Eaton 50 Series Instruction Manual

P50796 Rev 07
WIRING DIAGRAMS (Pin numbers are for reference only; rely on pin location when wiring)
Operating Voltage Models Cable Models
10-40V DC Thru-Beam Emitters
BR
BK
BU
Thru-Beam Receivers
BN
WH NPN
Load
BK
Load
BU PNP
12-240V DC or Thru-Beam Emitters
BR
24-240V AC with
Solid-State Relay
BU
Thru-Beam Receivers
BR
with Isolated AC/DC
WH
Isolated
Output
AC/DC Output
BK
BU
Thru-Beam
Receivers with
Non-Isolated AC/DC
Output
12-240V DC or Thru-Beam Emitters
BR
24-240V AC with
SPDT EM Relay
BU
Thru-Beam Receivers
BR
OR
WH
BK
BU
1
Connect load to the appropriate outlet for either sinking or sourcing operation.
2 Connecting the test input to 0V DC allows you to switch the light source off for troubleshooting while leaving the sensor under power.
3 Over current protection is to be provided in the fi eld. Conductor size for 20 AWG: 5 amp; 22 AWG: 3 amp; 24 AWG: 2 amp.
Effective: June 2010
Mini-Connector Models Micro-Connector Models
(Face View Male Shown) (Face View Male Shown)
(+) (+)
(–) OV
Test In
(–) OV Test In
(+) (+)
PNP
Load
NPN
Load (–) OV
(–) OV
L1 (+)
L1 (+)
L2 (–)
L2 (–)
L1 (+) L2 (–)
L1 (+)
Isolated
AC/DC
Output
Isolated
L2 ( – ) AC/DC Output
Load
L1 (+)
L1 (+)
L2 (–)
L2 (–)
L1 (+)
L1 (+)
COM
L2 ( – )
N.C.
COM COM
N.O.
N.O. N.C. N.O. N.C.
L2 (–)
(+)
Test In
(–) OV
MODELS COVERED IN THIS MANUAL
AC/DC Models
(+)
Load
PNP
Load
NPN (–) OV
Style
200-Foot Thru-Beam
L1 (+)
Source (Emitter)
200-Foot Thru-Beam
Detector (Receiver)
L2 ( )
–
500-Foot Thru-Beam
L2 ( – )
Source (Emitter)
L1 (+)
500-Foot Thru-Beam
Detector (Receiver)
DC Models
L2 (+)
L1 ( )
–
Style
L1 (+)
Emitter LED
200-Foot Thru-Beam
Source (Emitter)
L2 ( – )
200-Foot Thru-Beam
Detector (Receiver)
L2 ( – )
500-Foot Thru-Beam
Source (Emitter)
L1 (+)
500-Foot Thru-Beam
Detector (Receiver)
* Versions of these sensors are available with a non-isolated output. Non-isolated output models end in -45, ex. 1350E-6545. For more information, consult wiring diagrams on Page 4.
THESE PRODUCTS ARE NOT DESIGNED, TESTED, OR RECOMMENDED FOR
USE IN HUMAN SAFETY APPLICATIONS.
DURING INSTALLATION, CORRECT POWER CONNECTIONS MUST BE
MADE FIRST TO ENSURE FAIL-SAFE SHORT CIRCUIT PROTECTION OF THE
OUTPUTS. REFER TO THE WIRING DIAGRAMS IN THIS MANUAL.
DO NOT USE TOOLS TO APPLY TORQUE DIRECTLY TO SENSOR BODY.
ALIGN SENSOR BY HAND BEFORE TIGHTENING MOUNTING HARDWARE.
ADJUSTMENT POTS ARE 3/4 TURN DEVICES. ANY RESISTANCE
ENCOUNTERED WHILE ADJUSTING THESE POTS INDICATES YOU HAVE
REACHED THE ADJUSTMENT LIMIT STOP. TURNING PAST THIS STOP
WILL DAMAGE THE SENSOR.
USE ONLY THE ADJUSTMENT TOOL PROVIDED OR SUITABLE
SCREWDRIVER WHEN TURNING ADJUSTMENT POTS OR SETTING SWITCH
POSITIONS. SHARP OBJECTS CAN DAMAGE THE SENSOR AND RESULT IN
ELECTRICAL SHOCK.
ENSURE THE PRODUCT IS CONNECTED TO THE CORRECT POWER SUPPLY
FOR THE APPLICATION. REFER TO THE WIRING DIAGRAMS IN THIS
MANUAL.
AC/DC CONNECTOR VERSION SENSORS ARE EQUIPPED WITH AN AC-
TYPE CONNECTOR. THE USE OF DC POWER WITH AC-TYPE CONNECTORS
MAY NOT CONFORM WITH ESTABLISHED STANDARDS.
Page 4 Effective: June 2010
INSTRUCTION MANUAL:
ENHANCED 50 SERIES PHOTOELECTRIC SENSORS
THRU-BEAM
Integral Micro Quick
6-Foot Cable Disconnect
No Time With Time No Time With Time
Output Type Delay Delay Delay Delay
N/A 1150E-6513 N/A 1150E-6543 N/A
Solid-State Relay 1250E-6513 1250E-8513 1250E-6543* 1250E-8543* 1250E-6503
Electromechanical 1250E-6514 1250E-8514 N/A N/A
Relay
N/A 1151E-6513 N/A 1151E-6543 N/A
Solid-State Relay 1251E-6513 1251E-8513 1251E-6543* 1251E-8543* 1251E-6503
Electromechanical 1251E-6514 1251E-8514 N/A N/A
Relay
Integral Euro (Micro) Quick
6-Foot Cable Disconnect
No Time With Time No Time With Time
Output Type Delay Delay Delay Delay
N/A 1150E-6517 N/A 1150E-6547 N/A
NPN/PNP 1250E-6517 1250E-8517 1250E-6547 1250E-8547
N/A 1151E-6517 N/A 1151E-6547 N/A
NPN/PNP 1251E-6517 1251E-8517 1251E-6547 1251E-8547

