Page 1: Security System
WIRELESS HOME SECURITY SYSTEM Instruction Manual English Version1.0 MODEL: WA-410 www.lorexcctv.com Copyright © 2007 Lorex Technology Inc. -
Page 2: Table Of Contents
Table of Contents Introduction…………………………………………………………………………….…... System Package…………………………………………………………….…. Optional Accessories…………………………………………………………... Planning for Installation Choosing a Location………………………………………………………..…... Setting Alarm Zones…………………………………………………………... Installing the Back-up Battery………………………………………………... Powering the Main Console……………………………………………………. Connecting the Telephone Line……………………………………………...… Setting the Antenna………………………………………………………….…. Mounting the Main Console…………………………………………………..… About Passwords…..…………………………………………………………... Others………………………………………………………………………….…. Operation – Main Console……………………………………………………………….… LCD Panel Illustration…………………………………………………………... -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE OR POWER ADAPTER TO WATER OR MOISTURE • Read Instructions – All the safety and operating instructions should be read before operating this equipment. These instructions should be retained for future reference •... -
Page 4: Introduction
Thank you for choosing the Lorex® WA410 Wireless Home Security System. These security systems are high-quality, reliable and versatile. This system has a built in Auto- dialer for increased security. To ensure the best performance of your system, please read this manual thoroughly and follow the precautions and instructions presented. -
Page 5: Planning For Installation
Planning for Installation The security system is designed to be as flexible as possible in order to meet your present needs, and also to adapt as your needs change. For the reason, we recommend that you read and consider the following information and plan your system before installing these devices. -
Page 6: Connecting The Telephone Line
Connecting the Telephone Line To connect the Main Console to the telephone line, Please follow these steps: Locate the two phone jacks at the top of the main console. These phone jacks are marked “ Phone “ and “ Line “. Connect one end of the telephone cord that came with the system into the connector, labeled”... -
Page 7: Operation - Main Console
Operation – Main Console The Main Console is the heart of the security system. It monitors the sensors and responds according to how it is programmed, whenever a sensor is activated. The illustration shown for the Main Console may look complex at first, however, most procedures are straightforward and easy. -
Page 8: Function For Installer Menu
13. Armed LED : When the light is ‘on’, the system is armed; When the light is ‘off’, the system is disarmed. 14. LCD Panel : Displays messages 15. Speaker : Sounds alarm and plays back messages 16. Antenna : Used for wireless reception 17. -
Page 9: System Option Menu
3.1: System Option menu : Press 0 to start setting Setting : 0 – T 1 2 3 4 5 6 – P 7 – MSG 8 – DIAL 9 - CODE (1) 0-T : For time setting (Default is 30 seconds.) minimum 1 second, maximum 255 seconds. - Page 10 Setting 5 Setting 6 Note: The dialer will work with a touch tone service line only (3) 7- MSG : To set a recorded message which contains 1 segment of message for a maximum of 25 seconds. If the recorded message is less than 25 Sec, press ENTER to end the recorded message.
-
Page 11: 3.2: Sequence Programming Menu
Press 1 to change the Install code menu. Setting : Change Code 1 – Install Press 2 to change the Master code menu. Setting : Change code 2 – Master : 1 3 5 2 4 6 3.2: Sequence Programming Menu This menu for code learning establishes a link between all sensors/other wireless devices and the main console. -
Page 12: 3.3: Replacement Menu
listed below. It will automatically advance to the next sequencing learning order position. If the sensor that was learnt into the main console is sending a signal during the learning mode, the main console will indicate on the LCD, as shown below and will not allow duplication. -
Page 13: Function For Master Menu
be cleared. Press 3 to go into the clear mode. Clear Sensor 1 – Single Press 1 , and key-in the sequence learning order number. Press ENTER , to clear the sensor. Clear Sensor 1 – Single Clear Sensor Clear OK Num : xx Press 2 , It will display the words “Are you sure ? ”. -
Page 14: Check Function
If the password is correct, the main console will emit a long beep sound. (LCD display shown below). Now the system will select the arm mode and set the system in either Away arm/Home Arm mode (see below): A - AWAY : Press the AWAY button to set the “ Armed - Away “ alert. After the exit delay the Arm LED will illuminate steady and the system is armed in the AWAY mode. -
Page 15: Arm Or Disarm Via The Telephone Line
SP DIAL + 4 , the autodial order is: Preset 4 → Preset 1 → Preset 2 →Preset 3 (Burglary condition) SP DIAL + 5 , the autodial order is: Preset 5 → Preset 1 → Preset 2 →Preset 3 (Fire condition) SP DIAL + 6 , the autodial order is: Preset 6 →... -
Page 16: Lcd Messages
24 Hour & Home-Away Functions 24 Hour Mode The Lorex® security system can work for you 24 hours a day,7 days a week. The system features a 24 hour status capability which is important for use with some accessory sensors. The sensors that belong to the 24 hour mode include the Smoke Detector,... -
Page 17: Remote Control Handset
Remote Control Handset The key chain Remote Control Handset is a convenient way to arm (Home / Away mode) or disarm this system. Before using this device, please program it into the main console via the sequence programming menu. LEGEND 1. -
Page 18: Pir Motion Detector
• Press the PANIC button, to activate the “PANIC” function. The activation of the “PANIC” function will immediately trigger the alarm and auto dialer. 63 REMOTE SENSOR PIR Motion Detector The PIR Motion Detector is designed to detect the movement of objects in a room or hallway. - Page 19 4. BATTERY : Remove the Battery cover and insert one 9V alkaline battery. 5. ARM & HOLDER : For mounting on the wall. 6. BATTERY COVER Replace the Battery When the sensor sends a low battery message to main console, remove the old battery and replace it with a fresh alkaline battery.
