Lorex L404 Install Manual

STEP 1
SETTING UP YOUR DIGTIAL VIDEO RECORDER (DVR)
* This set-up guide assumes you are connecting cameras (not included with this system) to the Lorex DVR. Consult your DVR's owners manual for alternative DVR connection
and/or information to install a hard drive.
Pac ka ge C on te nts
1 - Remote Control
1 - L400 Series Digital Video Recorder
1 - Quick Installation Guide
1 - Power Cord
1 - Owners Manual & Warranty 4 - Rubber Feet (for base)
1 - Need Help Insert 1 - Rack Mount Bracket Kit
NOT INCLUDED - CAMERAS / BROADBAND ROUTER
3
Ensure to turn ON the Power switch (located at the front of
your DVR).
FRONT OF THE DVR
The number of cameras displayed on submenus will change based on the model of DVR: 4, 8, or 16 channel versions.
Information in this document is subject to change without notice. As our products are subject to continuous improvement, Lorex Technology and our subsidiaries reserve the right to modify product design, specifications and prices, without notice and without incurring any obligation. E&OE © 2006 LOREX. All rights reserved.
L400 Series
Page
Version .02

Connect the cameras (not supplied) to the CH,
CH2, CH3, CH4 Video Inputs (BNC Inputs)
BACK OF THE DVR
Your system is now ready to use. Refer to your DVR's owner's manual to
learn how to record, playback, use the search features and all other features
available with this system. Refer to Step 4 for Setting Up Remote Security
Monitoring.
BUS IN ESS & HOM E SECURI TY
2
Connect one end of the Power Cord to the
DVR; the other end to an electrical outlet
BACK OF THE DVR
NOTE: YOU WILL REQUIRE A PASSWORD TO ACCESS CERTAIN
MENU. THE DEFAULT PASSWORD IS 00000000