INTRODUCTION

Enhanced 50 Series photoelectric sensors offer fl exibility, durability, and
WARNING
high optical performance in a low-cost self-contained package. Each
sensor features several mounting options and a low-gain indicator for quick
installation and easy alignment. Models are available for operation with
DC power, or AC and DC power in a single unit. Sensors are wired using a
6-foot power cable, body-mounted quick disconnect mini connector, body
mounted quick disconnect micro (AC/DC Micro or Euro (Micro)) connector, or
quick disconnect micro (AC/DC Micro or Euro (Micro)) connector on a short
cable pigtail. All sensors have built-in light/dark selection, and modes are
available with timing features that include on-delay, off-delay, and one-shot
delay.
An Enhanced 50 thru-beam photoelectric sensor installation consists of an
emitter and a receiver positioned on opposite sides of a detection zone. The
emitter emits infrared light, which is detected by the receiver. The receiver
output switches on when this beam of light is either blocked (when set in
dark operate mode) or completed (in light operate mode).
A complete system consists of an emitter and receiver mounted such that
the emitter directs its light beam at the receiver and the receiver is aimed
to detect the beam. The emitter and receiver can be separated by up to 61
meters (200 feet) using standard range models and 152 meters (500 feet)
using extended range models.
P50796 Rev 07
Pigtail Micro
Integral Mini Quick Disconnect Quick Disconnect
No Time With Time No Time With Time
Delay Delay Delay Delay
1150E-6504 N/A 1150E-6534 N/A
1250E-8503 1250E-6533 1250E-8533
1250E-6504 1250E-8504 1250E-6534 1250E-8534
1151E-6504 N/A 1151E-6534 N/A
1251E-8503 1251E-6533 1251E-8533
1251E-6504 1251E-8504 1251E-6534 1251E-8534
Pigtail Euro (Micro) Quick
Integral Mini Quick Disconnect Disconnect
No Time With Time No Time With Time
Delay Delay Delay Delay
1150E-6507 N/A 1150E-6537 N/A
1250E-6507 1250E-8507 1250E-6537 1250E-8537
1151E-6507 N/A 1151E-6537 N/A
1251E-6507 1251E-8507 1251E-6537 1251E-8537
Page 1