-
Page 20: Door/Window Detector
Before installing the sensor, consider the following points: Mount the sensor two meters (6-1/2’) high for best coverage. Mount the sensor with a 14 degree downward incline angle against the wall for optimum range. To install the PIR Motion Sensor, please follow these steps: Take out the screws or double sided adhesive and install the mounting bracket on the wall. -
Page 21: Change The Battery
Door/Window Detector (for DC 12V battery) Change the Battery When the sensor sends a low battery message to the main console, remove the old battery and replace it with a fresh alkaline battery. The low battery message on the LCD is shown below 63 WINDOW SENSOR 01 Low battery... - Page 22 The LED on the sensor will flash once when the sensor is triggered. There cannot be a gap greater than 1/4 inch (5 mm) between the magnet sensor and the magnet, otherwise, the sensor will not work properly. Enter the installer password and press the “1” button to activate the “Sequence Programming Menu”.
-
Page 23: Mini Siren
INSTALLING POSITION REFERENCE FOR DOOR/WINDOW DETECTOR Mini Siren The siren is an effective deterrent to intruders. Choose a location inside your home where the siren is not plainly visible, but can be heard throughout the house. It is important to install the siren where the cable can be hidden, and discreetly out of reach of potential intruders (or anyone likely to tamper with the system.) When the siren is installed and the system is set to Arm, it will emit a piercing 110 decibel siren, once a sensor/detector activates the alarm. -
Page 24: Summary Of Program - Main Console
1. Plug the wire into the control panel OUTPUT JACK 2. Cord length – 8 meters. 3. Loudness output – 110 db. 4. Dimensions – 3.7 x 4.5 x 2 (cm) 5. Weight – 120g (including the cord) Summary of Program – Main Console Use the following form to record your programming choices for future reference. -
Page 25: Summary Of Sensors And Zone Settings
Item Install Code Master Code Exit Time Alarm Time Entry Time Auto-dialing Mode Preset Telephone No. for Auto-dialing : No. 1 No. 2 No. 3 No. 4 (Burglary Emergency) No. 5 (Fire Emergency) No. 6 (Help Emergency) Summary of Sensors and Zone Settings Use the following form to record the setting detail of sensors Descriptions Name... -
Page 26: Specifications
Learning Place of Number Installation 2F-xx room Learning Place of Number Installation Learning Zone Label Number Installation Window 1 Learning Zone Label Number Installation Specifications Place of Zone Label Place of Zone Label... -
Page 27: Installation Template
Items Frequency Power Source Power Consumption Back-up Battery (Optional) Temperature Range RF Range Security Code Alarm Activation Time Dialing Type Voice Message Playing Time Preset Telephone Numbers Material Weight Dimensions Installation Template Specifications - 303Mhz or 433Mhz - AC120V, DC 12V - 70mA (idle), 170mA (activated) - Approximate 7 hours ( NO AC adaptor) - 0°C... - Page 28 “Installation template for wall mounting of main control panel” 1. Use the template on the right to mark positions for mounting screws to install the main control panel on the wall. 2. Once the mounting screw positions have been marked, drill 3/16” pilot holes and install the plastic wall anchors supplied.
- Page 29 It’s all on the web Product Information User Manuals Quick Start Guides VISIT www.lorexcctv.com Lorex Technology Inc. Specification Sheets Software Upgrades Firmware Upgrades wwwlorexcctv.com...
