call customer service at
1-800 321-1134 prior to continuing use.
Do not pull or carry by cord, use cord as han-
dle, close a door on cord, or pull cord around
sharp edges or corners. Do not place product
on cord. Do not run product over cord. Keep
cord away from heated surfaces.
Do not unplug by pulling on cord. To unplug,
grasp the plug, not the cord.
Do not handle plug or product with wet hands.
©2022 Techtronic Floor Care Technology Limited. All Rights Reserved. Distributed by, Royal Appliance Mfg. Co. Charlotte, NC 28262
Do not put any objects into openings. Do not
use with any opening blocked; keep free
of dust, lint, hair, and anything that may
reduce air fl ow.
Keep hair, loose clothing, fi ngers, and all parts
of body away from openings and moving parts.
Brushroll continues to rotate when in upright
position.
Turn o all controls before unplugging.
Use extra care when cleaning on stairs. To
avoid personal injury or damage, and to
prevent the cleaner from falling, always place
cleaner at bottom of stairs or on fl oor. Do not
place cleaner on stairs or furniture, as it may
result in injury or damage.
When using tools, always ensure handle is in
upright position.
Do not use to pick up fl ammable or combus-
tible liquids, such as gasoline, or use in areas
where they may be present.
Unplug before connecting Turbo Tool.
Do not pick up anything that is burning or
smoking, such as cigarettes, matches, or
hot ashes.
Do not use without fi lters and/or dirt cup in
place.
CAUTION:
TO REDUCE THE RISK OF DAMAGE:
Avoid picking up hard, sharp objects with this
product, as they may cause damage.
Store appropriately indoors in a dry place. Do
not expose machine to freezing temperatures.
Do not use sharp objects to clean out hose as
they can cause damage.
With brushroll on, do not allow cleaner to sit
in one location for an extended period of time,
as damage to fl oor can result.
Brushroll continues to turn while product is
turned on and the handle is in the upright
position. To avoid damage to carpet, rugs, and
fl ooring, avoid tipping cleaner or setting it on
furniture, fringed area rugs or carpeted stairs
during tool use.
WARNING:
TO REDUCE THE RISK
OF ELECTRIC SHOCK, THIS PRODUCT HAS
A POLARIZED PLUG (ONE BLADE IS WIDER
THAN THE OTHER). THIS PLUG WILL FIT IN A
POLARIZED OUTLET ONLY ONE WAY. IF THE
PLUG DOES NOT FIT FULLY IN THE OUTLET,
REVERSE THE PLUG. IF IT STILL DOES NOT
FIT, CONTACT A QUALIFIED ELECTRICIAN
TO INSTALL THE PROPER OUTLET. DO NOT
CHANGE THE PLUG IN ANY WAY.
NOTICE:
A THERMAL PROTECTOR HAS BEEN DESIGNED
INTO YOUR CLEANER TO PROTECT IT FROM
OVERHEATING. WHEN THE THERMAL
PROTECTOR ACTIVATES THE CLEANER WILL
STOP RUNNING.
If this happens proceed as follows:
1. Turn cleaner OFF and unplug it from the
electrical outlet.
2. Empty dirt cup.
3. Inspect the nozzle inlet, hose connector,
hose, dirt cup inlet, cyclonic fi lter and
rinsable fi lter.
REPLACEMENT PARTS
• BELT STYLE 15
• PRE-MOTOR FILTER F112
• EXHAUST FILTER F111
Phillips head screwdriver
required for assembly
4. When cleaner is turned o and motor cools
for 30 minutes, the thermal protector will
deactivate and cleaning may continue.
If the thermal protector continues to activate
after following the above steps, your cleaner
needs servicing.
DO NOT
RETURN TO STORE
®
Contact Dirt Devil
Support
for assistance with your vacuum
Chat with us!
dirtdevil.com/pages/ddcontact
Every day 8am-8pm EST
Give us a call!
800-321-1134
Mon-Fri, 9am-5pm EST
961152094-R4
.
